Lynx Technik AG yellobrik OET 1510 Ethernet to 1Gbit Multimode Fiber Transceiver Switch with Duplex LC Fiber Connectors, Extends Up to 10km Over Single Mode Fiber, 850nm Transmitter Wavelength
SKU: LTOET1510MM
This item is no longer available.
Recommended Alternatives
Share:
Overview
Compare
Specs
Protection
About Lynx Technik AG OET 1510 MM
The OET 1510 is a compact 3 port Ethernet switch, designed to extend the reach of electrical Ethernet signals over long distances using a constant (fixed) high speed 1 Gbit optical transceiver speed. When paired with another OET 1510 at the receiving end (using two fiber links) you have a cost effective Ethernet extender system for distances up to 10km providing a stable, high speed 1Gbit error free optical connection between locations.
The OET 1510 has two standard RJ45 electrical Ethernet ports plus fiber I/O and functions as a 3 port Ethernet switch. For legacy system use; each electrical Ethernet port can be set for automatic speed detection (10/100/1000) or forced to 10Mbit and each port can use auto crossover detection or be forced manually if needed. These functions are available using the dip switch.
Lynx Technik AG OET 1510 MM Features
- Supports standard Ethernet inputs up to 1 Gbit
- 3 port Ethernet switch (1 fiber, 2 electrical)
- Auto (10/100/1000) electrical port speed detection
- Manually force 10Mbit electrical speed (if needed)
- Fiber transceiver speed always 1 Gbit
- Auto or manual electrical crossover selection
- Singlemode fiber 1310nm up to 10km (6.2 miles)
- Multimode fiber 850nm up to 550m (1,804 feet)
- Duplex LC optical connections
- Supports hot swapping and hot plugging
