ProX XC-5PDMX5 5' 5-Pin DMX XLR5-M to XLR5-F High Performance Cable
See all ProX items
33% Off

ProX XC-5PDMX5 5' 5-Pin DMX XLR5-M to XLR5-F High Performance Cable

SKU: PRXXC5PDMX5 MFR: XC-5PDMX5
Be the first to review this itemAsk a Question
$7.90
$11.85
Save: $3.95 (33%)
Earn VIP Reward Points

Key Features

  • ProX 5-Pin DMX cable ensures reliable data transmission for lighting effects.
  • Get superior sound quality with this 5-foot XLR cable, perfect for DJ setups.
  • This durable DMX lighting cable is designed for stage and studio environments.
  • Enjoy optimal performance with our high-quality XLR5 cable at an affordable price.
  • Connect your lighting consoles and DMX devices with this ProX DMX cable.
  • Experience peace of mind with our lifetime limited warranty on this ProX cable.
See More Product Details
Temporarily On Backorder?Expected Availability: 10/2025Request assistance or get notified
Calculate Shipping

See Options

1
Add to ListGet Sale Alert

Need help? Ask our experts.

Overview
Compare
Specs
Q&A

Questions & Answers

Reviews about this item

Review Summary

ProX XC-5PDMX5 Specifications

  • Characteristic Impedance

    Nominal: 110 Ohms

  • Capacitance Conductor to Conductor

    Nominal: 12.8 pF/ft @ 1KHz

  • Cap Cond. to Other Cond. & Shield

    Nominal: 23 pF/ft @ 1KHz

  • Velocity of Propagation

    Nominal: 66%

  • Delay

    Nominal: 1.6 Nanoseconds per foot

  • Conductor DC Resistance

    Nominal: 24 Ohms/1000' @ 68 Degrees F (20 Degrees C)

  • Outer Shield DC Resistance

    Nominal: 3.4 Ohms/ 1000' @ 68 Degrees F (20 Degrees C)

  • Attenuation (dB/100')

    Nominal: 0.6 (@ 1 MH z) dB/100'

  • Maximum Recommended Current

    2.1 Amps per conductor @ 77 Degrees F (25 Degrees C)

  • Operating Temperature Range

    -86 Degrees F to + 167 F Degrees (-30 Degrees C to + 75 Degrees C)

  • Fits

    XLR5-M to XLR5-F

  • Length Cable

    5' (1.52m)

  • UPC Code

    741459148737

Models
ProX XC-5PDMX5 5' 5-Pin DMX XLR5-M to XLR5-F High Performance Cable

ProX XC-5PDMX5 5' 5-Pin DMX XLR5-M to XLR5-F High Performance Cable

SKU: PRXXC5PDMX5

MFR: XC-5PDMX5

$7.90

$11.85

Save:$3.95 (33%)

Temporarily On Backorder

Although this item is temporarily on Backorder, you can order it now and it will ship as soon as it arrives. Your card will only be charged once item is shipped.

ProX XC-DMX5 5' 3-Pin DMX XLR5-M to XLR3-F High Performance Cable Adapter

ProX XC-DMX5 5' 3-Pin DMX XLR5-M to XLR3-F High Performance Cable Adapter

SKU: PRXXCDMX5

MFR: XC-DMX5

$7.90

$11.85

Save:$3.95 (33%)

Temporarily On Backorder

Although this item is temporarily on Backorder, you can order it now and it will ship as soon as it arrives. Your card will only be charged once item is shipped.

ProX XC-DMX3 3' 3-Pin DMX XLR3-M to XLR5-F High Performance Cable Adapter

ProX XC-DMX3 3' 3-Pin DMX XLR3-M to XLR5-F High Performance Cable Adapter

SKU: PRXXCDMX3

MFR: XC-DMX3

$7.30

$10.95

Save:$3.65 (33%)

Temporarily On Backorder

Although this item is temporarily on Backorder, you can order it now and it will ship as soon as it arrives. Your card will only be charged once item is shipped.

Accessory TypeCableCableCable

About ProX XC-5PDMX5

The ProX XC-5PDMX5 cable is ideal for DMX connection applications where a device with a male DMX XLR-5 output/input needs to be connected to a device with a female DMX XLR-5 output/input. 22AWG Oxygen-Free Copper (OFC) conductors for maximum signal transfer.

We know cables are not just cables, they are what protects your signal from being altered. Uncompromised signal power, with precise data transmission, is paramount for quality DMX control operations. Our DuoFoil and braided OFC Copper Compact shield blocks noise and protects data transfer.

Bending &Twisting, are no match for our high-performance tour-grade DMX cables. They're designed to provide years of dependable service and outlast every other cable on the market! Complete Coil technology demands consistent weave tolerances to create precise and accurate data transmission. This is the most important part of the design and greatly affects performance.

Note
Twisted pair DMX data transmission cables are not suitable for audio use. Conversely, audio cables are not suitable for DMX data use. Their specifications and characteristics differ substantially. Always use the correct cable for reliable connections!

ProX XC-5PDMX5 Features

  • Polyethylene insulation
  • Dual Twisted Pair Data Cable (4 Conductors)
  • Polyethylene inner jacket
  • Duofoil (100% coverage)
  • Cotton plus a tinned copper braid shield (85% coverage)
  • PVC jacket for durability
  • Gold Plated Contacts
  • ProX Branded, All Metal XLR-5 Connectors
  • Excellent Durability and Superior Data Transfer
  • 20 AWG x 4 Oxygen-Free Copper (OFC) conductors
  • Extra Durable & Flexible Long Life Construction

Warranty Information

This product has a limited lifetime warranty.

Join VIP PRO

2 Day Delivery on thousands of items!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • ProX 5-Pin DMX cable ensures reliable data transmission for lighting effects.
  • Get superior sound quality with this 5-foot XLR cable, perfect for DJ setups.
  • This durable DMX lighting cable is designed for stage and studio environments.
  • Enjoy optimal performance with our high-quality XLR5 cable at an affordable price.
  • Connect your lighting consoles and DMX devices with this ProX DMX cable.
  • Experience peace of mind with our lifetime limited warranty on this ProX cable.

What's in the box:

  • XC-5PDMX5 5' 5-Pin DMX XLR5-M to XLR5-F High Performance Cable
  • ProX Lifetime Limited Warranty
