Search & Playback
• 1, 4, 8, 9, 13, 16 multi-camera display modes
• Synchronized multi-screen playback
• Full-function playback (play, rewind, fast-forward)
• Search filters for playback (date & time, camera, area, event, vision, POS/ATM and log file)
• Image enhancement (brightness, contrast, gray, high pass, edge enhancement)
• Playback with 15x image zoom/image enhancement
• Still image print capability
• External HDD supported (USB, Network, NAS)
• Live data backup to network drive (NAS)
• Offsite data archiving
• Still image save with image verification utility
• Multiple still image export
• MPEG, .AVI or Proprietary .DVR backup formats
• Simultaneous local, remote and archive video viewing
Remote Surveillance
• Client software (Windows 2000, XP and Vista)
• PDA software (Windows CE)
• Smartphone software (Sybian / Windows compatible)
• TCP/IP remote network
• Unlimited number of connections on web viewer, 1,000 DVRs can be connected on CMS
• Remote transmission (live view, playback, file copy, audio & event log)
• Remote control (Pan/Tilt/Zoom, auxiliary devices, alarm & mini center)
• Unlimited connection time
• User log with search filters for remote access
Sensors & Alarms
• 4 sensor inputs (dry contact N/C, N/O)
• 4 alarm outputs (relay contact 3A 120VAC or 3A 24VDC)
• RS-232 output
• Software selectable sensor input type
• Adjustable alarm hold time (1-3,600 sec)
• Full screen mode for sensored camera
• Motion detection, video loss, voice detection, sensor trigger, abnormal event, POS keyword and alarm message alarms
• Smart Alarm Functions include launching E-Map, full screen cameras, audible warning, email notification, phone call, FTP files, SMS/MMS messaging and PTZ camera
• LCD alarm indicator on front panel
• Sensor input indicator
Event Log & Search
Logs:
• Sensor event
• Recording start/stop
• Date & time change
• Password change
• Settings change
• System power on/off
• System power recovery
• HDD failure, reboot
• Remote access users
• Unlimited number of events stored
• Event search filter (date & time, event, operation, system, network, POS viewer)
• Sensor event playback
• Search filter for sensor event playback (date & time, camera)
• Full or multi-screen sensor event playback
Security & Maintenance
• Image file encryption
• Auto rebooting after power failure
• Auto recovery of system files
• Auto recovery of data files
• Hardware watchdog (initiates conditional reboot)
• Passwords
• System access
• Set-up access (administrator)
• Remote access
• True hybrid DVR provides IP camera support on most popular brands
• Selectable software compression (H.264, MPEG-4)
• Digital Deterrent ready
• Supports POS integration
• Windows Embedded XP operating system
• Storage starts at 500GB available up to 4TB DVD/RW standard
• 8 camera inputs and loopouts
• 8 audio inputs
• 8 channel video loop-through
• Two-way audio (standard)
• 1 Gbps Ethernet interface
• 720x480, 640x480, 352x240 image sizes
• 240 & 480 fps total recording frame rate, configurable to divide across 8 channels
• 240 & 480 fps total live view frame rate, configurable to divide across 8 channels
• Advanced programmable motion detection with video analytics
• Pan/Tilt/Zoom control
• Password protection
• Fully integrated one-button backup to DVD-RW
• System failure handling with UPS support (auto rebooting with file recovery)
• Auto-sensing, auto protection power supply (100approx.127/200approx.240 VAC)
• Pentium E2160 (1.8GHz) dual core processor
• 1GB RAM
• 1280x1024 monitor resolution
• NTSC/PAL support
• Remote control and rack ears included
Monitoring (Live View) & Recording
• E-Map feature allows local and remote camera, alarm input and output selection from actual multi-level maps
• Display modes:VGA, composite, DVI & S-Video outputs
• Standard analog TV output (programmable, sequential & multiplexed)
• Adjustable multi-screen switching (3 sec to 10 sec. intervals)
• Covert camera mode (recording without viewing)
• Image quality adjustment (adjustable for individual cameras)
• Record and alarm on motion detection
• Unlimited number of motion detection zones
• Programmable motion detection sensitivity
• Fully programmable scheduled recording (1-hour increments; daily, weekly, monthly, date or event)
• Sensor-based recording
• Motion alarm
• Camera input detection
• Camera image adjustment (brightness, contrast, chroma, hue)
• Daylight savings time adjustment (automatically synchronized)
• Estimated recording period (remaining disk space shown on GUI and built-in HDD calculator)
• HDD health monitor sends email, displays an OSD warning and sounds a local alarm if failure is detected
