Item Note: Missing Remote Control; Lens Cap; Cord Cover; Software CD
See Options
Need help? Ask our experts.
Review Summary
2018-07-27T10:40:09
I work for a pro AV company and the total Epson projector line is the top for quality, brightness, resolution, ease to setup and long bulb life. we only use Epson in our installation and rental dept. thanks
DON M.
Extend coverage on pre-owned products after the retailer warranty ends and protect photo & video gear from accidental damage with Adorama Protect.
If we can’t fix it, we’ll replace it at no additional cost.
Coverage for pre-owned gear begins after the retailer warranty ends, plus accidental damage protection for photo/video gear that starts on day one.
Enjoy your gear without fear. We have you covered!
When regular use of your product over time results in mechanical or electrical failure.
We will never charge you a deductible after the purchase of a plan.
Our claims process is simple & easy and our customer service team is happy to help.
Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for International and U.S. territories purchases. Plans on pre-owned items do not cover pre-existing damages.
Browse our FAQ
High-aperture Epson 3-chip 3LCD technology
Front / rear / ceiling mount
Epson Poly-silicon TFT Active Matrix
1,024,000 pixels (1280 x 800) x 3
5500 lumens
5500 lumens
Supports 4:3, 16:9, 16:10
1920 x 1200 (WUXGA)
640 x 480, 800 x 600, 1280 x 1024, 1400 x 1050
300 UHE
Normal mode: Up to 10,000 hours
ECO mode: Up to 5000 hours
87%
1.26 - 2.30
30" - 300"
Horizontal: +/-30 deg.
Vertical: +/-30 deg.
High Brightness, Dynamic Mode: 15,000:1
10 bit
Up to 1 billion colors
Pixel Clock:
13.5 MHz - 162 MHz (up to UXGA 60 Hz)
Horizontal:
15 KHz - 92 KHz
Vertical:
50 Hz - 85 Hz
Manual focus / zoom
1.65 - 2.55
21.34 mm - 37.99 mm
Optical zoom 1.0x - 1.8x
Horizontal: +/-10 deg.
Vertical: +/-50 deg.
NTSC: 480 line
PAL: 576 line (depends on observation of the multi-burst pattern)
NTSC/NTSC4.43/PAL/M-PAL/N-PAL/PAL60/ SECAM/480i/576i/480p/576p/720p/1080i/1080p
1x HDBaseT
HDMI x 2 (1x MHL)
Computer: D-sub 15 pin x 1
Component Video: 1x BNC
Audio-in: 2x Mini stereo
Network: 1x RJ-45 100 Mbps
Serial: 1x RS-232c
USB: 1x Type A (for wireless module, service, firmware update, clone settings)
1x Type B (firmware update)
1x Hardwire remote jack
Monitor Out: 1x D-sub 15 pin
1x Audio Out
Normal mode: 38 dB
ECO mode: 28 dB
Power, Source Search Selection, Computer, Video, A/V Mute, Freeze, User ID, Auto, Aspect, Color Mode, Number, Page Up and Down, E-Zoom, Volume, Help, Menu, Enter, Esc and Pointer Functions
49' (14.94m)
Right / Left:
Front: +/-60 deg.
Rear: +/-30 deg.
Upper / Lower:
Front: +/-20 deg.
Rear: +10 to +45 deg.
100 - 240 V +/-10%, 50/60 Hz AC
Normal mode: 462 W
ECO mode: 324 W
Communication on: 3.0 W standby
Communication off: 0.5 W standby
Security Cable Hole
Lens Lock
Kensington lock provision
0 to 45deg. C (32 to 113deg. F)
Including feet: 8.5 x 13.9 x 6.2" (215.90 x 353.06 x 157.48mm)
Excluding feet and lens: 18.5 x 12.6 x 5.2" (469.90 x 320.04 x 132.08mm)
15.2 Lbs (6.89kg) with standard Lens
Epson bright projector
By DON M.
I work for a pro AV company and the total Epson projector line is the top for quality, brightness, resolution, ease to setup and long bulb life. we only use Epson in our installation and rental dept. thanks
Full HD large-venue projector with lens shift and robust connectivity
Designed for large venues, the PowerLite 5530U Full HD installation projector delivers uncompromising image quality and professional-grade reliability. Offering 3x Higher Color Brightness than competitive models, Epson 3LCD projectors ensure bright, vivid images. Featuring 5,500 lumens of color brightness and 5,500 lumens of white brightness, plus WUXGA resolution with 1080p support, the PowerLite 5530U shines bright, even in environments with high ambient light. Horizontal and vertical lens shift increases installation flexibility, while HDBaseT connectivity ensures easy integration. Miracast allows wireless screen mirroring for Android devices and 1080p video streaming. The projector also supports enterprise-level wireless security and remote network monitoring/control.
3x Higher Color Brightness and reliable performance: 3LCD, 3-chip technology
Look for two numbers: The PowerLite 5530U has: 5,500 lumens Color Brightness for accurate, vivid color, 5,500 lumens White Brightness for well-lit rooms
Crisp, detailed widescreen images up to 300": WUXGA resolution (1920 x 1200) with Full HD 1080p support and up to 15,000:1 dynamic contrast ratio
Installation flexibility: up to +/-50 percent vertical and +/-10 percent horizontal lens shift
Wireless screen mirroring with Miracast: stream Full HD 1080p content and mirror your wireless Android device screen
Advanced connectivity: HDBaseT and 2x HDMI inputs for easy integration with any system
Enterprise-level wireless security: the optional wireless LAN module (sold separately) supports robust wireless network security protocols that help keep information safe
Remote network monitoring and control: plus Message Broadcasting and built-in scheduling functions
Long-lasting lamp: up to 10,000 hours in ECO Mode
Seamless integration tools: compatible with Crestron RoomView and Extron
3x Brighter Colors with Epson
Brilliant image quality requires high color brightness. Epson 3LCD projectors have 3x Brighter Colors than leading competitive projectors. Delivering 5500 lumens of color brightness and 5500 lumens of white brightness, the PowerLite 5530U uses 3LCD, 3-chip technology for brilliant images with true-to-life color.
Bright and Colorful
Features 5500 lumens of color brightness (color light output) and 5500 lumens of white brightness (white light output).
WUXGA Resolution
1920 x 1200 Full HD widescreen resolution.
Lens Shift
Equipped with horizontal and vertical lens shift.
HDMI Connectivity
Includes all-digital, HDMI audio and video connection, for HD quality with just one cable.
HDBaseT
Combines HDMI, Ethernet and RS-232 into one cable.
