ClearOne INTERACT Pro 8-Channel AEC Microphone Mixer with Built-in Telephone Hybrid, DSP with 8 Mic/Line Inputs, 2 Line Inputs, 8 Line Outputs

SKU: CO910154055 MFR: 910-154-055
Earn VIP Reward Points

Key Features

  • Achieve crystal-clear audio with advanced noise cancellation technology.
  • Seamlessly integrate with existing systems using versatile connectivity options.
  • Enhance conference calls with the built-in telephone hybrid feature.
  • Optimize sound with the 8-channel AEC microphone mixer for balanced audio.
  • Customize audio settings using DSP for tailored sound output and clarity.
  • Ensure clear communication in any meeting space with echo cancellation.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$299.99

3 Year

$449.99

5 Year

$949.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

ClearOne INTERACT Pro Specifications

  • Audio Performance

    Conditions: Unless otherwise specified, all measurements are performed with a 20 Hz to 22 kHz BW limit (No Weighting)
    Frequency Response: 20 Hz to 22 kHz BW, Max Gain
    Noise (EIN): -124 dBu, 22 kHz BW, Max Gain
    Rs = 150 Ohms THD+N: < 0.02%
    Dynamic Range: 100 dB (non A-weighted)
    Crosstalk < -91 dB rel 17 dBu
    Sampling Rate: 48 kHz
    A/D - D/A Converters 24-bit

  • Auto Mixer Parameters

    Number of Open Microphones (NOM)
    PA Adaptive Mode
    First Mic Priority Mode
    Last Mic Mode
    Maximum # of Mics Mode
    Ambient Level
    Gate Threshold Adjust
    Off Attenuation Adjust
    Hold Time
    Decay Rate

  • Matrix Mixing Parameters

    8 Mic/Line Analog Inputs
    2 Line Inputs
    8 Line Outputs
    8 Line Mic/Line in Expansion with Optional
    INTERACT Pro 8i
    3 Assignable Processing Blocks IN/OUT

  • Microphone Input Parameters

    Input Gain Adjust
    Mic or Line Level
    Phantom Power ON/OFF
    Echo Cancellation ON/OFF
    Noise Cancellation ON/OFF
    PEQ
    Filters
    Mute ON/OFF
    Chairman Override ON/OFF
    AGC ON/OFF
    Automatic Level Control ON/OFF
    Auto Gate/Manual Gate
    Adaptive Ambient ON/OFF

  • Assignable Processing Blocks

    Channels: 3
    Filter Nodes: 4 Per Channel
    Filter Types: All Pass, Low Pass, High Pass,
    Low Shelving, High Shelving, PEQ, Notch
    Compressor: 1 Per Channel

  • Mic/Line Inputs 1-8

    Impedance: 5 kOhms Per Leg or 10 kOhms Balanced
    Maximum Level: -65 dBu to +17 dBu
    Echo Cancellation: 128 ms Tail Time (Works with 12 dB of Room Gain)
    Phantom Power: 24 VDC at 10 mA

  • Line Inputs 9-10

    Impedance: 5 kOhms Per Leg or 10 kOhms Balanced
    Maximum Level: 17 dBu

  • Line Outputs 1-8

    Impedance: 50Ohms Per Leg
    Nominal Level: 0 dBu
    Maximum Level: 17 dBu

  • Telephone Interface

    Telephone Audio Performance Conditions: Unless otherwise specified, all measurements are performed with Transmit Limiter and Receive ALC disabled
    Frequency Response: 250 Hz to 3.3 kHz +/-1dB
    THD+N: < 0.30% re-max level 250 Hz to 3.3 kHz
    SNR: > 62 dB re-max level
    Telco Line Echo Cancellation
    Tail Time: 32 ms
    Null: 55 dB Nominal
    Telephone Noise Cancellation
    Noise Cancellation 6-15 dB Attenuation

  • RS-232 Control Port

    DB9 female
    Baud Rates: 9,600 / 19,200 / 38,400 / 57,600 (default) / 115,200
    Protocol: 8-bit / 1 Stop / No Parity
    Hardware Flow Control ON(Default)/OFF

