Teradek Cube 775 HEVC/AVC SDI/HDMI Decoder with Dual-Band Wi-Fi
See all Teradek items

Teradek Cube 775 HEVC/AVC SDI/HDMI Decoder with Dual-Band Wi-Fi

SKU: TE100775

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Browse our FAQ

See Terms & Conditions

Teradek Cube 775 Specifications

Video

Video

Jump to...

  • Video Outputs

    HDMI 1.4a: Full Size
    SD/HD/3G-SDI (75Ohms BNC)

Supported Resolutions

Jump to...

  • Supported Resolutions

    1080p 23.98/24/25/29.97/30/50/59.94/60
    1080i 50/59.94/60
    1080PsF 23/24/25/29/30
    720p 50/59.94/60
    576i
    480i
    480p (for HDMI output only)
    576p (for HDMI output only)

Video Processing

Jump to...

  • Video Compression

    Decompresses HEVC (H.265), H.264, Baseline, Main and High Profile

  • Supported Video Bitrate

    250 Kbps to 15 Mbps
    15 Mbps (wired), 10 Mbps (Wi-Fi)

  • Test Pattern Generator Support

    No

  • Video Format Conversion Support

    Built in Video Scaler and Deinterlacer

  • Color Correction

    No

Protocol Support

Jump to...

  • Network Protocols

    TCP/IP, UDP, HTTP, DHCP, NTP, SSL, IGMP

  • Supported Video Transport Protocols

    RTP/RTSP: Unicast/TCP, Unicast/UDP, Multicast/UDP streams
    MPEG Transport Stream: Unicast/TCP (pushed in from an external source, or pulled down from a remote server such as Core), Unicast/UDP, Multicast/UDP
    Teradek Streaming : Unicast/UDP, Multicast/UDP

  • Remote Control

    Teradek Core

Audio Processing

Jump to...

  • Audio Compression

    AAC-LC, MPEG Layer 2

Inputs

Jump to...

  • Audio Input

    Embedded Audio Input
    Analog Line or Mic in, adjustable gain

Outputs

Jump to...

  • Audio Output

    Headphone output, adjustable volume

Construction

Jump to...

  • Construction

    Milled Aluminum

Interfaces

Jump to...

  • HTTP

    WebUI for Configuration and Control

  • Configuration Interfaces

    OLED Display with joystick Navigation buttons
    Feature-rich WebUI for configuration and control

  • Switches

    On/Off and Reset Switch

  • Mobile App

    Vuer, Live: Air

  • USB Interface Functionality

    Powered USB 2.0 host port

Network

Jump to...

  • Ethernet

    10/100BASE-T

  • Wireless

    Wi-Fi: 2.4/5GHz 802.11 a/b/g/n MiMo

  • USB

    No

  • RF Channel Selection

    Auto with 3 modes: (2.4 or 5 GHz), Auto (2.4 GHz only), Auto (5 GHz only)
    Configurable to specific channels

  • Encryption

    802.1x, 802,11i, WPA2, WPA and WEP 64/128 TKIP 128bit AES

General

Jump to...

  • Dimensions (WxDxH)

    4.75 x 3 x 1.1" (12.07 x 7.62 x 2.79cm)

  • Weight

    11.6 oz (328.85g)

Other

Jump to...

  • UPC Code

    818264020494

About Teradek Cube 775

Cube 775 is the latest in Teradek's line of professional, scalable integrated decoders designed for video over IP delivery. Compatible with Cube encoders, Cube 775 offers SD/HD MPEG-4 AVC/HEVC (H.264/H.265) decoding for point-to-point video distribution, allowing content creators, broadcasters and system integrators to cost-effectively and reliably meet strict QoS requirements.

With flexible HDMI/3G-SDI dual-output and Ethernet/Wi-Fi (2.4/5Ghz)/cellular USB connection options, Cube 775 streamlines IP video deployment in existing workflows and enhances infrastructure for all users. Small form factor and high-performance decoding make it one of the most versatile solutions for content delivery strategies in the video ecosystem.

Teradek Cube 775 Features

  • Real-Time H.265/H.264 (HEVC/AVC) Decoder
  • Dual-Band 2.4/5.8 GHz Wi-Fi, Ethernet and USB Interfaces
  • HDMI and SDI Video Outputs (Outputs 1080p/30)
  • Camera Top Form Factor
  • Built-In Scaler
  • OLED Display
  • Powers by AC Adapter or 2-pin Connector Battery
  • Outfitted for 1/4" Mounting

Join VIP PRO

2 Day Delivery on thousands of items!

Sell or Trade your Gear

Get started in 3 easy steps

What's in the box:

  • Teradek Cube 775 HEVC/AVC SDI/HDMI Decoder
  • Teradek 1 Year Limited Warranty
