Used Sony PDW-F1600 HD Professional Disc Recorder

SKU: US1540910

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest in Pre-Owned Gear & Peace of Mind!

Extend coverage on pre-owned products after the retailer warranty ends and protect photo & video gear from accidental damage with Adorama Protect.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Extended Protection

Coverage for pre-owned gear begins after the retailer warranty ends, plus accidental damage protection for photo/video gear that starts on day one.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for International and U.S. territories purchases. Plans on pre-owned items do not cover pre-existing damages.

Browse our FAQ

See Terms & Conditions

Sony PDW-F1600 Specifications

  • Power Requirements

    AC 100 V to 240 V, 50/60 Hz, DC 12 V

  • Power Consumption

    AC: 80 W, DC: 65 W, SAVEMODE(DC): 55 W

  • Operating Temperature

    +5 to +40 deg. C (+41 to +104 deg. F)

  • Storage Temperature

    -20 to +60 deg. C (-4 to +140 deg. F)

  • Humidity

    25 to 90% (relative humidity)

  • Recording/Playback Format

    Video:
    MPEG HD422 (CBR: 50 Mb/s)
    MPEG HD:
    HQ mode (VBR, maximum bit rate: 35 Mb/s)
    SP mode (CBR, 25 Mb/s)
    LP mode (VBR, maximum bit rate: 18 Mb/s) (Playback only)
    MPEG IMX (CBR, 50/40/30 Mb/s)
    DVCAM (25 Mb/s)
    Proxy Video:
    MPEG-4
    Audio:
    MPEG HD422: 8 ch/24 bits/48 kHz
    MPEG HD: 4 ch/16 bits/48 kHz
    MPEG IMX: 4 ch/24 bits/48 kHz or 8 ch/16 bits/48 kHz
    DVCAM: 4 ch/16 bits/48 kHz
    Proxy Audio:
    A-law (8 ch/8 bits/8 kHz)

  • Recording/Playback Time1

    MPEG HD422:
    50 Mb/s: Approx. 95 min. (PFD50DLA), Approx. 43 min. (PFD23A)
    MPEG HD:
    35 Mb/s, 4-ch audio: More than 145 min. (PFD50DLA), More than 65 min. (PFD23A)
    35 Mb/s, 2-ch audio (playback only): More than 150 min. (PFD50DLA), More than 68 min. (PFD23A)
    25 Mb/s, 4-ch audio: Approx. 190 min. (PFD50DLA), Approx. 85 min. (PFD23A)
    25 Mb/s, 2-ch audio (playback only): Approx. 200 min. (PFD50DLA), Approx. 90 min. (PFD23A)

  • Recording/Playback Time2

    18 Mb/s, 4-ch audio (playback only): More than 248 min. (PFD50DLA), More than 112 min. (PFD23A)
    18 Mb/s, 2-ch audio (playback only): More than 265 min. (PFD50DLA), More than 122 min. (PFD23A)
    MPEG IMX:
    50 Mb/s: Approx. 100 min. (PFD50DLA), Approx. 45 min. (PFD23A)
    40 Mb/s: Approx. 120 min. (PFD50DLA), Approx. 55 min. (PFD23A)
    30 Mb/s: Approx. 150 min. (PFD50DLA), Approx. 68 min. (PFD23A)
    DVCAM:
    25 Mb/s: Approx. 185 min. (PFD50DLA), Approx. 85 min. (PFD23A)

  • Search Speed Range

    Jog mode:
    -1 to +1 times normal speed
    Variable mode:
    -2 to +2 times normal speed
    Shuttle mode:
    -20 to +20 times normal speed:
    F.Fwd/Rev:
    -35 to +35 times normal speed

  • Reference Input

    BNC x 2 (including loop through), HD/SD
    HD Tri-level sync (0.6 Vp-p/75 Ohms/negative), HD/SD
    or SD blackburst/composite sync (0.286 Vp-p/75 Ohms/negative), HD/SD

  • SDI Input

    BNC x 1, HD
    (HD/SD switchable)
    SMPTE 292M (w/embedded audio), HD
    SMPTE 259M (w/embedded audio), HD

  • Analog Audio Input

    XLR 3-pin (female) x 2 (channel selectable)
    +4/0/-3/-6 dBu (selectable)
    10 kOhms, balanced

  • Digital Audio Input (AES/EBU)

    BNC (x2) - 4 ch (2 ch each, 1/2 ch and 3/4 ch) AES-3id-1995

  • Time Code Input

    BNC x 1, SMPTE time code, 0.5 to 18 Vp-p/3.3 kOhms/unbalanced

  • Composite Output

    BNC (x2)
    1: 1.0 Vp-p/75 Ohms/negative, SMPTE 170M
    2: 1.0 Vp-p/75 Ohms/negative, SMPTE 170M ,character On/Off

  • SDI Output

    BNC (x 2), HD
    1: SMPTE 292M (w/embedded audio), HD
    2: SMPTE 292M (w/embedded audio), character On/Off, HD
    BNC (x 2), SD
    1: SMPTE 259M (w/embedded audio), SD
    2: SMPTE 259M (w/embedded audio), character On/Off, SD

  • Analog Audio Output

    XLR 3-pin (male) x 2 (channel selectable)
    +4/0/-3/-6 dBu (selectable), 600 Ohms, Lo-Z, balanced

  • Monitor Audio

    XLR 3-pin (male) x 2, +4 dBu, 600O, Lo-Z, balanced

  • Digital Audio Output (AES/EBU)

    BNC (x2) - 4 ch (2 ch each, 1/2 ch and 3/4 ch) AES-3id-1995

  • Headphone Output

    JM-60 Stereo phone jack x 1
    -13 dBu, 8 Ohms, unbalanced

  • Time Code Output

    BNC x 1, SMPTE time code, 1.0 Vp-p/75 Ohms/unbalanced

  • Video Control

    D-sub 9-pin (female) x 1, EIA RS-423

  • i.LINK

    IEEE 1394 6-pin x 1
    File Access Mode HDV 1080i/720P IN/OUT AV/C (DV) stream is NOT supported.

