NEC MultiSync P243W Specifications

Display

Display

Jump to...
  • Panel Technology

    IPS

  • Aspect Ratio

    16:10

  • Pixel Pitch

    0.27 mm

  • Backlight Type

    W-LED

  • Contrast Ratio (typical)

    1000:1

  • Response Time (typical)

    8 ms

  • Displayable Colors

    1.07 billion

  • Viewable Image Size

    24.1"

  • Native Resolution

    1920x1200

  • Pixels Per Inch

    93 at native resolution

  • Brightness (typical)

    350 cd/m2

  • Viewing Angle (typical)

    178 deg. Vert., 178 deg. Hor. (89U/89D/89L/89R) at CR>10

  • Active Screen Area

    518.4 x 324.0 mm

  • Lookup Table

    14-bit (3D)

  • Color Gamut

    Adobe RGB Coverage/Size:77.0% / 79.3%
    NTSC Coverage/Size:73.1% / 75.7%
    sRGB Coverage/Size:99.8% / 106.9%

  • Synchronization Range

    Horizontal (Analog/Digital): 31.5 kHz-93.8 kHz and 118.4 kHz / 31.5-91.1 kHz and 118.4 kHz
    Vertical: 50-85 Hz

  • Signal Compatibility/Connectivity

    DisplayPort, DVI-D, HDMI, VGA 15-pin D-sub, USB hub (2 up/ 3 down) with DisplaySync Pro

    Input Terminals
    Connectors: DisplayPort, DVI-D, HDMI, VGA 15-pin D-sub, USB hub (2 up/ 3 down) with DisplaySync Pro

Power Consumption (typical)

Jump to...
  • Power Consumption (typical)

    On: 25W
    Power Savings Mode: 0.2 W

  • Power Supply

    AC 100-240 V, 50/60 Hz

  • Current Rating

    1.05 - 0.55 A

Environmental Conditions

Jump to...
  • Operating Temperature

    41-95 deg. F (5-35 deg. C)

  • Operating Altitude

    16400' (5000m)

  • Storage Humidity

    10-85%

  • Operating Humidity

    20-80%

  • Storage Temperature

    14-140 deg. F (-10-60 deg. C)

  • Storage Altitude

    40,000' (12,192m)

Environmental Compliance

Jump to...
  • RoHS

    Yes

Additional Function

Jump to...
  • Additional Function

    SpectraView Engine
    ECO Mode
    Carbon footprint meter
    Tilt
    Swivel
    Pivot
    Height-adjustable stand
    Quick release stand
    Carrying handle
    Rapid Response
    XtraView+
    OSD user controls
    NaViSet Administrator software
    Cable management
    Touch-integratable
    VESA mount
    HDCP
    DDC/CI
    No Touch Auto Adjust
    14-bit 3D LUT
    Black Level adjustment
    AmbiBright
    CableComp
    SpectraViewII software-ready

VESA Hole Configuration

Jump to...
  • VESA Hole Configuration

    100 x 100mm

Bezel Width

Jump to...
  • Bezel Width (Left/Right, Top/Bottom)

    17.9 / 17.9 / 17.9 / 17.9mm

General

Jump to...
  • Dimensions (WxHxD)

    With stand: 21.9 x 14.9-20.8 x 9.2" (55.63 x 37.85-52.83 x 23.37cm)
    Without stand: 21.9 x 14.2 x 2.3" (55.63 x 36.07 x 5.84cm)

  • Weight

    With stand: 18.1 lbs (8.21kg)
    without stand: 11.9 lbs (5.40kg)

6 Accessories for NEC MultiSync P243W 24" Professional sRGB Gamut Desktop IPS LED Monitor, 1920x1200

  • All Accessories (6)
  • Cables & Adapters (4)
  • Cleaning Accessories (2)

About NEC MultiSync P243W 24" Professional sRGB Gamut Desktop IPS LED Monitor #1698604

Designed to handle sRGB graphics projects with confidence, the LED-backlit P243W, a 24" widescreen monitor that is ideal for web, high-end desktop and photography applications. This model utilizes an IPS panel for great imaging performance. Offering 99.8% coverage of sRGB color gamut and 73.1% of NTSC, the P243W provides professional-grade benefits, such as an internal 14-bit 3D programmable lookup tables (LUTs), DisplayPort connectivity and built-in USB hub.

Technologies

Rapid Response
Delivers virtually uninterrupted, undistorted viewing of high-speed, full-motion video.

XtraView
Delivers wide viewing angles of up to 176 deg. horizontally and vertically (up to 88 deg. up, down, left and right) without any glare, reflection or distortion.

3D LUT
Internal 14-bit programmable 3D lookup tables (LUTs) allow the display of 1.07 billion colors out of a palette of 4.3 trillion (with 10-bit DisplayPort input) for accurate color, smooth images and hardware calibration.

6-Axis Color Control
Allows for precise and simplified color, color temperature and saturation adjustment.

AmbiBright
Automatically adjusts the backlight depending on the brightness of ambient lighting conditions. It also tells the monitor to enter power saving mode whenever the ambient lighting falls below a predetermined value (like when lights are shut off at the end of the day), which can significantly reduce energy consumption.

Ambix4
Allows up to four inputs (DisplayPort, VGA and two DVI-D) to be connected to a single monitor and for each of the four signals to be displayed with the press of a button.

Auto Image Rotation
Automatic rotation of the displayed image based on the orientation of the monitor head

CableComp
Equalizes the video signal to eliminate color halos on long cable runs.

