Lewitt LCT 340 Reference Class Condenser Microphone with Cardioid Capsule, 20-20000Hz

SKU: LEAMSLC340CO

This item is no longer available.

Overview
Compare
Accessories
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Lewitt LCT 340 Co Specifications

  • Acoustical operating principle

    Pressure & pressure gradient
    transducers, externally polarized

  • Transducer

    20.32mm / 0.80"

  • Directional pattern

    cardioid

  • Frequency range

    20 to 20000Hz

  • Sensitivity

    9 mV / Pa (-41 dBV), cardioid
    8 mV / Pa (-42 dBV), omni

  • Signal / noise ratio

    79 dB-A

  • Equivalent noise level

    15 dB-A, cardioid (IEC 61672-1)
    16 dB-A, omni (IEC 61672-1)

  • Dynamic range of mic

    124 dB-A

  • Max. SPL for 0,5 % THD

    139 dB, 0 dB pre-attenuation
    145 dB, 6 dB pre-attenuation
    151 dB, 12 dB pre-attenuation
    157 dB, 18 dB pre-attenuation

  • Pre-attenuation pad

    6 dB, 12 dB, 18 dB, switchable

  • Bass cut filter slope

    12 dB / octave at 40Hz
    6 dB / octave at 150Hz
    6 dB / octave at 300Hz

  • Rated impedance

    < 150 ohms

  • Rated load impedance

    > 1000 ohms

  • Supply voltage

    48 V + / - 4 V (IEC 61938)

  • Current consumption

    6,6 mA (IEC 61938)

  • Connector

    Gold plated 3-pin XLR

  • Top applications

    Overhead miking: Drums, percussion
    Ensembles: Choral or orchestral
    Acoustic instruments: Piano, guitar, drums, percussion, strings
    Wind instruments: Brass and woodwinds
    Demanding live and studio applications

  • Dimensions (Dia. x L)

    24 x 160mm / 0.94 x 6.30"

  • Weight

    200g / 7.05oz

  • UPC Code

    847986000033

11 Accessories for Lewitt LCT 340 Reference Class Condenser Microphone with Cardioid Capsule, 20-20000Hz

  • All Accessories (11)
  • Cables & Adapters (11)

About Lewitt LCT 340 Co

LEWITT's LCT 340 is a 0.8-inch externally polarized condenser microphone that excels at capturing acoustic and percussion instruments, drums and vocals and is perfectly suited for sophisticated live and studio applications. Two interchangeable capsules allow for quick and easy switching of patterns, ensuring greater flexibility without changing microphones.

The LCT 340 is equipped with four-position low-cut filter and pre-attenuation slide switches, dual-color LED indicators and a convenient snap closure. It offers a dynamic range of 124 dB and stands out for its extremely low self-noise of 15 dB. Last but not least, its transformerless output makes this ruggedly designed pro-mic resistant to electrical interference and a first-class pick for true sound enthusiasts.

Lewitt LCT 340 Co Features

  • 0.8-inch small-diaphragm capsule with ultra-thin externally biased, gold-layered low mass diaphragm for ultra-precise and neutral sound reproduction
  • Flat frequency response for natural, authentic sound
  • Interchangeable capsules for cardioid and omnidirectional pattern selection ensuring maximum flexibility and an undisturbed workflow
  • Wide dynamic range of 124 dB and low self-noise level of 15 dB for ear-catching realism and distortion-free sonic depth
  • 4-position switchable pre-attenuation pad (0 dB, 6 dB, 12 dB and 18 dB) for handling extremely high sound pressure levels and 4-position high-pass filter
  • Illuminated user interface for quick and easy handling even in dark environments
  • Rugged black die-cast full-metal body ensures long life
  • Hexagonal ruthenium-galvanized steel mesh grille to prevent wear and abuse
  • Immune to electromagnetic interference thanks to transformer less preamplifier circuitry
  • Corrosion-resistant gold-plated 3-pin XLR output connector

Key Features

  • Flat frequency response for natural, authentic sound
  • Rugged black die-cast full-metal body ensures long life
  • Hexagonal ruthenium-galvanized steel mesh grille to prevent wear and abuse
  • Corrosion-resistant gold-plated 3-pin XLR output connector

What's in the box:

  • Lewitt LCT 340 Reference Class Condenser Microphone with Cardioid Capsule
  • DTP 40 Mts Shock Mount
  • LCT 40 Ws Windshield
  • DTP 40 Lb Leather Bag
  • Lewitt 2 Year Limited Warranty
