Used NewTek TriCaster TCXD300 HD TV Studio for HD Portable Live Production, Full Unit, with NewTek Tricaster LiveControl LC-11

NewTek TriCaster TCXD300 HD TV Studio for HD Portable Live Production SKU1777571 Features

• End-to-end HD 1080i video pipeline, including effects and virtual sets
• Video processing employs 32-bit floating-point precision, 4:4:4:4 video processing and component (YCbCrA) color (well beyond industry standard 10-bit)
• Four-channel audio processed at 48 kHz, 32-bit floating point
• Extensive audio input/output flexibility including Embedded SDI on all video channels, four channels of AES/EBU and professional level balanced XLR/phone connectors
• All video inputs can be Proc-Amped, keyed and frozen, including titles and DDRs
• Integrated full field rate Waveform Monitor and Vectorscope with full color beam tracing
• Individual processing controls for both Main and VGA outputs
• Pristine capture of video or stills with support for full 4:2:2 up to 1920 x 1080 resolution at very high bit-rates
• Next-generation optimized user-interface design with key live production tools readily available, supported by the ability to quickly access controls to configure each source
• Five Virtual Input functions, each similar to advanced mix/effects bus with positioning and overlay capabilities
• Use "virtual cameras" by populating multiple Virtual Inputs from a single camera source (and switch between them)
• Each source has a Proc Amp, keying, garbage matte and alpha channel support
• Layer up to five live video or CG sources (internal or supplied by network)
• Independent zoom and pan controls for each source that make composition and camera placement easy
• All Virtual Inputs provide an additional overlay channel with independent transitions and scaling capabilities
• Insert live video inputs into live virtual sets with ease
• Zoom the virtual camera smoothly and easily either interactively, or using automatic control to user specified zoom preset levels
• Presets provide quick convenient access to numerous Virtual Input setups
• HD-SDI and HD component plus SD-SDI, component, Y/C and composite input/output
• Mix source resolutions and aspect ratios (including HD and SD video)
• Simultaneous HD and SD video output with Proc Amp control
• iVGA supports unlimited networked computers as live inputs to the switcher
• Simple live HD streaming with Adobe Flash or Windows Media in either push or pull
• Record 18 hours of full HD 1080i video in high quality 100Mbps I-Frame only MPEG at up to 4:2:2 color precision
• Genlock input for broadcast system integration supports bi-level and tri-level references
