Yamaha MG20 20-Input 6-Bus Mixing Console, +48V Phantom Power, 1-Knob Compressor, Rack Mount Kit Included

SKU: YMMG20 MFR: MG20
Earn VIP Reward Points

Key Features

  • Yamaha MG20: Achieve pristine sound quality with low noise for professional audio mixing.
  • This 20-input mixer offers versatile EQ control, perfect for shaping your unique sound.
  • Use the built-in USB interface to record live performances or stream directly to your audience.
  • Enjoy peace of mind with the durable construction, designed to withstand rigorous use.
  • Utilize 12 mono and 4 mono/stereo input channels for a wide range of microphone and line inputs.
  • The one-knob compressor on this Yamaha mixer ensures dynamic control for vocals and instruments.
See More Product Details
Special Order?Estimated to Ship: 09/10/2025
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$119.99

3 Year

$154.99

5 Year

$269.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

2015-11-18T19:00:00

Rated 5 out of 5

MG20XU EXCELLENT BOARD

Very well thought out product. I use this board all the time for when I run sound for live bands, and use for my Dj service "innovative Audio Dj Service. Have also gotten many compliments from individuals at the shows. they are all very impressed and excited when they see how it works.

Innovative S.

2015-06-08T20:00:00

Rated 5 out of 5

Great and easy to mix with

I use this mixer in my church to mix the music and the sermon. I have electric drums 2 guitars electric piano and a keyboard along with 5 stage mics and a wireles mic. i have my main, my stage monitors, and a loby monitor. i also run one of my aux channels through an interface to a laptop to record the servace for posting. my ald mackie just never worked well. This new yamaha worked well the first day I hooked it up. everything behaves the way it should. and my condenser mics are very clean sounding now. my dynamics seem to havv more signal on this board and more gain headroom. It as almost like i got new mics.

odepotmike

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Yamaha MG20 Specifications

  • Phantom Power

    +48V

  • Input Channels

    Mono[MIC/LINE]: 12
    Mono/Stereo[MIC/LINE]: 4

  • Output Channels

    Stereo Out: 2, Monitor Out: 1, Phones: 1, Aux Send: 4 Group Out: 4

  • Bus

    Stereo: 1, GROUP: 4, AUX: 4

  • PAD

    26 dB(Mono)

  • HPF

    80 Hz, 12 dB/oct (Mono/Stereo: MIC only)

  • Compressor

    1-knob compressor (Gain/Threshold/Ratio) Threshold: +22 dBu to -8 dBu, Ratio: 1:1 to 4:1, Output level: 0 dB to 7 dB, Attack time: approx. 25 msec, Release time: approx. 300 msec

  • EQ High

    Gain: +15 dB/-15 dB, Frequency: 10 kHz shelving

  • EQ Mid

    Gain: +15 dB/-15 dB, Frequency: Mono 250 Hz - 5 kHz peaking, Stereo 2.5 kHz peaking

  • EQ Low

    Gain: +15 dB/-15 dB, Frequency: 100 Hz shelving

  • Peak LED

    LED turns on when post EQ signal reaches 3 dB below clipping(Mono)

  • Level Meter

    2x12 -segment LED meter [PEAK, +10, +6, +3, 0, -3, -6, -10, -15, -20, -25, -30 dB]

  • Total harmonic distortion

    0.03 % at +14dBu (20 Hz to 20kHz), GAIN knob: Min, 0.005 % at +24dBu (1kHz), GAIN knob: Min

  • Frequency response

    +0.5 dB/-1.5 dB (20 Hz to 48 kHz), refer to the nominal output level at 1 kHz, GAIN knob: Min

  • Equivalent input noise

    -128 dBu (Mono Input Channel, Rs: 150Ohms, GAIN knob: Max)

  • Residual output noise

    -102 dBu (STEREO OUT, STEREO master fader: Min)

  • Crosstalk

    -78 dB

  • Power requirements

    AC 100 - 240 V, 50 / 60 Hz

  • Power consumption

    36W

  • Operating Temperature

    0 to +40deg.C

  • Dimensions (W x H x D)

    444 x 130 x 500mm (17.48 x 5.11 x 19.68")

  • Weight

    6.90kg (15.21lbs)

  • UPC Code

    086792991566

About Yamaha MG20

FEATURED REVIEWS

MG20XU EXCELLENT BOARD

By Innovative S.

