Sony DWT-P01/3040 Digital Plug-in Transmitter - 30/40 566.607-615.638MHz 1482730
See all Sony items
CloseoutUsed Condition: Average

Used Sony DWT-P01/3040 Digital Plug-in Transmitter, 30/40: 566 to 607MHz and 615 to 638MHz Carrier Frequency

Item Note: Missing SpareBattery Case; Softcase; USB Adapter Cable; Frequency List

SKU: US1482730 MFR: DWTP01/3040
Be the first to review this item
$600.00
OR
$100/mo suggested payments with 6‑month special financing. Learn how.
Earn VIP Reward Points
See all Used options (1) from $600

What`s in the box:

  • DWT-P01/3040 Digital Plug-in Transmitter
  • USB Cable ** Item Note: Missing SpareBattery Case; Softcase; USB Adapter Cable; Frequency List **

INCLUDES FREE WARRANTY

  • This used item comes with a free 90-day warranty. ?
Free Shipping

See Options

Add to List

Protect your gear with Adorama Protect.* Learn more

1 Year

$36.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest in Pre-Owned Gear & Peace of Mind!

Extend coverage on pre-owned products after the retailer warranty ends and protect photo & video gear from accidental damage with Adorama Protect.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Extended Protection

Coverage for pre-owned gear begins after the retailer warranty ends, plus accidental damage protection for photo/video gear that starts on day one.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for International and U.S. territories purchases. Plans on pre-owned items do not cover pre-existing damages.

Browse our FAQ

See Terms & Conditions

Sony DWT-P01/3040 Specifications

  • Type of Transmitter

    UHF Digital Plug-in

  • No Of Channels

    188

  • Carrier Frequency

    30/40: 566 to 607MHz & 615 to 638MHz

  • Type of Input Connector

    3-pin XLR

  • Frequency Response

    20Hz to 20kHz

  • Battery Type/Approx. Life

    Approximately 3.5 hr at 10mW output using alkaline batteries
    Power Requirements: DC 3.0V, (two AA size batteries)

  • RF Output

    1mW / 10mW / 50mW

  • Level Control

    Max. -22dBu (with 0dB attenuator) Mic; +24dBu Line

  • Antenna Type

    1/4 Wave

  • Display

    LED Display

  • Dimensions (W x H x D)

    1 3/4 x 1 3/4 x 1 1/2" (63 x 73 x 17mm)

  • Weight

    9 oz including batteries

About Sony DWT-P01/3040 Digital Plug-in Transmitter - 30/40 566.607-615.638MHz 1482730

The Sony DWT-P01 Digital Plug-in Transmitter adapts to XLR terminated microphones and enables them to be used with Sony UHF wireless microphone receivers operating on UHF channels 30/40: 566 to 607MHz & 615 to 638MHz. The transmitter features 48V phantom power for condenser microphones and digital audio processing for lower noise and longer, efficient range.

Up to three selectable output power settings are provided for maximum results and improved battery efficiency. Two AA alkaline batteries power the DWT-P01 for up to 10 hours at the 10mW power setting. Additional features include an input attenuator, RF frequency selection, RF power output, Audio LCF frequency and a power sleep mode (in the transmitter) that can be remotely controlled from the DWR-S01D digital wireless receiver.

Sony DWT-P01/3040 Digital Plug-in Transmitter - 30/40 566.607-615.638MHz 1482730 Features

  • Supports mic or line input
  • Audio and metadata transmission operates on UHF-TV channels 30/40: 566 to 607MHz & 615 to 638MHz
  • Transmitter settings can be remotely controlled from the digital wireless receiver (using 2.4 GHz IEEE802.15.4 communication technology)
  • Compact, lightweight and built with a sturdy die-cast magnesium body
  • 3.5 hr battery life using two AA alkaline batteries @ 10mW power setting
  • 7-1/2 hr battery life using two AA nickel-metal hydride batteries @ 10mW power setting
  • 10-1/2 hr battery life using two AA lithium batteries @ 10mW power setting
  • Selectable output power 1/10/50mW

Warranty Information

This used item has a FREE 90-day warranty. See details.

Used Guarantee

30-day money back!

Sell or Trade your Gear

Get started in 3 easy steps

What's in the box:

  • DWT-P01/3040 Digital Plug-in Transmitter
  • USB Cable
  • Item Note: Missing SpareBattery Case; Softcase; USB Adapter Cable; Frequency List
