Barco FL35 1,200 Lumens 1080p 1920 x 1080 X-Port LED 2nd Generation Projector, Body Only, Black Metallic

SKU: BAR9023114

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Barco FL35 1080 X-PORT Specifications

  • Technology

    2nd Generation Solid State LED DLP projector

  • Concept

    Single chip DLP, powered lens shift system

  • 3D capability

    Active Stereo (for the WUXGA and 1080p version)

  • 3D glasses compatibility

    IR / RF models

  • Resolution

    1,920 x 1,080

  • Brightness

    Up to 1,000 ANSI lumens (Infinitely adjustable)

  • Contrast

    Up to 8,000 : 1 (Infinite Contrast and total black with Dynamic Black enabled)

  • Aspect ratio

    16:9

  • Display colors

    30-bit

  • Latency

    About 19ms

  • Computer graphics formats

    2,560 x 1,600 - 640 x 480

  • Horizontal scan frequencies

    15 - 150 kHz (resolution dependant)

  • Vertical scan frequencies

    48 - 190 Hz (resolution dependant)

  • Video formats

    HDTV (1080p, 1080i, 720p), EDTV (576p, 480p), SDTV (576i, 480i)

  • Lens operation

    Motorized zoom, Focus, Shift, Iris and Mechanical shutter

  • Image width

    0.5 - 20m

  • Light source

    LED

  • Lamp lifetime

    Up to 100.000 hours

  • Computer inputs

    2 x DVI-D, 1 x VGA, 2 x HDMI 1.3a, 1 x XPort1, 1 x XPort2

  • Video Input

    2 x HDMI 1.3a, 1 x YPbPr, 1 x Component

  • Control possibilities

    1 x RJ-45 TCP/IP, 1 x 9-pin D-SUB RS232, 2 x USB

  • Power requirements

    Certified rating: 8.4A, - 100-240V, 50-60Hz / Typical consumption: Max 325W at 100V, - 2.7A, 50Hz; - 1.2A, 240V, 50Hz

  • Conformances

    CE, FCC Class A and cCSAus

  • Operating temperature

    50 - 104 Degree F (10 - 40 Degree C)

  • Storage temperature

    Minus 68 - 140 Degree F (Minus 20 - 60 Degree C)

  • Altitude

    Up to 3,000m

  • Operating humidity

    20 - 80% RH

  • Storage humidity

    10 - 90% RH

  • Color

    Black metallic

  • MTBF

    59,542 hours

  • BTU per hour

    Less than 1,100

  • Weight

    27.78lb (12.6kg)

  • Dimensions

    20.1 x 8.8 x 14.8" (510.0 x 223.0 x 376.0mm)

About Barco FL35 1080 X-PORT

Barco's FL35 projector has no lamp and no consumables and creates the world's most stunning image with a pixel precision of 2,560 x 1,600. Featuring 2nd generation LED illumination, the FL35 shows amazing pictures at double the resolution and 50 % more brightness than any other LED-illuminated projector, with an unmatched 100,000 hours lifetime . With its 2,560 x 1,600 native resolution, brightness level of up 1,000 ANSI lumens and 24/7 operation time - warranted for up to 5 years - the FL35 excels in image quality. The FL35 improves uptime and drastically reduces maintenance costs, operating costs, and technical resources.

Low Total Cost of Ownership
With no lamps, the 2nd generation patented solid-state ReaLED illumination provides up to 100,000 hours lifetime. The projector requires no re-calibration, no color degradation and no maintenance. This drastically improves your uptime while reducing operating costs and technical resources. Additionally, the FL35 has a low environmental footprint thanks to its low power consumption. The 2nd generation Solid State LED consumes up to 75% less power when compared to products of the same performance.

Unlimited installation flexibility
As it has no lamps, the FL35 can be placed in any orientation. With its comprehensive range of high-quality projection lenses, and industry standard mounting, it greatly simplifies installation. It features just one cabinet, complete with optics, I/O, processing, and control. The system's weight is only 16 kg (35 lbs.), including mounted lens. The rugged projector can easily be integrated onto motion platforms or in simple truss systems in any orientation angle.

Smooth imagery with Smear Reduction Processing
The unique frame rate processing and integrated adjustable SRP Smear Reduction Processing creates smooth imagery, perfect for fast-moving images.

Body only, lenses not included.

Barco FL35 1080 X-PORT Features

  • 1920 x 1080 native pixel resolution
  • Dual-link DVI input to produce more than 4 Megapixels
  • 2nd Generation solid state ReaLED illumination
  • Active 3D stereo up to 1,920 x 1,200
  • 120 Hz refresh rate for smooth imagery
  • Adjustable SRP smear reduction processing
  • Up to 1,000 lumens brightness
  • Up to 100,000 hours service life
  • Designed for 24/7 operation
  • Designed for multi-channel systems
  • Unique color matching capabilities with RealColor
  • Unrestricted installation flexibility
  • Expandable and customizable I/O
  • Wide range of Ultra high-quality projection lenses
  • Compatible with X-PORT modules for increased connectivity options
  • Suitable for Motion Simulators
  • Portrait Orientation Supported
  • Ethernet, USB, RS-232 Controllable

Key Features

  • 1920 x 1080 native pixel resolution
  • Dual-link DVI input to produce more than 4 Megapixels
  • 2nd Generation solid state ReaLED illumination
  • Active 3D stereo up to 1,920 x 1,200
  • 120 Hz refresh rate for smooth imagery
  • Adjustable SRP smear reduction processing

What's in the box:

  • Barco FL35 1080p X-PORT LED 2nd Generation Projector
  • Remote Control
  • Batteries
  • Barco Limited 2 Years Warranty
