Used Teradek Ace 800 3G-SDI/HDMI Wireless Video Transmitter and Receiver Set

SKU: US1409756

This item is no longer available.

Overview
Compare
Specs
Q&A

Questions & Answers

Reviews about this item

Review Summary

Teradek Ace 800 Specifications

Wireless

Wireless

Jump to...
  • Wireless Range

    800' (243.84m)

  • Latency

    < 1 ms

  • Wi-Fi

    5 GHz

Interfaces

Jump to...
  • Transmitter Antenna Ports

    2x RP-SMA Female

  • Receiver Antenna Ports

    3x RP-SMA Female

  • Transmitter Video Connectors

    1x BNC (3G-SDI) Input
    1x BNC (3G-SDI) Loop Output

  • Receiver Video Connectors

    1x BNC (3G-SDI) Output
    1x HDMI (HDMI 1.3) Output

  • HDCP Support

    None

  • Transmitter Built-In Battery

    None

  • Receiver Built-In Battery

    None

  • Transmitter Power Connector

    1x 2-Pin LEMO Input

  • Receiver Power Connector

    1x 2-Pin LEMO Input

  • Transmitter Power Consumption

    Device: 6 to 28 VDC

  • Receiver Power Consumption

    Device: 6 to 28 VDC

General

Jump to...
  • Material

    Aluminum

  • Transmitter Mounting

    3x 1/4"-20 Female

  • Receiver Mounting

    3x 1/4"-20 Female

About Teradek Ace 800 3G-SDI/HDMI Wireless Video Transmitter and Receiver Set

Affordable Wireless Video
Ace 800 is an affordable, zero delay wireless video system featuring HD video transmission and professional performance with up to 800 ft. of range. Designed with the same reliability and performance as the renowned Teradek Bolt line, you get the benefits of wireless video without the hefty price tag.

Zero-Delay HD Quality
For mission-critical video applications, count on Ace 800 to provide a continuous video feed and clean, HD picture quality. An intelligent RF design enables you to transmit over the 5GHz band in even the most challenging production environments.

Connect Ace 800 to any camera via SDI for a compact, lightweight wireless setup that enables greater mobility so you can capture tricky shots with ease.

Built For Content Creation

Monitoring For All
Send 1080p60 video from one transmitter to up to four receivers simultaneously and let your crew and clients monitor every shot as it happens.

Designed For Durability
With a durable aluminum-milled chassis and 2-pin locking power connector, Ace 800 is ready to take on the elements - from in-studio to run-and-gun productions.

Designed For Any Rig
To adapt to whatever your rig requires, Ace 800 features three built-in 1/4-20" mounting points for camera arms or hot shoes, and an optional mounting bracket.

Professional Power
Keep your Ace powered with optional battery plates that attach directly to your transmitter. Power your receiver with optional Gold or V-Mount battery plates.

Robust Antenna Design
External antennas on the TX and RX ensure a more robust wireless performance and greater signal diversity for a consistent video feed in variable production environments.

Wireless Video For Any Application
Whether you need to receive video in the palm of your hands or input to a video switcher, Ace 800 has you covered with SDI and HDMI outputs. Trust your wireless link even on large sets or in tough production conditions. With flexible outputs and a compact chassis, Ace 800 makes it easy and affordable to integrate wireless video onto any set.

Teradek Ace 800 3G-SDI/HDMI Wireless Video Transmitter and Receiver Set Features

  • 1080p60 wireless video, less than 1ms of delay
  • Up to 800' wireless range
  • HDMI input/output
  • Supports up to 4 Ace/Bolt receivers
  • 1x 1/4-20" mounting points

What's in the box:

  • Ace 800 Wireless Transmitter
  • Ace 800 Wireless Receiver
  • 5x Antenna
  • 2x Power Adapters
  • D Tap Cable
  • International Adapters
  • 2x SDI Cables USB to MICRO USB
  • Hot Shoe Mount Adapter
  • Original Box
