16% Off

Electro-Voice Zx5-90 600W 15" 2-Way Full-Range Loudspeaker, 90x50deg., 8 Ohms Nominal Impedance, 98 dB Sensitivity, 58Hz-18kHz, 2x Neutrik Speakon, Single, White

SKU: EVZX590W MFR: F.01U.265.566
Earn VIP Reward Points

Key Features

  • Experience powerful, full-range sound with this 600W Electro-Voice PA loudspeaker.
  • Achieve optimal audio clarity with a frequency response of 58 Hz - 18 kHz for live sound.
  • This durable PA speaker is built with a robust polypropylene enclosure for lasting use.
  • Enjoy flexible setup options with multiple suspension points on this reliable loudspeaker.
  • Get wide sound coverage with 90x50 degree dispersion, perfect for venues and events.
  • Connect easily using Neutrik Speakon connectors, ensuring a secure and high-quality signal.
See More Product Details
FREE 2-Day Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$139.99

3 Year

$184.99

5 Year

$339.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Shopper : Why Did You Choose This?Jaswinder S : To add to existing Electrovoice speakers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Electro-Voice Zx5-90 Specifications

  • Frequency Response (-3 dB)

    58 Hz - 18 kHz

  • Frequency Response (-10 dB)

    39 Hz - 20 kHz

  • Recommended Hi-pass Frequency

    36 Hz

  • Axial Sensitivity

    98 dB (1W/1m)

  • Max. Calculated SPL

    132 dB

  • Horizontal Coverage

    90 deg.

  • Vertical Coverage

    50 deg.

  • Power Handling (Passive)

    600W Continuous, 2400W Peak

  • LF Power Handling (Biamp)

    500W Continuous, 2000W Peak

  • HF Power Handling (Biamp)

    40W Continuous, 160W Peak

  • LF Transducer

    DVX3150, 15" (381mm) Driver

  • HF Transducer

    ND2, 1" (25.4mm) exit Neodymium Compression Driver

  • Crossover Frequency

    1.5 kHz

  • Nominal Impedance

    8 Ohms

  • Minimum Impedance

    6.5 Ohms

  • Connectors

    (2) Neutrik Speakon NL4's

  • Enclosure Material

    Polypropylene Structural Foam

  • Suspension

    Enclosure has locations for 5 Single-Stud Attachment Plates and 10 Forged Steel Eyebolts - 2 on Top, 2 on Bottom, 2 on Side, and 4 on Rear of Enclosure

  • Grille

    Polyester Powder Coated, 16GA Galvanized Steel, with Rotatable Logo

  • Environmental

    IEC 529 IP24

  • Dimensions (H x W x D)

    692 x 446 x 411mm (27.24 x 17.55 x 16.18")

  • Weight

    22.2 kg (49.0 lbs)

  • UPC Code

    00800549682398

About Electro-Voice Zx5-90

You'll experience no-compromise audio performance and versatility with the Electro-Voice ZX5-90 600W 15" 2-Way White Full-Range Loudspeaker, a compact yet powerful audio solution. This high-quality, durable loudspeaker is engineered with state-of-the-art transducers at its core.

The DVX3150, a high-performance low-frequency transducer, is designed using advanced computer-aided techniques. This results in forced air, directional voice coil cooling for high power and efficiency. The suspension and magnetic structure are optimized through finite element analysis, ensuring long, linear travel for low distortion and greater LF extension. Forged magnetic components and special materials contribute to the reliability of this lightweight transducer, which boasts a 500W power rating.

The ND2, a 2" voice coil compression driver, leverages a neodymium motor structure for maximum output while minimizing size and weight. Its precision phasing plug and titanium diaphragm enhance HF performance, and the integral heatsink ensures cooling for high power output.

The ZX5-90's enclosure is crafted from injection-molded high-impact polypropylene structural foam, making it incredibly durable and stylish. The enclosure geometry has been meticulously designed for maximum rigidity and optimal bass response.

This reliable loudspeaker is not only perfect for delivering powerful sound but also doubles as an excellent stage monitor, offering two angles (45deg. or 55deg.) without any additional accessories. It comes equipped with three anchor plates for rigging with single stud-fittings and additional anchor plate attachment points on the bottom. For permanent suspension or attaching brackets, the ZX5-90 also provides two M8 inserts on the top and bottom, two under the handle, and four on the back of the enclosure, totaling 10.

Experience the power and versatility of the Electro-Voice ZX5-90 600W 15" 2-Way White Full-Range Loudspeaker, a perfect blend of performance, durability, and style.

Electro-Voice Zx5-90 Features

  • DVX3150 15" LF Transducer with Forced Air Cooling
  • ND2 2" Voice Coil, 1" Exit Neodymium Compression Driver
  • 90deg. x 50deg. Coverage Pattern
  • 600W Continuous (2400W) Power Handling
  • High Sensitivity, 132 dB Maximum SPL
  • Adjustable Monitor Angle (45deg. or 55deg.)
  • 3 Anchor Plates for Single Stud Fittings and 10 Integral Suspension Points
  • Passive/Biamp Selectable

Warranty Information

This product has a limited warranty of 60 months.

Key Features

  • Experience powerful, full-range sound with this 600W Electro-Voice PA loudspeaker.
  • Achieve optimal audio clarity with a frequency response of 58 Hz - 18 kHz for live sound.
  • This durable PA speaker is built with a robust polypropylene enclosure for lasting use.
  • Enjoy flexible setup options with multiple suspension points on this reliable loudspeaker.
  • Get wide sound coverage with 90x50 degree dispersion, perfect for venues and events.
  • Connect easily using Neutrik Speakon connectors, ensuring a secure and high-quality signal.

What's in the box:

  • Electro-Voice Zx5-90 600W 15 " 2-Way Full-Range Loudspeaker
  • 3x Anchor Plates
  • 10x M8 Metric Suspension Insert Points
  • Electro-Voice 5 Year Limited Warranty
