RED Digital Cinema DSMC RED MOTION TI Canon Specifications

  • Material

    Machined Titanium

  • Operating Temperature

    0 Degree C to 40 Degree C (32 Degree F to 104 Degree F)

  • Storage Temperature

    -20 Degree C to 50 Degree C (-4 Degree F to 122 Degree F)

  • Maximum Altitude

    20,000 ft.

  • Humidity Range

    0 to 90% RH

  • Shock

    10g

  • Input Voltage

    +5.0 VDC

  • Power Consumption

    1.5 W

  • Optical Density Range

    OD 0.48 to 1.20 (1.6 to 4.00 stops)(when MOTION MOUNT shutter is enabled)
    OD 0.48 to 2.40 (1.6 to 8.00 stops)(in ND Only mode)

  • Square Shutter Angle Range

    62.1 Degree to 180 Degree (Global Shutter)

  • Soft Shutter Angle Range

    62.1 Degree to 194.4 Degree

  • Maximum Frame Rate

    Max frame rates vary based on the camera and selected resolution. (when MOTION MOUNT shutter is enabled)

  • Compatibility

    WEAPON 8K S35
    WEAPON 6K
    EPIC-W
    SCARLET-W
    EPIC/SCARLET DRAGON
    EPIC/SCARLET M-X

  • Dimensions (H X W X D)

    79.9 x 85 x 23.3 mm (3.14 x 3.34 x 0.91")

  • Weight

    8.0 oz (227g)

About RED Digital Cinema DSMC RED MOTION TI Canon Mount (Captive)

The RED MOTION MOUNT Ti Canon (Captive) pushes the limits of what is possible under virtually any motion capture scenario. Its a finely tunable neutral density filter over a wide range of stops. Its a global shutter that prevents partial illumination with strobes and shearing with fast subjects. Its a time filter that renders sharper yet smoother pans, artifact-free cyclical motion, more natural motion blur, and reduced or eliminated flicker with lights and electronic displays. Most importantly, all of this can be achieved using a drop-in titanium lens mount that preserves your existing camera and workflow. The DSMC RED MOTION MOUNT Ti Canon (Captive) features captive mounting screws, so youre never searching for hardware.

Variable ND

The RED MOTION MOUNT integrates an intelligent neutral density (ND) system into its design, allowing you to electronically adjust your ND levels for precise exposure. Through the on-screen controls of your RED EPIC or SCARLET, you can finely adjust your ND opacity up to 2.4 ND, instead of having to interchange work around the predetermined values of ND glass filters. This technology encourages you to work faster and lighter by reducing the need to overload your matte box.

Global Shutter

The RED MOTION MOUNT also has a mode that behaves like a global shutter. When working with strobes or fast subjects, this mode reduces partial exposure issues and provides more consistent illumination for every frame. Skewed and smeared artifacts become imperceptible as the RED MOTION MOUNT fundamentally changes the way your camera captures light.

Soft Shutter Filter

Cleaner pans, less cyclical motion artifacts, and no flicker - thats what you can expect from your image with a RED MOTION MOUNT. The built-in time filter system eliminates many of the troubles associated with traditional motion cameras and elevates the quality of all of your imagery. With more natural motion blur and no more flickering displays or lights, the RED MOTION MOUNT brings your digital image closer to human eyesight than ever before.

Note: In ND Only mode, if the MOTION MOUNT is set near the end of its ND range and used with a very wide aperture you may notice a modified out-of-focus field (bokeh), and possibly some vignetting at the edge of the image with smaller image circle lenses. We recommend that you do not shoot past 4 stops of ND on the mount if you are shooting wide open.
