Prism Sound ADA-8XR Audio Interface with 8-Channel 8C-AD Input Module, 8C-DA Output Module, 8C-AES and 8C-FW FireWire I/O Module

SKU: PSAD8XRFWAES MFR: ADA-8XR-FW-AES
Earn VIP Reward Points

Key Features

  • Experience pristine audio quality with this Prism Sound audio interface for professional recordings.
  • Achieve ultra-low latency for seamless tracking and mixing with the FireWire I/O module.
  • Utilize 8 channels of analog I/O for complex studio setups, ensuring versatile connectivity.
  • Enjoy stable driver performance on both macOS and Windows for uninterrupted workflow.
  • Capture every nuance with up to 192 kHz/24-bit resolution, perfect for high-definition audio.
  • Integrate easily with AES3 digital I/O, expanding your connectivity options for any project.
See More Product Details
Special Order?Estimated to Ship: 08/08/2025
Free Shipping

See Options

Qty
1

Need help? Ask our experts.

Overview
Compare
Specs
Q&A

Questions & Answers

Reviews about this item

Review Summary

Prism Sound ADA-8XR Specifications

ADA-8XR Audio Interface

ADA-8XR Audio Interface

Jump to...
  • Form Factor

    Rackmount

  • Channels of I/O

    None

  • Max Sample Rate/Resolution

    192 kHz / 24-Bit

  • Number of Mic Preamps

    None

  • Expansion Slots

    2x Analog I/O Slot
    2x Digital I/O Slot
    1x Utility Slot
    1x Internal DSP Slot

  • Analog Audio I/O

    1x Stereo RCA Balanced Output
    1x 1/4" TRS Headphone Output

  • Digital Audio I/O

    1x BNC Coaxial AES-3id / S/PDIF Output

  • Sync I/O

    1x BNC Video Sync/Word Clock Input
    1x BNC Word Clock Output
    1x XLR 3-Pin AES11 Input
    1x XLR 3-Pin AES11 Output

  • MIDI I/O

    None

  • Other I/O

    1x DE-9/DB-9 RS-232/RS-485 In/Out

  • Impedance

    RCA Outputs: 50 Ohms
    1/4" Outputs: 115 Ohms
    XLR Outputs: 110 Ohms
    BNC Sync Outputs: 75 Ohms
    XLR Mic Inputs: 110 Ohms
    BNC Sync Inputs: 75 Ohms

  • Dynamic Range

    RCA Outputs: 105 dB (-60 dBFS, 1 kHz)

  • THD+N

    RCA Outputs: -101 dB / 0.0009% (1 kHz, at -1 dBFS)

  • Channel Separation

    RCA Outputs: > 120 dB (1 kHz)

  • dBFS Reference Level

    +15 / +18 / +21 / +24 dBu = 0 dBFS (Selectable)

  • Sample Rates

    Up to 192 kHz

  • Bit Depths

    Up to 24-Bit

  • Clocking

    Accuracy: +/-25 ppm
    Jitter Suppression: > 60 dB (above 700 Hz)

  • OS Compatibility

    macOS
    Windows

  • AC Input Power

    90 to 125 VAC, 50 / 60 Hz
    180 to 250 VAC, 50 / 60 Hz

  • Power Consumption

    60W

  • Rackmount Size

    2 RU

  • Dimensions

    19 x 15.4 x 3.5" (483 x 390 x 88mm)

  • Weight

    16.5 lbs (7.5kg)

8C-AD 8-Channel Input Module

Jump to...
  • Inputs

    8x XLR 3-pin female (balanced)

  • Input Impedance

    21.005 kOhms

  • Input Range

    +5 to +24 dBu

  • Gain Accuracy

    +/-0.05 dB

  • CMRR

    60 Hz: < -100 dB
    1 kHz: < -90 dB
    20 Hz to 20 kHz: < -65 dB

  • Limiter

    Software selectable on/off

  • THD + N

    -105 dB (0.0006%) at 997 Hz, -1 dBFS

  • Dynamic Range

    112 dB at 997 Hz, -60 dBFS

  • Intermodulation Distortion (SMPTE)

    < -100 dB (60 Hz at -3 dBFS, 7 kHz at -12 dBFS)

  • Spurious

    Maximum Aharmonic Spurium: < -130 dBFS (997 Hz at -1 dBFS)