  • USB Configuration Port

    USB 2.0 Compatible
    Type: B Connector

  • LAN

    10/100 Ethernet
    RJ-45 with Activity LED
    Supports: Telnet, HTTP

  • Expansion Bus In/Out

    Cable: CAT5 Twisted Pair, Solid Conductor
    Maximum Cable Length:
    Between INTERACT Pro & INTERACT Pro 8i: 80' (24.38m)
    Between INTERACT Pro/Pro 8i & INTERACT COM: 80' (24.38m)

  • Configuration Software

    INTERACT Supports:
    Microsoft XP, Vista and Windows 7

  • Power Supply

    Primary Voltage: 100 to 240 VAC
    Auto-Sensing, 50-60 Hz
    Power Consumption: 26W max

  • Compliance

    ROHS Compliant
    WEEE Compliant
    UL Safety Listed
    AES48-2005 AES Standard on Grounding and EMC Practice

  • Dimensions (WxDxH)

    17 x 7.5 x 2" (43.18 x 19.05 x 5.08cm)

  • Weight

    4.5 lbs (2.04kg)

About ClearOne INTERACT Pro

Experience the pinnacle of professional conferencing with the INTERACT Pro 8-Channel AEC Microphone Mixer. This comprehensive and adaptable conferencing system delivers unparalleled audio performance, making it an essential tool for any modern business. With its easy configuration and expandability, the INTERACT Pro seamlessly integrates with enterprise telephones, HD conferencing systems, and emerging Unified Communication (UC) endpoints, including popular desktop UC applications like Skype and Microsoft Lync.

The INTERACT Pro is built on the legacy of ClearOne's HDConference technology, known for its exceptional audio clarity. It offers true stereo echo cancellation for up to 16 microphones, superior noise cancellation, full-duplex sound, and automatic microphone gating and speaker level controls. These features ensure that you never miss a word in your professional conferences, providing the ultimate in flexible room solutions.

The INTERACT Pro is designed to enable Unified Communication in the conference room. Its USB port connects to PCs for Skype, WebEx, and other A/V conferencing applications, while the headset port is compatible with Cisco, Avaya, and Nortel handsets. With ClearOne's HDConference and new true stereo AEC, you can expect unrivaled audio quality and intelligibility.

The INTERACT Pro also features Stereo Echo Cancellation, perfect for use with HD video conferencing or Telepresence. Its Distributed Echo Cancellation effectively eliminates echo, while the noise cancellation feature reduces background noises from fans or HVAC systems. The full-duplex sound allows participants to speak and listen simultaneously without interruption, and automatic level controls keep participants' audio balanced and consistent.

The INTERACT Pro is scalable and flexible to meet most conferencing needs, with options for a wireless or wired controller. Additional features include the INTERACT Tabletop Dialer for room control and the INTERACT COM for direct interface to PC or enterprise telephone sets. It also interoperates with NetStreams A/V over IP systems, making it easy to install, program, and use.

Whether for Unified Communications, Rich-Media Systems, Web Conferencing, Personal Computers, IP Telephony, Video Conferencing, Telepresence, Board Rooms, Conference Rooms, or Executive Offices, the INTERACT Pro 8-Channel AEC Microphone Mixer is your solution for superior audio performance in professional conferencing.

ClearOne INTERACT Pro Features

  • Seamless integration with UC systems, including Skype and Microsoft Lync
  • ClearOne HDConference technology for crystal-clear audio clarity
  • True stereo echo cancellation with up to 16 microphone capacity
  • Full-duplex sound for simultaneous speaking and listening
  • Noise cancellation for pristine sound in noisy environments
  • Easy installation with scalable options for conferencing needs

Key Features

  • Achieve crystal-clear audio with advanced noise cancellation technology.
  • Seamlessly integrate with existing systems using versatile connectivity options.
  • Enhance conference calls with the built-in telephone hybrid feature.
  • Optimize sound with the 8-channel AEC microphone mixer for balanced audio.
  • Customize audio settings using DSP for tailored sound output and clarity.
  • Ensure clear communication in any meeting space with echo cancellation.

What's in the box:

  • ClearOne INTERACT Pro 8-Channel AEC Microphone Mixer
  • ClearOne 2 Year Warranty