Digital Uniformity Compensation
Reduces screen uniformity errors and compensates for differences in color/grayscale and luminance using new signal processing circuitry.

DisplaySync Pro
DisplaySync Pro is a type of KVM (keyboard, video, mouse) switch. It allows multiple computers to be connected to the monitor through USB and share the attached USB devices, such as a keyboard and mouse, saving desktop space and increasing productivity.

Kensington Lock
Enables a security cable to be attached to the projector.

MultiProfiler
This software provides an intuitive interface to control the display's sophisticated technologies, such as loading any ICC profile directly into the display for optimal color space matching.

MultiSync P/PA Series Picture by Picture
Displays a either second video source or the same video source in an window beside the main video source. The Picture by Picture window can display the video source in the same or an alternate color space.

Picture-in-Picture
Allows two sources to be displayed on the screen at one time in either a picture-in-picture or side-by-side configuration. SpectraView Engine (SPECTRAVIEW ENGINE)
This system is designed for improving the visual quality of the monitor. By making automatic adjustments during operation of the monitor hardware in real time, optimal settings are configured without any user interaction.

DisplayPort
DisplayPort is designed to be a future-ready, scalable solution for high performance digital display connectivity. It enables the highest resolutions, the fastest refresh rates and deepest color depths over standard cables.

HDMI
HDMI is designed to be a future-ready, scalable solution for high performance digital display connectivity. It enables the highest resolutions, the fastest refresh rates and deepest color depths over standard cables, especially for consumer audio/ video equipment.

P&D (Plug and Display)
The VESA standard for digital flat panel monitor interfaces. It is more robust than DFP since it allows for other options off a signal connector (options like USB, analog video and IEEE-1394-995). The VESA committee has recognized that DFP is a subset of P&D. As a DVI-based connector (for the digital input pins), only a simple adapter is necessary for compatibility between P&D and other DVI-based digital connector such as DVI and DFP.

Color Control Systems
Adjusts the colors on the screen and allows customization of the color accuracy of the monitor to a variety of standards.

Natural Color Matrix
Combines Six-axis color control and the sRGB standard. Six-axis color control permits color adjustments via six axes (R, G, B, C, M and Y) rather than through the three axes (R, G and B) previously available. The sRGB standard provides the monitor with a uniform color profile. This assures that the colors displayed on the monitor are exactly the same as on the color printout (with sRGB supporting operating system and sRGB printer). This allows you to adjust the colors on your screen and customize the color accuracy of your monitor to a variety of standards.

OSD (On-Screen Display) Controls
Provides access for quick and easy adjustment to all elements of the screen image via simple to use on-screen menus.

ErgoDesign Features
Enhance human ergonomics to improve the working environment, protect the health of the user and save money. The ergonomic features include a fully articulating stand, OSD controls for quick and easy image adjustment and lower emissions.

VESA Standard Mounting Interface
Connects the MultiSync monitor to any VESA standard third party mounting arm or bracket.

Adjustable stand with pivot capability
Adds flexibility for your viewing preferences.

Quick Release stand
Allows fast removal of the stand from the monitor.

Plug and Play
The Microsoft solution with the Windows operating system facilitates setup and installation by allowing the monitor to send its capabilities (such as screen size and resolutions supported) directly to the computer, automatically optimizing display performance.

Intelligent Power Manager System
Provides innovative power-saving methods that allow the monitor to shift to a lowerpower mode when on but not in use, reducing emissions and lowering the cost of operating the monitor by reducing its power consumption.

FullScan Capability
Allows use of the entire screen area in most resolutions, significantly expanding the image size.

Wide Viewing Angle Technology
Allows you to be able to see the monitor from any angle (178 deg. ) from any orientation - Portrait or Landscape. Provides full 178 deg. viewing angles either up, down, left or right.

No Touch Auto Adjust (Analog input only)
Automatically adjusts the monitor to optimal settings upon initial setup.

sRGB Color Control
An optimized color management standard which allows for color matching on computer displays and other peripherals. The sRGB, which is based on the calibrated color space, allows for optimal color representation and backward compatibility with other common color standards.

Uniformity (UNIFORMITY)
This feature compensates for slight variations in the white uniformity level that may occur on the screen and improves the color and evens out the luminance uniformity of the display.

Response Improve
Improves gray to gray response.

Auto dimming technology
Automatically adjusts the backlight level depending on the level of ambient light.

USB 3.1 Gen 1
USB 3.1 Gen 1 hub for faster communication with the workstation, e.g. using a USB memory stick.

NEC MultiSync P243W 24" Professional sRGB Gamut Desktop IPS LED Monitor #1698604 Features

  • AH-IPS LCD panel with 99.8% coverage of sRGB color space
  • Superior screen performance (1000:1 contrast ratio, 1920 x 1200 native resolution, 350 cd/m½ brightness)
  • Supports internal programmable 14-bit 3D lookup tables (LUTs) for calibration
  • 2-port USB hub with DisplaySync Pro controls two computers with only one keyboard and mouse
  • Five programmable Picture Mode profiles for quick access to multiple color spaces
  • Picture in Picture and Picture by Picture modes increase productivity by displaying two sources simultaneously
  • Wide connectivity includes DisplayPort, VGA, HDMI and DVI-D inputs
  • NaViSet Administrator 2: Free software solution that greatly eases administration and management of larger display device installations

What's in the box:

  • NEC MultiSync P243W 24 " Professional sRGB Gamut Desktop IPS LED Monitor
  • Power Cord
  • DisplayPort Cable
  • Mini DisplayPort to DisplayPort Cable
  • USB A to B Cable
  • Original Box
