Quilter Labs MicroBlock 45 - 45W Compact Guitar Amplifier Pedal

SKU: QLMICROBL45

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Quilter Labs MicroBlock 45 Specifications

  • Inputs and Outputs

    Instrument Input: 1/4" (6.35mm) TS
    Line Input: 1/8" (3.5mm) TRS
    Line Output: 1/8" (3.5mm) TRS
    Speaker Output: 1/4" (6.35mm) TS

  • Input Impedances

    Line Input: 20kOhms
    Instrument Input: 1MOhms

  • Output Impedance

    Speaker: 4, 8, or 16Ohms

  • Speaker Power Handling

    8Ohms: 33W
    4Ohms: 45W

  • Power Supply

    24VDC, 3A

  • Dimensions

    2.3 x 4.3 x 1.2" (58.42 x 109.22 x 30.48mm)

  • UPC Code

    854710003666

About Quilter Labs MicroBlock 45

Pedal Sized Power Amp
Quilter's in-depth knowledge of tone and overdrive is now available in a compact pedal format with 33/45 watts of speaker power. Perfect for the player who doesn't need the mighty Tone Block's 200-watt output. Go ahead, plug in, turn it up and watch the jaws drop as a big helping of high energy Quilter mojo pours out of this little box! Clean or dirty, this efficient little workhorse keeps on rocking.

Intuitive Controls
Gain, Tri-Q, Master. The same three wide-range controls that made the Tone Block 200 famous are now available in pedal form. Gain goes from clean to soaring overdrive. Tri-Q goes from Blackface chime to roaring lead boost. And Master takes you from full output down to zero with no change in tone or overdrive. Perfect for practice or playing out.

Amazing Flexibility
As a complete miniature guitar amp, the MicroBlock 45 can fill a bedroom, living room or even a small club as a backup amp. In addition, the MicroBlock makes a great utility amp for driving headphones and a great general purpose playback amp using either the guitar or mini-jack input. It can even be used as a natural distortion pedal by using the headphone jack as a line output. It's the easiest way to see what the "Quilter thing" is all about.

Quilter Labs MicroBlock 45 Features

  • Comes with universal voltage 72-watt power supply
  • Quarter-inch high impedance input for maximum pickup response
  • Quarter inch speaker output drives 16, 8 and 4 ohm loads and is fully protected
  • Mini-jack input accepts stereo inputs, summing to mono
  • Mini-jack output drives headphones or line outputs

What's in the box:

  • Quilter Labs MicroBlock 45
  • 45W Compact Guitar Amplifier Pedal
  • Power Supply
  • Quilter Labs 1 Year Limited Warranty
