Dwarf Connection DC-LINK CLR2.MKII Transmitter and Receiver Kit with DC-GO Director's Monitor Cage and Case

SKU: DWDCLI0020

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Dwarf Connection CLR2.MKII Specifications

General

General

Jump to...
  • Power

    7.2-18V DC

  • Range

    984.2' (300m)

Transmitter

Jump to...
  • Connectors

    2x SDI
    1x HDMI in
    1x SDI loop out
    1x mini USB

  • Power consumption

    8W

  • Dimensions (L x W x H)

    5.13 x 2.83 x 0.86" (130.5 x 72 x 21.75mm)

  • Weight

    10.18 oz (288.8g)

Receiver

Jump to...
  • Connectors

    2x SDI
    1x HDMI out
    1x mini USB

  • Power consumption

    8W

  • Dimensions (L x W x H)

    5.54 x 3.93 x 0.88" (140.95 x 100 x 22.4mm)

  • Weight

    13.28 oz (376.6g)

DC-GO Monitor Cage

Jump to...
  • Material

    Aluminum, Leather

  • Compatibility

    Atomos Shogun 7

  • Mounting

    Monitor Mount: 2x Included 1/4"-20 Male Screw

  • Dimensions

    14.96 x 5.71 x 2.95" (38 x 14.5 x 7.5cm)

  • Weight

    21.16 oz (600g) (without monitor & receiver)
    Weight: 27.65 oz (784g)

Flexible Sword Antenna

Jump to...
  • Compatibility

    DC-LINK

  • Antenna Type

    Paddle

  • Beamwidth

    Horizontal: 360 Degree
    Vertical: 40 Degree

  • Polarization

    Vertical

  • Connector

    1x Coaxial RP-SMA Male

  • Operating Frequency

    5100 to 5800 MHz

  • Gain

    3.3-dBi

  • Number of Antennas

    5

  • Height

    6.3" (160mm)

  • Weight

    0.6 oz (17g) (Each Antenna)

D-Tap Cable

Jump to...
  • Connector 1

    D-Tap

  • Connector 2

    4-Pin LEMO-Type

  • Length

    19.7" (50cm)

  • Weight

    1.23 oz (35g)

DC-LINK.MKII Case

Jump to...
  • Weight

    4.25 lbs (1.93kg)

DC-GO Case

Jump to...
  • Compatibility

    DC-GO

  • Weight

    7.05 lbs (3.2kg)

  • UPC Code

    0659436478527

About Dwarf Connection CLR2.MKII

- CLR2.MKII Transmitter and Receiver -
"C" stands for "Compact" - and that is what the CLR2 is all about. Wireless video with no external antennas, it is small and practical. Its transmission range of 300m makes it ideal for film sets and similar production environments.

- DC-GO -
With the DC-GO Director's Monitor Kit Dwarf Connection comes up with a cage Solution that is designed to solidly hold the components of your choice while being as compact as possible.

We put a lot of effort in developing a tool that makes compromises unnecessary. The tailor made back plate perfectly fits all Dwarf Connection DC-LINK wireless receivers and your preferred director's monitor, customized cables are just as long as they need to be.

This first edition of the DC-GO Director's Monitor Kit includes the DC-GO Base Unit and the Mounting Kit for the very popular ATOMOS Shogun 7 and DC-LINK wireless systems, including customized cables to connect your DC-LINK to the monitor and its battery.

- DC-GO Case -
This is our transport case with custom cut foam inlay with space for your DC-GO.

- Flexible Sword Antenna -
Our standard antennas is Light, flexible and powerful.

Note: Please make sure that the flat surface of the antennas is facing in the RX direction.

- D-Tap to Right Angle LEMO 4-Pin Cable -
D-Tap to 90 Degree 4-Pin cable for your DC.LINK devices.

- Case -
This is our transport case with custom cut foam inlay with space for your DC.LINK TX, RX, antennas, cables and other stuff.

Dwarf Connection CLR2.MKII Features

  • CLR2.MKII Transmitter and Receiver Features
  • Wireless video with no external antennas, it is small and practical
  • Its transmission range of 300m makes it ideal for film sets and similar production environments
  • DC-GO Director's Monitor Cage Features
  • High grade Aluminum & genuine leather handles
  • Tailor made for a compact setup of monitor and DC-LINK wireless receiver
  • Director's monitor cage solution that is designed to solidly hold the components
  • Flexible Sword Antennas Features
  • Compatible with DC-LINK
  • Antennas is Light, flexible & powerful
  • Vertical Polarization Antenna
  • Coaxial RP-SMA Male Connector
  • 3.3-dBi Gain
  • D-Tap to Right Angle LEMO 4-Pin Cable Features
  • D-Tap to Right Angle LEMO-Type 4-Pin Connector
  • 19.7" Cable Length
  • Case Features
  • Compatible with CLR2.MKII Transmission System
  • Custom cut foam inlay with space

Key Features

  • CLR2.MKII Transmitter and Receiver Highlights
  • Wireless video with no external antennas, it is small and practical
  • DC-GO Director's Monitor Cage Highlights
  • High grade Aluminum & genuine leather handles
  • Flexible Sword Antennas Highlights
  • Antennas is Light, flexible & powerful

What's in the box:

  • CLR2.MKII Transmitter
  • CLR2.MKII Receiver
  • DC-GO Base Unit
  • Back Plate
  • Power Cable (DC-LINK to Battery)
  • SDI Cable (DC-LINK to Monitor)
  • 2x Leather Handgrip
  • Neck Strap
  • Screw Set
  • Allen Wrench
  • 3x Flexible Sword Antennas (DC.X.0020)
  • 2x D-Tap to Right Angle LEMO 4-Pin Cable (DC.X.0026)
  • Magic Arm
  • Hotshoe Mount
  • Case (DC.X.0027)
  • DC-GO Case (DC.X.0028)
  • (Monitor/Sun Hood/NPF Batteries/2.1mm Hollow Plug Not Included)
  • Dwarf Connection 2 Year Limited Warranty