  • Frequency Response

    44.1 kHz: 5 Hz to 20.1 kHz (-0.05 dB), <1 Hz to 22 kHz (-3 dB)
    48 kHz: 5.5 Hz to 22.8 kHz (-0.05 dB), <1 Hz to 24 kHz (-3 dB)
    96 kHz: 6.1 Hz to 43.3 kHz (-0.05 dB), <1 Hz to 48 kHz (-3 dB)
    192 kHz: 6.2 Hz to 50.2 kHz (-0.05 dB), <1 Hz to 77.7 kHz (-3 dB)

  • Passband Ripple

    48/96 kHz: <0.015 dB

  • Inter-Channel Differential Phase

    <0.03 Degree

  • Channel Separation

    1 kHz: >125 dB
    20 Hz to 20 kHz: >117 dB

  • Latency

    44.1 kHz: 20 samples / 0.45 ms
    48 kHz: 20 samples / 0.42 ms
    96 kHz: 20 samples / 0.21 ms
    192 kHz: 20 samples / 0.10 ms

  • Dimensions

    7.9 x 7.1 x 1.2" (20 x 18 x 3cm)

  • Weight

    11.2 oz (317.5g)

8C-DA 8-Channel Output Module

Jump to...
  • Outputs

    8x XLR 3-pin male (balanced)

  • Output Impedance

    50 Ohms

  • Input Range

    +5 to +24 dBu in 1 dBu steps, trims in 0.05 dBu steps

  • Gain Accuracy

    +/-0.05 dB

  • Balance

    Output Balance: 54 dB

  • THD + N

    -102 dB (0.0007%) at 997 Hz, -1 dBFS

  • Dynamic Range

    108 dB at 997 Hz, -60 dBFS

  • Intermodulation Distortion (SMPTE)

    < -94 dB (60 Hz at -3 dBFS, 7 kHz at -12 dBFS)

  • Spurious

    Maximum Aharmonic Spurium: < -130 dBFS (997 Hz at -1 dBFS)

  • Frequency Response

    44.1 kHz: 5 Hz to 20.8 kHz (-0.05 dB), 1.4 Hz to 22 kHz (-3 dB)
    48 kHz: 5.1 Hz to 22.6 kHz (-0.05 dB), 1.4 Hz to 23.9 kHz (-3 dB)
    96 kHz: 5.1 Hz to 38.9 kHz (-0.05 dB), 1.4 Hz to 47.4 kHz (-3 dB)
    192 kHz: 5.2 Hz to 37.2 kHz (-0.05 dB), 1.4 Hz to 74.4 kHz (-3 dB)

  • Passband Ripple

    <0.005 dB

  • Inter-Channel Differential Phase

    <0.02 Degree

  • Channel Separation

    1 kHz: >115 dB
    20 Hz to 20 kHz: >110 dB

  • Latency

    44.1 kHz: 49.5 samples / 1.12 ms
    48 kHz: 49.5 samples / 1.03 ms
    96 kHz: 49.5 samples / 0.52 ms
    192 kHz: 49.5 samples / 0.26 ms

  • Dimensions

    7.9 x 7.1 x 1.2" (20 x 18 x 3cm)

  • Weight

    11.2 oz (317.5g)

8C-AES 8-Channel AES3 Digital I/O Module

Jump to...
  • I/O Connections

    1x DB25 female (transformer coupled)

  • Impedance

    AES3 Mode: 110 Ohms
    S/PDIF Mode: 75 Ohms

  • Output Signal Amplitude

    AES Mode: 3.2 V p-p (loaded)
    S/PDIF Mode: 0.5 V p-p (loaded)

  • Sample Rates

    Up to 192 kHz
    One-wire or two-wire (Split96) input and output modes are supported at 88.2 kHz, 96 kHz, 176.4 kHz, and 192 kHz

  • Bit Depth

    16-bit, 20-bit, 24-bit

  • Channel Support

    Consumer (S/PDIF) or professional (AES3)

  • Jitter Tolerance

    Below 200 Hz: 15 UI p-p
    Above 8 kHz: 0.5 UI p-p x1 (UI = 163 ns at 48 kHz)

  • Latency

    44.1 kHz: 34 samples / 0.77 ms
    48 kHz: 34 samples / 0.71 ms
    96 kHz: 34 samples / 0.35 ms
    192 kHz: 34 samples / 0.18 ms

  • Dimensions

    4.3 x 6.7 x 1.6" (11 x 17 x 4cm)

  • Weight

    3.2 oz (90.7kg)

8C-FW 8-Channel FireWire I/O Module

Jump to...
  • Form Factor

    Internal

  • Channels of I/O

    8 Input / 8 Output at 48/96 kHz
    4 Input / 4 Output at 176.4/192 kHz

  • Max Sample Rate/Resolution

    192 kHz / 24-Bit

  • Number of Mic Preamps

    None

  • Analog Audio I/O

    None

  • Digital Audio I/O

    None

  • Host Connection / USB

    2x FireWire 6-Pin (FireWire 400)

