Zoom TAC-8 18 Input and 20 Output Rack-Mountable Thunderbolt Audio Interface
SKU: ZOTAC8
This item is no longer available.
Recommended Alternatives
Share:
Overview
Compare
Specs
Protection
Q&A
Questions & Answers
Reviews about this item
Review Summary
Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.
TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.
Invest In Your Gear and Peace Of Mind!
Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.
Repair or Replacement
If we can’t fix it, we’ll replace it at no additional cost.
Accidental Damage
Protect your product from drops, spills, and more.
Peace of Mind
Enjoy your gear without fear. We have you covered!
Failure Protection
When regular use of your product over time results in mechanical or electrical failure.
Zero Deductible
We will never charge you a deductible after the purchase of a plan.
Customer-Focused Support
Our claims process is simple & easy and our customer service team is happy to help.
Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500
Browse our FAQ
Zoom TAC-8 Specifications
Analog Inputs: Connectors
Inputs 1-8: XLR/TRS combo jacks
(XLR: 2 hot, TRS: TIP hot)Analog Inputs: Input gain
Inputs 1-8: 0-60 dB (1 dB steps)
Analog Inputs: Input impedance
Input 1-8: 5k Ohm
1MOhms (When IN1/IN2 Hi-Z on)Analog Inputs: Maximum input level
Inputs 1-8: +13 dBu (XLR at 0 dBFS)
+21 dBu (TRS at 0 dBFS)Analog Inputs: Phantom power
Inputs 1-8: +48 V
Analog Outputs: L/R Connectors
Master Outputs: TRS jacks (balanced)
Analog Outputs: Maximum output level
Line Outputs 1-8: +14 dBu (at 0 dBFS)
Phones 1/2: +10 dBuAnalog Outputs: Output impedance
Line Outputs 1-8: 150 Ohms
Phones 1/2: 33 ohmsAnalog Outputs: Connectors
Phones 1/2: Standard stereo phone jacks
20 mW x 2 (into 32 Ohms load)Digital IN/OUT: ADAT Optical: Connectors
ADAT Optical (lightpipe)
8 IN/OUT: 44.1 kHz/48 kHz
4 IN/OUT: 88.2kHz/96kHz, S/MUX compatible
2 IN/OUT: 176.4kHz/192kHz, S/MUX4 compatibleDigital In/Out: S/PDIF: Connectors
RCA (coaxial)
Digital In/Out: Supported sampling freq.
S/PDIF: 44.1 / 48 / 88.2 / 96 / 176.4 / 192 kHz
Word Clock: 44.1 / 48 / 88.2 / 96 / 176.4 / 192 kHzDigital In/Out: Connectors
Word Clock: BNC
Digital In/Out: Output impedance
Word Clock: 75 Ohms
Frequency characteristics
44.1 kHz: -1.0 dB, 20 Hz 20 kHz
96 kHz: -1.0 dB, 20 Hz 40 kHz
192 kHz: -1.0 dB, 20 Hz 60 kHzInput conversion noise
Measured EIN: 125 dB (IHF-A) at 60dB, 150 Ohms input
Dynamic range
AD: 120 dB typical (IHF-A)
DA: 120 dB typical (IHF-A)Sampling frequencies
192 kHz, 176.4 kHz, 96 kHz, 88.2 kHz, 48 kHz, 44.1 kHz
Bit depth
24-bit
Interface
Thunderbolt
MIDI IN/OUT
5-pin DIN jacks
Power supply
AD-19 DC12V 2A AC adapter
No. of Recording And Playback Channels
At 44.1 kHz and 48 kHz:
Recording: 18 channels (ANALOG: 8, S/PDIF: 2, ADAT Optical: 8)
Playback: 20 channels (ANALOG: 10, S/PDIF: 2, ADAT OPTICAL: 8)
At 88.2 kHz and 96 kHz:
Recording: 14 channels (ANALOG: 8, S/PDIF: 2, ADAT Optical: 4)
Playback: 16 channels (ANALOG: 10, S/PDIF: 2, ADAT OPTICAL: 4)
At 176.4 kHz and 192 kHz:
Recording: 12 channels (ANALOG: 8, S/PDIF: 2, ADAT Optical: 2)
Playback: 14 channels (ANALOG: 10, S/PDIF: 2, ADAT OPTICAL: 2)Dimensions (D x W x H)
External: 6.21 x 19.00 x 1.81" (157.7 x 482.6 x 46.0mm)
Weight
4.43 lbs (2.01kg)
UPC Code
884354014568
About Zoom TAC-8
What's in the box:
- Zoom TAC-8 18 Input and 20 Output Rack-Mountable Thunderbolt Audio Interface
- Power Adapter
- Thunderbolt Cable
- Zoom 1 Year Limited Warranty
