Bosch PRS-SW Praesideo Software

This software has three parts:

• Configuration software, which is installed in the network controller
• Diagnostic & logging software, which is installed in the network controller and optionally on a logging PC
• File transfer software, which is to be installed on the configuration PC and supplied together with the network controller

Configuration software
The configuration software is required for every system. Once the configuration data entry has been completed and downloaded to the network controller, the system can operate without the configuration PC. The configuration software is required only during installation and to make changes to an existing system configuration. The configuration software design allows even first time users to navigate easily through the configuration.

Diagnostic and logging software
The main function of the diagnostic & logging software is to monitor and record the status of all elements of the PA system. This software logs all events, such as calls and changes in the status of system components and displays the current status of the system. It can provide real-time logging to a PC.

File transfer software
The file transfer software transfers both data and message files from the PC to the network controller.

Functions

Configuration Software
The software supports three access levels: administrator, installer and user. Each of the three levels carries different access rights. Call macros allow users to configure various functions and/or actions that can be assigned to inputs such as control inputs and call station keys. The same call macro can be assigned to multiple inputs. A call macro defines: priority, start and end tones, an audio input, a message or sequence of messages, number of repetitions, scheduling with duration and interval and more.

Zone grouping allows the user to define zones covering the same types of area. In the zone configuration, zone-related items such as amplifier channel outputs, audio outputs and control outputs can be assigned to defined zones. A power amplifier can be linked to a spare power amplifier so that if there is a fault in the power amplifier it will automatically change over to the spare power amplifier. The ratio of main power amplifiers to spare power amplifiers is flexible and can be configured to meet specific application requirements.

The software can configure all equipment inputs and outputs in the system. All audio inputs and outputs have audio processing facilities, including parametric equalization with high and low-pass filters for inputs and outputs and gain and limiter adjustments for inputs only. The audio inputs can be set to microphone or line. Delays can be configured for each amplifier output individually. The level of the 20 kHz pilot tone will be adjusted automatically. Keys on call station keypads can be configured with various functions.

A call station can be defined as an emergency call station, with the ability to add zones or audio outputs during an announcement. Control inputs can be configured for a sequence of functions. Control inputs can be configured for monitoring lines connected to them for open-circuits and short-circuits. Zones can be configured for various, time-based volume settings. BGM sources can be assigned to music channels, which can be assigned to different zones/audio outputs.

Diagnostic and Logging Software
Modes of enquiry supported by the software include general events, call logging and fault logging. This part of the software allows monitoring the fault status of all units, as well as any status changes in the system. Users can view the last 200 fault messages, which are stored in the network controller. Control inputs can be used for reporting the fault status of third-party equipment, which is not part of the Praesideo system, allowing users to view logged events of monitored external devices.

The software also provides control of audible and visual fault indicators. Faults and alarm states can be acknowledged and reset and the acknowledgement and reset actions are logged. Optionally, a PC-based logging server can store events from multiple systems in a database. This can be accessed remotely by a dedicated Praesideo log viewer program.

File Transfer Software
File transfer is protected by user IDs and passwords. The message set (a set with multiple wav files), which has to be stored in the network controller, can be assembled, stored on the PC and sent to the network controller. A configuration file, which has been created in off-line mode, can be transferred to the network controller. The configuration file can also be retrieved from the network controller.
