Autel Robotics EVO MAX 4N 4K Night Vision Drone with Smart Controller V3

SKU: A102002198 MFR: 102002198
Earn VIP Reward Points

Key Features

  • Capture stunning 4K video with the Autel EVO Max 4N drone's advanced camera system.
  • Enjoy extended flights with a maximum flight time of up to 42 minutes on a single charge.
  • Navigate confidently with the drone's GPS and obstacle avoidance for safer flights.
  • The Autel EVO Max 4N drone's night vision lets you capture clear images in low light.
  • Use the Smart Controller V3 for enhanced control and real-time video transmission.
  • The Autel EVO Max 4N's impressive range lets you explore up to 12.4 miles away.
See More Product Details

Product Options

FREE 2-Day Shipping

See Options

Qty
1

Need help? Ask our experts.

Overview
Compare
Accessories
Specs
Q&A

Questions & Answers

Reviews about this item

Review Summary

Autel Robotics EVO Max 4N Specifications

General

General

Jump to...
  • Number of Rotors

    4

  • Configuration

    Drone with Camera

  • Edition

    With Smart Controller

  • FAA Registration (Non-Commercial Usage)

    Required

  • Features

    IP Rated, Night Vision, Camera Included

  • Kit Style

    Base

  • Model

    Autel EVO Max 4N

  • Skill Level

    Enterprise

Aircraft

Jump to...
  • Color

    Gray

  • Maximum Flight Time

    42 Minutes (no wind)

  • Takeoff Weight

    4.41 lbs (1.9kg)

  • Max Ascent/Decent Speed

    Maximum Ascent Speed - 17.9 mph / 28.8 km/h
    Maximum Descent Speed - 13.4 mph / 21.6 km/h

  • Max Horizontal Speed

    51.4 mph / 82.7 km/h

  • Max Wind Speed Resistance

    27 mph / 43.5 km/h

  • Max Takeoff Altitude

    4.3 Miles / 7000 m

  • Max Hovering Time

    38 mins (no wind)

  • Max Tilt Angle

    36°

  • Max Angular Velocity

    Pitch: 300 Degree/s
    Yaw: 120 Degree/s

  • Global Navigation Satellite System (GNSS

    GPS+Galileo+BeiDou+GLONASS

  • Hovering Accuracy Range

    Vision Positioning
    Vertical: ±0.3' / 0.1 m
    Horizontal: ±0.49' / 0.15 m
    GNSS
    Vertical: ±1.0' / 0.3 m
    Horizontal: ±1.0' / 0.3 m
    RTK
    Vertical: ±0.49' / 0.15 m
    Horizontal: ±0.3' / 0.1 m

  • IP Rating

    IP43

  • Recommended microSD Cards

    microSD/microSDHC/microSDXC (UHS-III) [Class 10/U1/V10 or Faster Recommended]

  • Camera Still Resolution

    50 MP, 2 MP

  • Video Resolution

    4K

  • Image Sensor

    Wide Camera - 1/1.28 CMOS, Effective pixels: 50M
    Thermal Camera - Uncooled VOx Microbolometer

  • Lens

    Starlight Camera
    Focal Length: 35mm (equivalent 41.4mm)
    FOV:52 Degree
    Zoom Range: 1-8x, supports linkage zoom

    Thermal Camera
    FOV: 61 Degree
    Focal length: 9.1mm
    Aperture: f/1.0
    Focusing Distance: 7.21' - Infinite (2.2m - Infinite)

    Wide Camera
    FOV: 85 Degree
    Focal length: 4.5 mm (equivalent: 23mm)
    Aperture: f/1.9
    AF motor: PDAF focus

  • ISO Range

    Starlight Camera
    Auto: ISO100-ISO450000
    Super Sensitive Mode: Auto ISO100-ISO450000

    Wide Camera
    Auto:
    Photo: ISO100-ISO6400
    Video: ISO100-ISO64000 (Night scene mode: up to ISO64000)

  • Shutter Speed

    Photo: 8s - 1/8000s
    Video: 1s - 1/8000s

  • Photo Format

    JPG

  • Video Format

    MP4

  • Digital Zoom

    1 to 8x

  • Gimbal Option

    3-Axis Gimbal

  • Stabilization

    3: Pitch (Tilt), Roll, Yaw (Pan)

