Centrance MixerFace R4R Specifications

Analog

Analog

Jump to...

  • Phantom Power

    48 V, channels 1 & 2

  • Mic Preamplifier Gain

    +10 dB to +53 dB

  • Mic Input Impedance

    1k Ohms

  • Line Input Impedance

    10k Ohms

  • Hi-Z Input Impedance

    1M Ohms

  • High-Pass Filter

    130 Hz, 6 dB/octave roll off

  • Frequency Response

    20 Hz to 20 kHz +/-0.5 dB

  • Signal to Noise Ratio

    >103 dB, no weighting

  • Total Harmonic Distortion (THD) + N

    0.002%

  • Crosstalk at 1 kHz

    -95 dB

  • Aux

    3/4 Nominal Input Level: .2 Vrms / +9.2 dBu

  • Nominal Line Level

    Output at 1 kHz: 2.9 Vrms / +11.3 dBu

  • Balanced Output Level

    Nominal: 3.5 Vrms / +13.1 dBu

  • Output Impedance

    1Ohms (headphone output)

  • Output Power

    Headphone Output: 400 mW (total) at 32 Ohms

  • Supported Headphones

    16 to 600 Ohms

  • Gain Switch

    46 dB of gain reduction (set low to feed DSLR)

Digital

Jump to...

  • Resolution

    6-bit, 24-bit and 32-bit

  • Sample Rate

    44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.2 kHz and 192 kHz

  • Clocking

    Two custom, mil-spec clocks, 10 ppm precision, 1 ps jitter

  • Compatibility

    iPhone, iPad, Android, Mac, Linux, Windows. Driver is available for Windows

  • USB Input

    USB 2.0, fully compatible with USB 3.1

General

Jump to...

  • Mic Preamps

    Custom designed Jasmine technology, dual-stage analog preamplifier

  • Headphone Amplifier

    Custom designed AmpExtreme technology with bipolar power supply

  • AC Adapter

    Supports standard 5 V chargers/adapters with a micro-USB cable

  • DC Current Requirements

    +5 V from adapter, such as iPad charger. 2A or more recommended

  • Power Supply

    Analog: Battery-isolated, triple-filtered +/-7 V analog power supply rails
    Digital: Five independent, high-efficiency switch mode power supplies

  • Rechargeable Battery

    Li-Po, 8 hours play/record time (varies with phantom-powered mics)

  • Dimensions (LxWxH)

    4.8 x 2.8 x 1.4" (12.19 x 7.11 x 3.56cm)

  • Weight

    1 lbs (0.45kg)

Other

Jump to...

  • UPC Code

    899862001351

About Centrance MixerFace R4R

The MixerFace R4R model retains all the features of its parent MixerFace R4, a mobile recording interface for smartphones, tablets and computers, but adds a built-in, "one-button record," stereo micro-SD card recorder for added in-the-field flexibility and recording redundancy. This allows you to stream audio via the phone, while recording a local copy to the internal SD card recorder, a level of flexibility unmatched by any existing field recorders.

Centrance MixerFace R4R Features

  • R4R retains all the features of the original MixerFace R4 and adds a one-touch micro-SD card recorder
  • R4R simultaneously records to SD-card and to a digital device (smartphone, tablet, laptop, etc.)
  • For extra redundancy with video, feed the analog output to a DSLR for simultaneous audio recordings
  • The smartphone, micro-SD card and line outputs are all fed the same stereo mix for safety/redundancy recording
  • Internal rechargeable battery is designed to last an entire gig, charges from any USB charger
  • Dual Jasmine Mic Preamps with true 48V phantom power deliver boutique audio quality
  • Two Neutrik combo XLR jacks to record from Mic, Line or Instrument sources
  • High Pass Filters to cut wind noise during location recording
  • Dual Hi-Z inputs place a "direct box" inside MixerFace for recording electric guitar or bass
  • Adjustable Zero Latency Monitor control for dialing in the perfect headphone mix
  • Stereo AUX input to mix in a 2-channel source
  • AmpExtreme headphone amp for extra loudness and clarity, with no distortion
  • Balanced and un-balanced outputs for flexible speaker monitoring
