Mamiya/Leaf Credo 50 Specifications

  • Imaging Sensor

    CMOS; 44 x 33 mm

  • Effective Resolution

    50 MP

  • Resolution

    8280 x 6208 (50MP)

  • Frame size (crop factor)

    44 mm x 33 mm (1:1.3)

  • Aspect ratio

    4:03

  • Pixel size

    5.3 micron

  • Dynamic range

    14 f-stops

  • Color depth

    14 Bit (16,384 levels per channel)

  • Image File Formats

    RAW, TIFF

  • ISO sensitivity

    100-6400

  • Exposure time

    1/10,000- 1 Hour

  • Full resolution capture rate

    1.2 frames/sec

  • Color management workflow

    A range of factory ICC profiles, plus optional ability for users to create their own custom camera profiles

  • Display

    3.2", bright 1.15" touch screen with 170 Degree viewing angle

  • Image viewing

    Preview up to 6 images on one LCD screen, up to 400% zoom

  • On-board tools

    Live View on LCD, spirit level, ISO, WB, histogram, exposure alarms, image rating, 645DF custom functions

  • Languages

    English, Chinese, French, German, Italian, Japanese, Spanish, Russian

  • Storage

    CompactFlash inc. UDMA 6

  • Connectivity

    FireWire 800, USB 3.0, USB 2.0

  • Software

    Capture One 7.2.4 or higher
    Minimum requirements Apple Mac: Core Duo 2 or higher, 4GB or more, 10.8 or higher
    Minimum requirements Windows: Core Duo 2 or higher, 4GB or more, Windows 7 or higher

  • Cameras Supported

    Mamiya: 645DF+, 645DF, 645AFDIII, RZ (all types), RB
    Phase One: 645DF+, 645DF, 645AF, iXR
    Hasselblad: V-series (except for 200 and 2000 models), H1, H2, H4X
    Contax: 645AF
    View/technical: ALPA, Arca-Swiss, Cambo, Horseman, Linhof, Rollei X-Act 2, Sinar, Toyo and other 4x5" & 6x9 via Leaf Graflok or 3rd party adapter
    Other: Bronica ETRSi/ SQA/ SQAi, Fuji GX680I/II via 3rd party adapter

  • Battery

    4,300 mAh rechargeable Li-ion

  • RAW file compression

    Large: 50MB
    Small: 33MB

  • Compatible Cameras

    Hasselblad H mount

  • Operating conditions

    -10 to 40 deg. C / 14 to 104 deg. F, Humidity: 15%-80% (non-condensing)

  • Certifications

    FCC (A), CE, RoHS

  • Output image dimensions

    300 dpi: 70.1 x 52.6cm / 27.60 x 20.71"
    600 dpi: 35.0 x 26.3cm / 13.78 x 10.35"

  • Dimensions

    98 x 80 x 61.5mm / 3.86 x 3.15 x 2.42"

  • Weight

    562g / 19.82oz

Related Articles & Videos

Leaf & Mamiya: 22MP ProDigital son returns

Leaf & Mamiya: 22MP ProDigital son returns

Image files which were produced thanks to Leaf's extensive software and print industry experience, and compatibility with Mamiya's well-established line of fine cameras and optics. As icing on the cake, users could swap the digital back for Mamiya's 120 and 220 film backs. But the 6- and 11MP Val...

Read more

About Mamiya/Leaf Credo 50 Digital Back with Hasselblad H Mount

The Mamiya Leaf Credo series of digital camera backs brings the legendary Leaf image quality along with speed, flexibility and versatility that are second to none. All Leaf Credo digital backs deliver exciting new features including a 3.2" high resolution (1.15MP), bright touch LCD with a viewing angle of 170deg. to elegantly display detailed images.

Uncompromising Image Quality
The Leaf Credo delivers stunning, film-like quality that has been Leaf's trade-mark for many years. The large, specially designed sensor with unsurpassed 14 f-stops of dynamic range provides unmatched detail, richness of color, low noise and beautiful tonality. Lossless 14/16-bit file compression accelerates file handling without loss of image quality.

High Resolution and High Speed
The Leaf Credo uses unique, high resolution DELSA CCD sensors sensors with up to 80 Megapixel, measuring up to 53.7 x 40.3 mm. The Leaf Credo 80 offers the best price-performance ratio of any 80 MP single-shot capture device, allowing you to take your photography further by capturing the highest quality, single-shot images possible. The sensor provides the ability to record the finest detail, eliminating the need to use cumbersome multi-shot solutions. The Leaf Credo 50 allows you to capture what you need, when you need it, breaking the medium format ISO barrier - shoot at available light. The best of legendary Leaf colors, now at ISO 100 - 6400 or anywhere in between.

Capture Speeds as Fast as 1.2 Frames per Second
Fastest image transfer speed, by using advanced FireWire 800, USB 3.0 and UDMA CompactFlash technologies.

Total Control from Capture-to-Delivery
The Leaf Credo lets you shoot anywhere. Featuring a high resolution, 3.2" touch screen, enabling you to view, inspect and edit your images under all kinds of challenging lighting conditions, specifically with the credo 50 whether you are shooting at ISO 100, 6400 or anywhere inbetween you can capture unique images in available light anytime.

Capture One Software
Photographers are able to leverage the unique features and workflow environment of Capture One workflow software to optimize and enhance their images, create web galleries and print contact sheets directly from the computer.

Wireless Preview, Control and Liveview
With the Leaf Credo, you, your client or an art director can use Capture Pilot to preview and rate images during the shoot on an Apple iPhone, iPad or iPod touch and remotely control your camera. High quality Live View of the Credo 50 allows for easy composition and focusing - on the digital back or on your mac/PC through Capture One.

Extensive Compatibility
Leaf Credo backs are compatible with many current and legacy medium and large format cameras as well as wide-angle technical cameras with tilt-and-shift movements. RAW files can be used in most 3rd party applications such as Adobe Camera Raw, Adobe Lightroom and Iridient Raw Developer.

What's in the box:

  • Item Note: Large scratch along bottom edge of sensor; Image quality will be severely affected; May have other issues; Sold as-is FOR PARTS ONLY; Cosmetic condition is E
