Used Sky-Watcher HEQ5i Pro GoTo SyncScan Equatorial Mount with Wi-Fi Adapter

Item Note : Does not include tripod; Counter Weights ;

SKU: US1942175 MFR: S30405
Earn VIP Reward Points

What`s in the box:

  • Sky-Watcher HEQ5i Pro GoTo SyncScan Equatorial Mount
  • SynScan Pro App with Wi-Fi Adapter
  • DC Power Cord
  • Original Box ** Item Note : Does not include tripod; Counter Weights ; **

INCLUDES FREE WARRANTY

  • This used item comes with a free 1-year warranty. ?
Calculate Shipping

See Options

Protect your gear with Adorama Protect.* Learn more

1 Year

$119.00

2 Year

$209.00

3 Year

$309.00

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Sky-Watcher HEQ5i Pro Specifications

General

General

Jump to...
  • Mount Type

    German Equatorial

  • Telescope Mounting

    Tube Rings

  • Slow-motion Control

    R.A. & Dec (motor controlled)

  • Tripod Diameter

    1.75" (44.45mm) Stainless Steel Pipe

  • Tripod Height

    38.18-47.63" (97-121cm)

  • Counterweight Shaft Diameter

    0.70" (1.8cm)

  • Counterweight Shaft Length

    8.46" (21.5cm)

  • Counterweight Shaft Material

    Stainless Steel

  • Mount Height

    13.77" (35cm)

Computer/Drive System

Jump to...
  • Power Supply

    12 VDC 2Amp (Tip positive)

  • Motor Type

    Micro step driven 1.8° stepper motors

  • Resolution

    0.144 arc sec (or 9,024,000 steps/rev.)

  • Slew Speeds

    2X, 8X, 16X, 32X, 64X, 400X, 500X, 600X, 800X

  • Gear Ratio

    705

  • Tracking Rate

    Sidereal, Lunar, Solar

  • Tracking Modes

    Dual Axis, R.A. Tracking

  • Alignment Methods

    One-star Alignment, Two-star Alignment, Three-star Alignment

  • Database

    25 user defined objects. Complete M, NGC, and IC catalogues. Total 13,436 objects

Physical

Jump to...
  • Weight

    Total: 33.06 lbs (15kg) (counterweight not included)
    Tripod: 12.34 lbs (5.6kg)
    Mount: 22.04 lbs (10Kg)
    Counterweight: 11.24 lbs (5.1kg) each

About Sky-Watcher HEQ5i Pro GoTo SyncScan Equatorial Mount with Wi-Fi Adapter

Meticulous Mid-Range Machinery
Sky-Watcher SynScan mounts have been designed for use by novices and experts alike. These mounts provide extremely high precision tracking and have built in autoguider ports. This heavy-duty HEQ5i Pro mount is a smaller version of the sturdy EQ6 Pro mount. It is specially designed for observers who need the steadiness of the EQ6 Pro mount but find it too physically demanding. But make no mistake, the HEQ5i Pro can be that perfect mid-range rock solid platform you build your astroimaging rig on.

42,000+ Object Database
For novice users, the user-friendly menu allows automatic slewing to 42,900+ objects. Even an inexperienced astronomer can master its variety of features in a few observing sessions. PC control can be done with SynScan Pro for Windows app or your favorite third-party software with the correct drivers.

Flexible Polar Alignment
Sky-Watcher includes an illuminated polar finderscope to aid the alignment process. The finderscope features a circular grid reticle for the Northern Hemisphere, consistent with todayf s popular polar alignment apps. For astronomers in the Southern Hemisphere, the constellation Octans is built into the reticle as well. Simply choose one of the visible stars listed and use the latitude adjustment screws to center it in the eyepiece.

SynScan Wi-Fi App Complete GoTo control using your phone with the free SynScan Pro app. Available for both iOS and Android

Bundle of Accessories
As customary with all Sky-Watcher products, an assortment of accessories are included with the HEQ5i Pro mount. A retractable counterweight bar is supplied, allowing for easier transportation. Two 11-pound counterweights are also included to help balance up to a 30-pound payload. The HEQ5i Pro features a saddle compatible with both D- and V-style mounting plates, allowing users the flexibility to utilize multiple optical tubes, even if the mounting plate is different.

Sky-Watcher HEQ5i Pro GoTo SyncScan Equatorial Mount with Wi-Fi Adapter Features

  • HEQ5i GoTo equatorial head
  • 30-pound payload capacity
  • Adjustable 1.75-inch diameter rolled steel tripod
  • SynScan GoTo telescope mount with 42,900+ object database
  • Built-in polar scope with illuminator
  • Two 11-pound counterweights
  • Metal accessory tray
  • D/V-style dovetail saddle
  • SynScan Wi-Fi App Complete GoTo control using your phone with the free SynScan Pro app
  • Available for both iOS and Android

Warranty Information

This used item has a FREE 1-year warranty. See details.

What's in the box:

  • Sky-Watcher HEQ5i Pro GoTo SyncScan Equatorial Mount
  • SynScan Pro App with Wi-Fi Adapter
  • DC Power Cord
  • Original Box
  • Item Note : Does not include tripod; Counter Weights ;
