Used RED Pro I/O Module, Central Hub for DSMC BRAIN #720-0004

SKU: US1794007 MFR: 720-0004
Earn VIP Reward Points

What`s in the box:

  • RED Digital Cinema Pro I/O Module

INCLUDES FREE WARRANTY

  • This used item comes with a free 180-day warranty. ?
Free Shipping

See Options

Protect your gear with Adorama Protect.* Learn more

1 Year

$24.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest in Pre-Owned Gear & Peace of Mind!

Extend coverage on pre-owned products after the retailer warranty ends and protect photo & video gear from accidental damage with Adorama Protect.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Extended Protection

Coverage for pre-owned gear begins after the retailer warranty ends, plus accidental damage protection for photo/video gear that starts on day one.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for International and U.S. territories purchases. Plans on pre-owned items do not cover pre-existing damages.

RED Digital Cinema Pro I/O Module Specifications

  • Compatibility

    EPIC/SCARLET DRAGON and EPIC/SCARLET M-X Cameras

  • System Requirements

    The Pro I/O Module is compatible with all EPIC and SCARLET BRAINs
    The Pro I/O Module requires either the Module Adaptor or the +1 Adaptor Module to be connected to the BRAIN
    The Pro I/O Module requires that your DSMC is on firmware v3.3.18 or later

  • Construction

    Aluminum Alloy

  • Connectors

    1x Genlock / PGM / Preview (BNC)
    1x AES
    2x 3-Pin XLR Input
    1x 5-Pin XLR Output
    1x Timecode (5-Pin LEMO)
    1x GPIO (4-Pin LEMO)
    1x Power (4-Pin LEMO)
    1x AUX (10-Pin LEMO)
    1x LCD/EVF Output (LEMO, RED Display/EVF)

  • Current Draw

    24 W when used with RED Touch 5.0" LCD

  • Auxiliary Power Output

    1.5 A continuous load at 11.5 to 17 VDC

  • Operating Temperature

    0 to 40 deg. C (32 to 104 deg. F)

  • Storage Temperature

    -20 to 50 deg. C (-4 to 122 deg. F)

  • Dimensions (HxWxD)

    4.29 x 3.86 x 3.84" (108.97 x 98.04 x 97.54mm)

  • Weight

    2.4 lbs (1.09kg)

About RED Pro I/O Module Central Hub for DSMC BRAIN - Mfr# 720-0004 SKU#1794007

For advanced configurations, the Pro I/O Module attaches to the rear of your DSMC BRAIN to provide a central hub for essential I/O connections. Professional I/O support for audio and video is critical for large productions and the Pro I/O Module bundles them conveniently into one compact DSMC module.

RED Pro I/O Module Central Hub for DSMC BRAIN - Mfr# 720-0004 SKU#1794007 Features

  • Centralized ports that make it easy to manage connections and cables
  • LCD/EVF port that allows you to connect an additional RED LCD or EVF
  • Customizable triggers that interface with third-party GPIO and RS232 control devices
  • Mounting points for an additional DSMC module or a REDMOTE
  • Internal cooling system that maintains an appropriate operating temperature

Warranty Information

This used item has a FREE 180-day warranty. See details.
