Orion Images Premium Series 15RTC 15" 720p CCTV LCD Monitor
See all Orion Images items

Orion Images Premium Series 15RTC 15" 720p CCTV LCD Monitor, 1024x768

SKU: OR15RTC

This item is no longer available.

Overview
Compare
Specs
Q&A

Questions & Answers

Reviews about this item

Review Summary

Orion Images 15RTC Specifications

  • Screen Size

    15"

  • Max. Resolution

    1024 x 768 at 75Hz

  • Pixel Pitch

    0.29 x 0.29mm

  • Brightness

    250cd/square meter

  • Contrast Ratio

    500 : 1

  • Aspect Ratio

    4 : 3

  • Viewing Angle (H/V)

    150 / 130 deg.

  • Display Color

    16.2 Million

  • Response Time

    < 8ms

  • Video System

    NTSC / PAL

  • Frequency (H)

    31 - 48 KHz(H)

  • Frequency (V)

    55 - 75 KHz(V)

  • Video In / Out (BNC Type)

    2 / 2

  • S-Video In / Out

    1

  • HDMI In

    1

  • VGA In (15Pin D-Sub)

    1

  • Audio In (RCA Type)

    1

  • PC Stereo In

    1

  • Remote Control

    Yes

  • Built-in Speakers

    Yes (1W x 2)

  • Filter Type

    3D Comb Filter

  • LCD Protection Glass

    Option

  • Deinterlace

    Yes

  • Noise Reduction

    Yes

  • Auto Source Sequencing

    Yes

  • Multi Language

    English, Spanish, French, German, Italian

  • Material

    Electronic galvanized iron

  • Desktop Stand

    Tilt Back

  • Power Consumption: < On

    < 22W

  • Electrical Ratings

    AC100 - 240V (50/60Hz)

  • Operating Temperature

    0 to 40 deg. C / 32 to 104 deg. F

  • Storage Temperature

    -20 to 60 deg. C / -4 to 140 deg. F

  • VESA Mount Size

    100 x 100mm

  • Wall Mount

    WB-5, WB-10, WB-30, WB-31

  • Ceiling Mount

    CMK-01

  • Rack

    RMK-08

  • Dimensions

    13.66 x 11.65 x 3.19" / 34.70 x 29.59 x 8.10cm

  • Weight

    10.1lbs / 4.58kg

  • UPC Code

    836228001150

About Orion Images 15RTC

ORION Images is a true manufacturer of LCD CCTV monitors. The ORION Images monitors are true Commercial Grade with FCC Class A Certification - Built to Run 24 x 7 x 365 continuously. Their monitors are designed, engineered and manufactured with CCTV PCB boards and circuitry making these the LCD solution for your security surveillance.

The ORION Images 15 inch Premium Grade 15RTC LCD CCTV monitors are designed with a Metal Cabinet, 3D Comb Filter, Noise Reduction, LCD Protection Glass and a Tilt Back stand providing this series the versatility you need to support your security surveillance and industrial applications.

Orion Images 15RTC Features

  • Premium Grade 15 Inch LCD Monitor
  • Optional LCD Protection Glass, Metal Cabinet
  • 1024 x 768 at 75Hz Resolution, 250 Nits, 500:1 Contrast
  • BNC Video 2 In / 2 Out, HDMI 1 In, S-Video In 1, VGA In 1, Audio In 1, PC Stereo 1 In
  • 3D Comb Filter / Deinterlace / Noise Reduction
  • 1W x 2 Built-In Speakers
  • Mount Options: Wall, Ceiling or Rack

Join VIP PRO

2 Day Delivery on thousands of items!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Premium Grade 15 Inch LCD Monitor
  • 1W x 2 Built-In Speakers

What's in the box:

  • Orion Images Premium Series 15RTC 15" 720p CCTV LCD Monitor
  • User Manual
  • Power Adapter
  • Power Cord
  • VGA Cable
  • Remote Control with Batteries
  • Orion Images 3 Year Parts and Labor Warranty