  • Mechanical Range

    Yaw (Pan): 180° (-135 to 45°)
    Pitch (Tilt): 90° (-45 to 45°)
    Roll: 90° (-45 to 45°)

  • Controllable Range

    Pitch (Tilt): 120° (-90 to 30°)

  • Max Control Speed (tilt)

    100°/s

  • Angular Vibration Range

    ±0.005°

Sensing

Jump to...
  • Forward

    Detection Range: 1.0 to 164.0' / 0.3 to 50 m
    Field of View: 120° (Horizontal) / 80° (Vertical)

  • Backward

    Detection Range: 1.0 to 164.0' / 0.3 to 50 m
    Field of View: 120° (Horizontal) / 80° (Vertical)

  • Lateral

    Detection Range: 1.6 to 85.3' / 0.5 to 26 m

  • Upward

    Detection Range: 0.7 to 85.3' / 0.2 to 26 m
    Field of View: 120° (Front-to-Back) / 180° (Side-to-Side)

  • Downward

    Detection Range: 0.49 to 262.5' / 0.15 to 80 m
    Field of View: 120° (Front-to-Back) / 180° (Side-to-Side)

  • Operating Environment

    The 60GHz millimeter-wave radar sensing system supports all-weather obstacle avoidance for glass, water, wires, buildings, and trees. Its obstacle avoidance distance varies with the obstacle's ability to reflect electromagnetic waves and its surface size.

Video Transmission

Jump to...
  • Operating Frequency

    2.4GHz/5.8GHz
    5.2GHz (only applicable for FCC, CE, and UKCA regions)
    900MHz (only applicable for FCC regions)

  • Transmitter Power (EIRP)

    2.4GHz: <30dBm (FCC), <20dBm(CE/SRRC/MIC)
    5.8GHz: <27dBm (FCC/SRRC), <14dBm (CE)
    5.15-5.25GHz: <23dBm (FCC/CE)
    902-928MHz: <30dBm (FCC)
    5.65-5.755GHz: <27dBm (MIC)

  • Max Transmission Distance

    12.4 miles/20km (FCC), 4.9 miles/8km (CE) (unobstructed, free of interference)

Battery

Jump to...
  • Capacity

    8070 mAh

  • Voltage

    14.88 V

  • Battery Material

    LiPo 4S

  • Energy

    120 Wh

  • Battery Quantity

    1

Remote Controller

Jump to...
  • Remote Controller

    with Remote Controller

  • Max Operating Time

    2.5 hours (Max. brightness)
    4.5 hours (50% brightness)

  • Operating Temperature

    -4 to 104 Degree F (-20 to 40 Degree C)

Physical

Jump to...
  • Dimensions

    22 x 25.6 x 5.8" (562 x 651 x 147mm) (Unfolded, incl. propellers)
    12.5 x 15.7 x 5.8" (318 x 400 x 147mm) (Unfolded, excl. propellers)
    10 x 5.7 x 5" (257 x 145 x 131mm) (Folded, excl. propellers)

  • Weight

    3.62 lbs (1.6kg) (With battery and gimbal included)

  • UPC Code

    889520218702

1 Accessories for Autel Robotics EVO MAX 4N 4K Night Vision Drone with Smart Controller V3

  • All Accessories (1)
  • Landing Gear (1)
Models
Autel Robotics EVO II DUAL 640T V2 Standard Rugged Bundle
$5,999.00

In Stock

Autel Robotics Evo II V3 Dual 640T RTK Rugged Thermal Drone Bundle
$5,799.00

$6,999.00

Save:$1,200.00 (17%)

In Stock

FeaturesCamera Included, IP Rated, Night VisionCamera Included, Thermal CameraCamera Included, Thermal Camera
Kit StyleBaseBaseBase
ConfigurationDrone with CameraDrone with CameraDrone with Camera
EditionWith Smart Controller-RTK
Video Resolution4K4K4K
Camera Still Resolution2 MP, 50 MP48 MP50 MP
Maximum Flight Time42 min.40 min.38 min.
FAA Registration (Non-Commercial Usage)RequiredRequired-

About Autel Robotics EVO Max 4N

After extensive research and development, the Autel EVO MAX 4N 4K Night Vision Drone with Smart Controller V3 emerges as a cutting-edge solution for advanced aerial photography and videography. This high-tech drone is equipped with a 4K camera, capable of capturing high-resolution images and videos, even in the most challenging lighting conditions.

