Review Summary
Black, White
SGCC steel, clear tempered glass (white), tinted tempered glass (black)
Mid-tower
E-ATX (Up to 277mm), ATX, Micro-ATX, Mini-ITX
Yes (ATX) (BTF, Project Zero)
China
165mm
Up to 459mm (with <56mm thickness fans installed at the front-right)
Up to 410 mm (with 56 mm thick 420 mm AIO and fans installed at the front-right)
200mm
Up to 80mm (360mm)
Up to 62mm (420mm)
2x
1x
1x
7
0
4+2
2
3x 120mm / 3x 140mm (1 x F420 RGB Core included)
3x 120mm / 3x 140mm
3x 120mm / 3x 140mm (1 x F420 RGB Core included)
1x 120mm (1 x F120 RGB (CV) included)
Up to 420mm
Up to 420mm
Up to 360mm
Up to 120mm
F420 RGB Core
F120 RGB Core (CV)
F420 RGB Core: 2,000 +/- 200 RPM
F120 RGB Core (CV): 1,300 +/- 130 RPM
F420 RGB Core: 98.61 CFM
F120 RGB Core (CV): 55.17 CFM
F420 RGB Core: 3.2 mmH2O
F120 RGB Core (CV): 1.27 mmH2O
F420 RGB Core: 34.5 dBA
F120 RGB Core (CV): 26.1 dBA
F420 RGB Core: 8-pin
F120 RGB Core (CV): 3-pin
3x NZXT 8-pin (PWM only)
1x NZXT 8-pin (DC+PWM control)
1x 4-pin PWM (DC+PWM control)
4x NZXT 8-pin
1x NZXT RGB
Each NZXT 8-pin channel supports a maximum of 96 LEDs. NZXT RGB channel supports up to 40 LEDs and up to NZXT 5 devices
USB 2.0 Internal Header 8-pin PCIe Power
4680.52 cu. in (76.7L)
19.9 x 12.4 x 18.9" (506 x 315 x 481mm)
29.54 lbs (13.4kg)
Black: 810074847896 | White: 810074847889
The H9 Flow is a spacious mid-tower ATX case built for high-performance builds, balancing airflow and aesthetics. Its dual-chamber design improves cooling and cable management, while perforated panels, angled fans, and ample fan and radiator support deliver optimal thermal performance.
Dual-Chamber Design
Separates main components from the PSU and drives for improved thermal performance and cable management.
Optimized Airflow
Perforated steel panels and angled front-right fans ensure efficient cooling for high-performance builds.
RGB Ready
Includes two F420 RGB Core single-frame fans, one F120 RGB Core (CV) fan in the rear, and an NZXT Control Hub. CV = Case Version (3-pin DC)
Ten-Fan Capacity
Supports up to nine 140mm fans across the top, front-right, and bottom, plus one 120mm fan in the rear.
Panoramic View
Showcase every detail of your build with seamless, wraparound tempered glass paneling.
Large Radiators & GPUs
Fits up to a 420mm radiator on the top and front-right, with plenty of clearance for high-end graphics cards.
Easy Cable Management
Extra-wide channels, built-in Self-Securing Closure straps, and tie-down points make cable routing effortless.
Back-Connect Ready
Compatible with rear-connecting motherboards like ASUS BTF and MSI Project Zero for a cable-free look.
Built to Flow. Made to Show
The H9 Flow is a spacious, dual-chamber case built for high-performance builds, featuring extensive cooling support and wraparound glass panels for an uninterrupted view of your build.