Very well thought out product. I use this board all the time for when I run sound for live bands, and use for my Dj service "innovative Audio Dj Service. Have also gotten many compliments from individuals at the shows. they are all very impressed and excited when they see how it works.

Great and easy to mix with

By odepotmike

I use this mixer in my church to mix the music and the sermon. I have electric drums 2 guitars electric piano and a keyboard along with 5 stage mics and a wireles mic. i have my main, my stage monitors, and a loby monitor. i also run one of my aux channels through an interface to a laptop to record the servace for posting. my ald mackie just never worked well. This new yamaha worked well the first day I hooked it up. everything behaves the way it should. and my condenser mics are very clean s...

View full Review

How does the Yamaha MG20 20-Input 6-Bus Mixing Console stand out in the realm of professional audio equipment This high-quality, durable mixer is designed with the discerning musician or music producer in mind. It offers an impressive 20 input channels, FX send, and 2 bus groups, providing a versatile platform for mixing and routing multiple audio sources.

Unlike other models, the MG20 features faders instead of knobs, offering a more visual and intuitive control interface. This advanced mixer also includes compression controls on channels 1-8, enabling precise volume management for a superior audio experience.

Constructed with a robust, impact-resistant steel chassis, the MG20 is designed to withstand the rigors of regular use without showing signs of wear and tear. This sleek, professional-grade mixer is not only durable but also features a state-of-the-art design that allows for convection cooling. This innovative feature ensures your power unit remains cool, even after continuous use, preventing overheating and prolonging the life of the unit.

The MG20 also boasts a unique design where the power supply is separated from the analog circuitry inside the mixer. This design choice significantly reduces background noise, resulting in a high-quality output sound that's free from interference.

Moreover, the knob placement has been strategically positioned above the chassis of the console. This thoughtful design detail protects the underlying circuitry from potential damage in the event of accidental drops or mishandling.

In summary, the Yamaha MG20 20-Input 6-Bus Mixing Console is a professional, high-quality, and versatile audio equipment choice that offers advanced features and durable construction. It's designed to deliver superior audio control and output, making it an ideal choice for serious musicians and producers.

Yamaha MG20 Features

  • 20-Channel Mixing Console
  • Max. 16 Mic / 20 Line Inputs (12 mono + 4 stereo)
  • 4 GROUP Buses + 1 Stereo Bus
  • 4 AUX (incl. FX)
  • "D-PRE" mic preamps with an inverted Darlington circuit
  • 1-Knob compressors
  • PAD switch on mono inputs
  • +48V phantom power
  • XLR balanced outputs
  • Internal universal power supply for world-wide use
  • Metal chassis

Warranty Information

This product has a limited warranty of 12 months.

Product Documents

User Manual

Key Features

  • Yamaha MG20: Achieve pristine sound quality with low noise for professional audio mixing.
  • This 20-input mixer offers versatile EQ control, perfect for shaping your unique sound.
  • Use the built-in USB interface to record live performances or stream directly to your audience.
  • Enjoy peace of mind with the durable construction, designed to withstand rigorous use.
  • Utilize 12 mono and 4 mono/stereo input channels for a wide range of microphone and line inputs.
  • The one-knob compressor on this Yamaha mixer ensures dynamic control for vocals and instruments.

What's in the box:

  • Yamaha MG20 20-Input 6-Bus Mixing Console
  • Rack-Mount Kit
  • AC Power Cord
  • Owner's Manual
  • Yamaha Warranty
