Bright Tangerine 57-60mm DJI Riser Shim for Sony VENICE Extension System Mini

The DJI Riser Shim provides elevation for compatible cameras, setting them to the correct height for use on DJI RS gimbals when combined with the DJI RS Receiver for LeftField Mini. Compatible with cameras such as the Sony VENICE Extension System Mini (E-Mount), the Riser Shim is a small but essential component for gimbal shooting.

Elevate your camera setup with the DJI Riser Shim for LeftField Mini Baseplates: designed to elevate cameras to the correct height for gimbal shooting. Sitting between the LeftField Mini and DJI RS Receiver, the Riser Shim mounts cleanly and is intuitively designed to give the proper height clearance to cameras with low optical centers - see the "Compatibility" section below for a full list of compatible cameras. Lightweight and wear-resistant, the 57mm-60mm Riser Shim is essential for compact shooting.

Designed for LeftField Mini
Want to mount more compact cameras to a DJI gimbal? Use the Riser Shim to set the cameras listed below to the correct height. With the LeftField Mini being a deliberately downsized version of our bestselling LeftField 3 Baseplate, the Riser Shim has been designed to maintain that same minimal form factor.

Compact Clearance
With Riser heights, you have approximately 3mm of leeway - which gives our Riser Shim the potential for a broad range of compatibility. For cameras with an optical center distance of 72mm and 74mm, such as the Sony VENICE Extension System Mini (E-Mount), this Riser Shim is ideal for elevating it on your Baseplate.

Note: The Shim also factors in the added 14.75mm of height added by the Universal Dovetail

Easy Installation
The Riser Shim mounts to your LeftField Mini's central channel via four M4 screws, sitting snugly within the baseplate. The three marked screw threads on the corners are for the DJI Receiver: which is also installed with the same M4 screws and just a few turns of a 3mm Hex Key.

Part of the LeftField System
The LeftField system of quick-release baseplates are the most convenient mounting option for professional filmmakers. Our patented Open UP system allows you to cleanly mount your camera rig to any ARRI standard dovetail in moments, and release it just as quickly.

Compatibility
The DJI Riser Shim bridges the gap between the LeftField Mini Baseplate and the DJI Receiver - setting specific cameras to the correct height for use on DJI RS gimbals. Cameras with an optical center height between 72mm and 74mm are compatible with this Riser Shim, such as: Sony VENICE Extension System Mini (E-Mount)