  • MIDI I/O

    None

  • Sample Rates

    Up to 192 kHz

  • OS Compatibility

    macOS 10.3.7 or Later
    Windows XP or Later

  • Processor Requirement

    Mac: 700 MHz PowerPC G4
    PC:900 MHz Intel Pentium

  • RAM Requirements

    256 MB

  • Minimum Display Resolution

    800 x 600

  • Required Hardware

    Available FireWire 400 Port

  • Dimensions

    4.3 x 6.7 x 1.6" (11 x 17 x 4cm)

  • Weight

    3.2 oz (90.7kg)

  • UPC Code

    669014270733

About Prism Sound ADA-8XR

Become a part of the audio revolution with the ADA-8XR Audio Interface, a legendary modular AD/DA converter that has been the cornerstone of audio performance for over two decades. This British-engineered converter has been utilized in high-profile projects including Star Wars and Lord of the Rings, and is a staple in world-renowned recording facilities such as Metropolis and British Grove.

The ADA-8XR Audio Interface offers unparalleled accuracy with its ultra-detailed A/D and D/A conversion. This ensures a complete focus on sound, allowing every nuance of a performance to be heard without any distracting coloration. Its modular design offers the flexibility of an 8 input/8 output, 16 input, or 16 output converter, complete with digital I/O cards for AES and FireWire.

This audio interface is not just a converter, but also a master clock for your entire system. It provides rock-solid stability and jitter rejection for crystal clear imaging. Its multi-sample rate compatibility allows for different sample rates to be sent and received simultaneously.

The ADA-8XR is a modular system, providing great flexibility when creating systems with larger numbers of channels. It's the ideal choice for high-quality conversion, whether you need just a few channels or a large multi-track setup. With the range of digital interfaces, you can build the system that perfectly matches your requirements.

This audio interface is the industry's converter of choice in the most exacting applications in music and sound recording, mastering, broadcast, and post-production. It's perfect for recording vocals, single instruments, drums, or an orchestra, and is just as much at home providing multiple outputs for external analogue summing.

The ADA-8XR takes the philosophy of the widely-acclaimed Prism Sound converter range a stage further. It provides A/D and D/A conversion and the essential digital interfaces with a stereo monitor mix output in digital and analogue formats. Unlike most other converter systems, the ADA-8XR is ideal as a master clock for your entire system, delivering your recordings with perfect transparency, whatever the setup.

The package includes the 8C-AD 8-Channel Analogue Line Input Module, the 8C-DA 8-Channel Analogue Line Output Module, the 8C-AES 8-Channel AES3 Digital I/O Module with AES Breakout Loom, and the 8C-FW 8-Channel FireWire I/O Module for ADA-8XR Audio Interface. Each module is designed to provide the highest quality audio conversion, ensuring that your recordings are as clear and accurate as possible.

In conclusion, the ADA-8XR Audio Interface is a versatile, high-quality audio converter that offers unparalleled sound quality and performance. It's the perfect tool for producers, engineers, and songwriters who want to produce the best results in recording, tracking & overdubbing, mixing to stereo or surround, mastering, and monitoring.

Prism Sound ADA-8XR Features

  • Modular Design for Flexible I/O Setups
  • Up to 24-Bit / 192 kHz Resolution
  • Versatile Clocking and Routing Options
  • Selectable Input Limiters

Product Documents

User Manual

Key Features

  • Experience pristine audio quality with this Prism Sound audio interface for professional recordings.
  • Achieve ultra-low latency for seamless tracking and mixing with the FireWire I/O module.
  • Utilize 8 channels of analog I/O for complex studio setups, ensuring versatile connectivity.
  • Enjoy stable driver performance on both macOS and Windows for uninterrupted workflow.
  • Capture every nuance with up to 192 kHz/24-bit resolution, perfect for high-definition audio.
  • Integrate easily with AES3 digital I/O, expanding your connectivity options for any project.

What's in the box:

  • Prism Sound ADA-8XR Audio Interface
  • 8C-AD 8-Channel Analogue to Digital Line Input Module
  • 8C-DA 8-Channel Digital to Analogue Line Output Module
  • 8C-AES 8-Channel AES3 Digital I/O Module with AES Breakout Loom
  • 8C-FW 8-Channel FireWire I/O Module
  • Power Cable
  • BNC to RCA Connector
  • 4.9' DB25 to XLR AES3 Breakout Cable
  • Prism Sound 3 Year Limited Warranty
