Sony Control Unit for BVM Series Monitors

SKU: SOBKM17R MFR: BKM 17R
Earn VIP Reward Points

Key Features

  • Enhance your BVM series monitor workflow with this Sony control unit for precise adjustments.
  • Enjoy seamless remote operation via LAN with the RJ-45 Ethernet port for efficient control.
  • Maintain optimal performance with a wide operating temperature range for diverse environments.
  • Ensure reliable connectivity with serial remote input, perfect for professional setups.
  • Experience durable performance with robust design, ideal for demanding broadcast applications.
  • Compact and lightweight at 4.63 lbs, this Sony control unit integrates easily into your setup.
See More Product Details
Special Order?Estimated to Ship: 08/21/2025
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$89.99

3 Year

$109.99

4 Year

$139.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Sony Control Unit Specifications

  • Compatibility

    BVM Series Monitors

  • Input: Serial Remote (LAN)

    RJ-45 (x1) (Ethernet, 10BASE-T/100BASE-TX)

  • DC Input

    DC jack (x1)

  • Option Output

    Serial Remote (LAN) RJ-45 (x1) (Ethernet, 10BASE-T/100BASE-TX)

  • Operating Temperature

    0 to 35deg. C (32 to 95 deg. F)
    32 to 95 deg. F (0 to 35 deg. C)

  • Operating Humidity

    0% to 90% (no condensation)

  • Storage/Transport Temperature

    -10 to 40 deg. C (14 to 104 deg. F)

  • Storage/Transport Humidity

    0% to 90%

  • Operating/Storage/Transport Pressure

    700 hPa to 1060 hPa

  • Dimensions

    424 x 58.8 x 169.6mm (16.69 x 2.31 x 6.68") (Approx.)

  • Weight

    2.1kg (4.63 lbs) (Approx.)

About Sony Control Unit

The 19" rack-mountable BKM-17R monitor control unit gives you control of the BVM-E251/E171 Series monitor. It can also control the BVM-X Series, BVM-E series, BVM-F series, BVM-L Series, PVM-L series and PVM-X550. A USB memory is used for storing captured data. One BKM-17R can control up to 32 BVM monitors.

Modular Monitor Control Unit
The control unit for the BVM-E251/E171 Series monitor. It also can control the BVM-X Series, BVM-E series, BVM-F series, BVM-L Series, PVM-L series and PVM-X Series. The Monitor Control Unit can be attached below the BVM-E251/E171 monitor using the optional Controller Attachment Stand (BKM-37H, BKM-38H or BKM-39H) or connected remotely via an Ethernet cable.

USB memory
A USB memory is used for storing a captured data, exchanging setting data of the monitor to another BVM-E251 or E171 monitor and updating them.

19-inch EIA standard rack-mountable
The rack mount brackets and screws are supplied.

Warranty Information

This product has a limited warranty of 12 months for parts and 3 months for labor.