The EVO MAX 4N is designed for night operations, boasting a starlight night vision feature that allows it to operate in lighting conditions as low as 0.0001 Lux. This sophisticated drone is ideal for night surveys, emergency responses, and other critical missions that require superior visibility.

Powered by Autel's advanced Autonomy Engine, the EVO MAX 4N collects surrounding environmental data and plans 3D flight paths through complex environments like mountains, forests, and buildings. This makes it a powerful tool for a wide range of commercial applications, including rapid 3D scene reconstruction, public safety overwatch, industrial inspection, and land surveying.

The EVO MAX 4N also features advanced sensors that allow it to navigate within hardened structures, underground, or in environments without GPS. Its AI recognition technology enables it to automatically identify and lock onto different types of targets such as heat sources, moving people, or vehicles, making it an invaluable tool for high-altitude tracking and data collection for law enforcement and other applications where reliable, real-time surveillance is crucial.

This innovative drone combines traditional binocular vision systems with millimeter wave radar technology, effectively eliminating blind spots and allowing operation in low light or rainy conditions. It also features advanced flight control modules and algorithms designed to counter RFI, EMI, and GPS spoofing, allowing it to fly confidently near power lines, critical structures, and in complex areas.

The EVO MAX 4N is built to withstand challenging weather conditions, with an IP43 Ingress Protection rating. It also features a hot-swappable battery system, allowing for extended flight times without any downtime.

The EVO MAX 4N is the only commercial drone that combines traditional binocular vision systems with millimeter wave radar technology. It also features the new A-Mesh system, enabling drone-to-drone autonomous communication, connection, and collaboration.

The EVO MAX 4N SkyLink 3.0 system comes with 6 antennas, 4 frequency bands, AES-256 encryption, and optional 4G integration to provide users with the most advanced flight capabilities ever in an EVO.

The Autel Enterprise App has been specifically designed for industrial applications, with a brand-new interface that streamlines operation and enhances usability. With additional features and semi-autonomous modes, the app maximizes the EVO MAX 4N's mission capability, enabling efficient and effective operation in a wide range of scenarios.

The EVO MAX 4N also comes with the Smart Controller V3, featuring a daylight readable display, super download capabilities, functional interface, ultra-long battery life, and built-in 128G storage space.

In conclusion, the Autel EVO MAX 4N 4K Night Vision Drone with Smart Controller V3 is a sophisticated, powerful, and innovative tool for advanced aerial photography and videography, offering unparalleled performance in a wide range of commercial applications.

Autel Robotics EVO Max 4N Features

  • Starlight Night-Vision Camera | as low as 0.0001 LUX and ISO ranges from 100-450,000
  • Lock Targets & Track at Night
  • Thermal Camera: 640x512 | 16x Digital Zoom
  • Wide Camera: 50MP | 1/1.28" CMOS
  • Laser Rangefinder
  • Autel SkyLink 3.0 | 12.4 miles Transmission Range
  • 720 Degree Obstacle Avoidance
  • 42 mins Max Flight Time
  • A-Mesh 1.0 | Mesh Networking Technology
  • 3D Map Planning | Multiple Mission Types | Data Security
  • Multi-channel Projection Screen
  • Autel SDK

Warranty Information

This product has a limited warranty of 12 months.

Product Documents

User Manual

Key Features

  • Capture stunning 4K video with the Autel EVO Max 4N drone's advanced camera system.
  • Enjoy extended flights with a maximum flight time of up to 42 minutes on a single charge.
  • Navigate confidently with the drone's GPS and obstacle avoidance for safer flights.
  • The Autel EVO Max 4N drone's night vision lets you capture clear images in low light.
  • Use the Smart Controller V3 for enhanced control and real-time video transmission.
  • The Autel EVO Max 4N's impressive range lets you explore up to 12.4 miles away.

What's in the box:

  • Autel Robotics EVO MAX 4N 4K Night Vision Drone
  • Smart Controller V3
  • Battery
  • Gimbal Cover
  • 64GB MicroSD Card
  • Battery Charger and Power Cable
  • 3x Clockwise Propellers
  • 3x Counter-Clockwise Propellers
  • Screwdriver
  • Smart Controller Lanyard
  • Smart Controller Cover
  • 2x Controller Joystick
  • RC Charger
  • RC Charging Cable
  • Data Cable
  • Rugged Case
  • User Manual
  • Autel Robotics 1 Year Limited Warranty
