Bosch Conettix D6100 Communications Receiver/Gateway, 120 VAC Transformer

The Conettix D6100 Communications Receiver/ Gateway provides alarm communications over two PSTN lines. The D6100 has a compact, economical design that is well-suited for applications such as small central stations, gated communities, security offices, or university campuses. The D6100 uses the same firmware and supports the same major communication formats as the Conettix D6600 Communications Receiver/Gateway.

PSTN Communications Configuration
This configuration uses existing telephone lines. A control panel's signal transmits over a PSTN analog telephone line to the D6100. The D6100 translates the signal to a common data format and sends the signal through RS-232 to a central station automation system.

Conettix D6200 Programming/Administration Software
Conettix D6200 Programming/Administration Software is a PC-based application that allows users to view, change, upload, and download D6100 programming parameters through an RS-232 serial port. With the Conettix D6200 Programming/Administration Software, users can edit programming parameters and view the status of the receiver.

Functions
Communication Formats

• Acron Superfast • ROBOFON
• Ademco Slow • Scantronics Scancom
• Ademco Express • SERIEE FSK/DTMF
• Ademco High Speed • Sescoa Super Speed
• Ademco Contact ID • SIA 8/20/300
• CFSK BELL/V.21 • SIA ADT
• FBI Superfast • SIA V.21
• Franklin/Sescoa • Silent Knight Fast
• ITI • Silent Knight FSK
• Radionics BFSK • Standard Pulse Formats
• Radionics Hex • Sur-Gard DTMF
• Radionics Modem II • Telim
• Radionics Modem IIe/IIIa2 • Veritech FSK

PSTN Communications

Function:
Caller identification (Caller ID) alarm processing stores corresponding handshake formats. The processing automatically recalls the format when the same caller identification is processed.
Benefit:
Shortens the amount of time that calls are connected to the receiver. Decreases money spent on fixed hardware or monthly phone bills.

Additional PSTN Communication Advantages
• Receives signals on two telephone lines simultaneously.
• Independent, configurable communication format settings for each telephone line.
• Visual front panel light emitting diode (LED) indicators for on-line and line-fault status conditions.

Two-way Audio
• Able to transfer calls to another line or extension
• Activated by account numbers and by events

Flash Technology
Using the Conettix D6200 Programming/ Administration Software, flash technology in the D6100 allows for software upgrades without additional hardware or firmware changes.
