Whirlwind ES4 2RU Digital Snake Transmitter for Cobranet, 16 Line Output, 8 Line Input, DB25 Connector, 20Hz-20kHz Frequency Response, 200 Ohms Output Impedance

SKU: WWES4TC MFR: ES4TC
Earn VIP Reward Points

Key Features

  • Experience pristine audio with the ES4 digital snake's exceptional sound quality.
  • This Whirlwind ES4 offers reliable connectivity with 16 line outputs and 8 line inputs.
  • Achieve superior durability with the rugged 2RU design of this stage box transmitter.
  • Optimize your audio setup with the ES4's wide 20Hz-20kHz frequency response.
  • Enjoy ease of use with the DB25 connector, simplifying your audio connections.
  • Get great value with the Whirlwind ES4, a high-performance audio solution for pros.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$179.99

3 Year

$249.99

5 Year

$489.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Whirlwind ES4 Specifications

  • Frequency Response

    Input (Line/Mic): +/-0.2 dBV 20 Hz to 20 kHz
    Control in detent position
    Output: +/-0.23 dBV 20 Hz to 20 kHz

  • THD + N

    Input Line Mode: <0.0015% 20 Hz to 20 kHz
    Input Mic Mode: <.0022% 20 Hz - 20 kHz
    Output: <0.0024% 20 Hz to 20 kHz

  • Mic Mode Equivalent

    Input Noise: '-124.3 dBV

  • Total Gain

    50 dBV

  • Range of Level Pot

    -40 to 20 dBV

  • Common Mode Rejection

    >60 dB

  • Maximum Input Level

    Line: 19 dBV
    Mic: -10 dBV

  • Input Impedance

    Mic and Line 20 kOhms balanced

  • Noise at unity gain

    Line: -101 dBfs
    Mic: (30 dBV gain) 95 dBfs (potentiometer at center)

  • Noise Output

    -85 dBV

  • Isolation

    Between Input Channels Line: 126 dB at 1 kHz
    Between Input Channels Mic: (40 dBV gain) 110 dB at 1 kHz
    Between Output Channels: 124 dB

  • Digital Conversion

    24 bit / 48 kHz

  • Maximum Output Level

    +20 dBV balanced

  • Output Impedance

    200 Ohms balanced

  • LED Thresholds

    Red LED: -2 dBfs, +/- 1 dBfs, Green LED: -30 dBfs, +/- 3 dBfs

  • Phantom Power

    48V DC

  • Power Consumption

    0.8 Amps at 120 VAC maximum
    0.31 A at 120 VAC minimum

  • Power Requirement

    100 to 240 VAC 50/60 Hz

  • Internal Mains Fuse

    2 A slow blow type 3AG

  • AC Dropout Voltage

    90V AC

  • Dimensions (H x W x D)

    5.25 x 19 x 12.5" / 133.35 x 482.6 x 317.5mm

  • Weight

    12lbs / 5.44kg

  • UPC Code

    69246502281

About Whirlwind ES4

Under the umbrella of professional audio equipment, the Whirlwind ES4 2RU Digital Snake Transmitter for Cobranet stands out as a high-quality, reliable, and advanced solution for your audio networking needs. Engineered with 16 line level outputs and 8 line level inputs, this American-made transmitter offers superior microphone preamplification across 16 channels and 8 line level return channels, all delivered via a choice of digital transport formats.

Configured specifically for the Cobranet format, the ES4 2RU Digital Snake Transmitter showcases exceptional performance and ease of use, making it an ideal I/O device for any digital audio network. It is equipped with a DB25 connector, a widely recognized standard for digital audio connections, ensuring seamless integration with your existing equipment.

The transmitter's frequency response range of 20Hz-20kHz enables it to handle a broad spectrum of audio signals, making it versatile for a range of applications, from live sound to recording. Each input features variable gain controls and LED level monitoring, providing you with precise control and clear visibility of your audio levels.

Constructed with durability in mind, this professional-grade transmitter is designed to withstand the rigors of regular use, making it a reliable choice for both studio and live sound environments. Experience the advanced features and high-quality performance of the Whirlwind ES4 2RU Digital Snake Transmitter for Cobranet, a key player in the realm of professional audio networking.

Whirlwind ES4 Features

  • High-quality, professional-grade Digital Snake Transmitter for Cobranet networks
  • Features 16 line level outputs and 8 line level inputs for versatile audio handling
  • Equipped with a DB25 connector for seamless integration with other digital audio equipment
  • Offers a broad frequency response range of 20Hz-20kHz, suitable for a variety of applications
  • Includes variable gain controls and LED level monitoring for precision and visibility
  • Durable and reliable, designed for both studio and live sound environments

Warranty Information

This product has a limited warranty of 60 months.

Key Features

  • Experience pristine audio with the ES4 digital snake's exceptional sound quality.
  • This Whirlwind ES4 offers reliable connectivity with 16 line outputs and 8 line inputs.
  • Achieve superior durability with the rugged 2RU design of this stage box transmitter.
  • Optimize your audio setup with the ES4's wide 20Hz-20kHz frequency response.
  • Enjoy ease of use with the DB25 connector, simplifying your audio connections.
  • Get great value with the Whirlwind ES4, a high-performance audio solution for pros.

What's in the box:

  • Whirlwind ES4 Digital Snake Transmitter for Cobranet
  • Whirlwind 5 Year Limited Warranty
