Gefen 1:4 Splitter Specifications

  • Compatibility

    HDMI with Ultra HD 4Kx2K Support

  • Audio Switch

    2-Position slide-type

  • DC Power Connector

    Locking type

  • EDID Switch

    2-Position slide-type

  • FST Switch

    2- Position slide-type

  • HDMI Input Connector

    Type A 19-pin female, Locking

  • HDMI Output Connectors

    4x Type A 19-pin female, Locking

  • Maximum Pixel Clock

    300MHz

  • Operating Temperature

    32 to 104 deg. F / 0 to 40 deg. C

  • Power Consumption

    10W (max.)

  • Power Indicator

    LED, Blue

  • Power Supply

    5V DC

  • USB Port

    Mini-B

  • Dimensions (W x H x D)

    3 x 9 x 1" / 7.62 x 22.86 x 2.54cm

  • UPC Code

    845344024028

About Gefen 1:4 Splitter

Hi-Def input to four Hi-Def outputs using HDMI with Ultra HD resolution
The GefenToolBox 1:4 Splitter for HDMI 4K x 2K distributes one Ultra Hi-Def A/V source to four Ultra HD displays simultaneously, without loss of quality or resolution. This product works with any Ultra Hi-Def source and supports resolutions up to 4K x 2K (3840x2160 at 30Hz). It features Fast Switching Technology and supports HDCP, Deep Color, 3DTV pass-through and lossless audio formats such as Dolby TrueHD and DTS-HD Master Audio.

FST
Fast Switching Technology (FST) is a Gefen software implementation for HDMI products. FST eliminates the lengthy HDMI authentication process and allows connecting/disconnecting or turning ON / OFF of HDTV displays without having these activities affect other displays in the same distribution system.

How It Works
Using the supplied HDMI cable, connect the Ultra Hi-Def source to the HDMI input on the 1:4 splitter. Connect up to four Ultra HD displays to the HDMI outputs. Connect the included locking power supply to the 1:4 Splitter and to an available electrical outlet. Apply power to the source and displays. The HD source signal will now be seen on all of the connected displays simultaneously.

Features
• Simultaneously displays an Ultra Hi-Def source on up to four Ultra HD displays
• Supports resolutions up to Ultra HD 4K x 2K (3840 x 2160 at 30Hz) and 1080p Full HD
• Supports 12-bit Deep Color
• 3DTV pass-through
• Lip Sync pass-through
• FST Technology speeds up HDCP authentication process
• Fast and Slow FST Modes
• Advanced EDID Management for rapid integration of source and displays
• Supports LPCM 7.1, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio
• Supports the use of DVI sources and DVI displays with HDMI-to-DVI adapters (not included)
• Field-upgradeable firmware using Mini-USB port
• Locking Power Supply
• Surface-mountable

What's in the box:

  • Gefen 1:4 Splitter
  • CAB-HD-LCK-06MM 6' Locking HDMI Cable
  • EXT-PS526AIP-LP 5V DC Power Supply
  • QSG-GTB-HD4K2K-144 Quick-Start Guide
  • Gefen 2 Year Limited Warranty