  • Ethernet

    RJ-45 x 1
    1000Base-T: IEEE802.3ab
    100Base-TX: IEEE802.3u
    10Base-T: IEEE802.3

  • Remote (9P) Input

    D-sub, 9-pin (female) (x1), RS-422A

  • DC Input (12 V)

    XLR 4-pin (male) x 1

  • DC Output (12 V)

    4-pin (female) x 1, DC 12 V, 7.5 W

  • Maintenance

    USB x 2

  • AC Input

    x 1, 100 to 240 V, 50/60 Hz

  • Video: Sampling Frequency

    Y: 74.25 MHz, Pb/Pr: 37.125MHz

  • Video: Quantization

    8 bits/sample

  • Video: Error Correction

    Reed Solomon Code

  • Processor Adjustment Range

    Video Level: -Infinity to +3 dB
    Chroma Level: -Infinity to +3 dB
    Setup/Black Level: +/-30 IRE/+/-210 mV
    Chroma Phase: +/-30 deg.
    System Sync Phase: +/- 15 ½s
    System Sync Phase (Fine): 0 to 400 ns
    System SC Phase: 0 to 400 ns

  • Audio: Sampling Frequency

    48 kHz

  • Audio: Quantization

    24 bits

  • Audio: Frequency Response

    20 Hz to 20 kHz +0.5/-1.0 dB (0 dB at 1 kHz)

  • Audio: Dynamic Range

    More than 90 dB

  • Audio: Distortion

    Less than 0.05% (at 1kHz)

  • Audio: Headroom

    20/18/16/12 dB (selectable)

  • Built-In Display

    4.3" type color LCD monitor

  • Built-In Audio Speaker

    x1, monaural

  • Dimensions (W x H x D)

    Excluding Protrusions: 210 x 132 x 396mm/ 8.27 x 5.2 x 15.59"

  • Weight

    6.5kg / 14.33lbs

About Sony PDW-F1600 HD Professional Disc Recorder - SKU#1540910

The Sony PDW-F1600 is a compact HD recorder which provides outstanding picture quality of MPEG HD422 as well as an eight-channel (HD-SDI), 24-bit audio recording capability. The foundation of the PDW-F1600 deck incorporates the features of the PDW-HD1500 and acts as more than just file-based recording deck. With its insert/assemble editing capability, it can be used as a recorder in a linear editing system - just like a conventional VTR. 23.98P and SD legacy formats are supported as standard. What's unique about this deck is its ability to operate on AC, DC or power. With its large 4.3-inch LCD and Built-In Speaker, it performs as a versatile and high-quality recorder which is suitable for both in-house and field operations. It comes equipped with a multi-format up/down converter, which is highly useful when employing both HD- and SD-format materials at the same time.

Sony PDW-F1600 HD Professional Disc Recorder - SKU#1540910 Features

  • Recording Bit Rates: MPEG-2 422p at HL format - Bit rate is 50Mbps for both 1080 and 72 - Audio Format 24bit x 8ch (PDW-700 can record up to 4ch Audio at the same time)
  • Multi-Format & Legacy Format Support: Legacy formats (DVCAM, MPEG IMX 30/40/50 Mbps, MPEG HD 420 18/25/35Mbps) are supported for both recording and playback as standard
  • 3 types of power supply: AC / DC / Battery
  • Well-constructed Body: Tilt up front panel
  • 3.5-inch Widescreen: An easy-to-view color LCD screen provided on the camcorder side panel enables advanced operations such as Thumbnail Search and Scene Selection. Status indicators such as four-channel audio meters, and disc and battery remaining time can also be displayed
  • Dual Optical Pick-up: Provides High speed file transfer - FTP Get speed(through Gb-Ethernet) : 220Mbps - i.Link read speed : 200Mbps
  • Easy and Intuitive Search Operation: Thumbnail Search function - Expand function - Equipped with a Jog/Shuttle dial, providing VTR-like operation (Jog: -1 to +1 time normal speed, Variable: -2 to 2 times
  • Built-in Multi Format Converter: The following conversion is possible in Playback mode: Downconversion from HD to SD, Upconversion from SD to HD, Cross conversion between 1080 and 720Available fall 2008
  • Video Process Control: Front panel operation using the function keys & mlti-dial 9pin video control remote
  • Control for Linear Editing Player: RS-422A control for linear editing player
  • Advanced Clip Operation: Thumbnail search, Expand" thumbnail search, Skip scroll, etc - Remote Recording over HD-SDI connection (with PDW-700 and HDW camcorders) - PDW-HD1500 can be installed into the XDCAM CART (for both PDJ-C1080 and PDJ-A640)
  • Insert/Assemble edit function: F1600 can be used as a recorder of linear editing System
  • Clip Continuous REC: Allows users to create a single, large clip with multiple rec. start & stop. The Rec. start Essence Mark is recorded to every rec. start frame. The benefits of using this mode are: capable of having more than 300 takes" on a disc - Faster transfer speed by sending a single clip
