VocoPro UHF-5800 Pro 4-Channel UHF Wireless Microphone System, Ch 4: Q, R, S, T
See all VocoPro items

VocoPro UHF-5800 Professional 4-Channel UHF Wireless Microphone System with UHF-5800 Receiver, 4x Handheld Microphone, Channel 4: Q, R, S, T

SKU: VPU58004

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Browse our FAQ

See Terms & Conditions

VocoPro UHF-5800-4 Specifications

  • Type of System

    Multi-Channel UHF Handheld

  • Frequency Band

    Channel 4: Q, R, S, T

  • RF Carrier Frequency Range

    600 - 698MHz UHF

  • Overall Frequency Response

    40Hz to 16kHz

  • Signal-to-Noise Ratio

    105dB

  • No. Of Channels

    4

  • Type of Receiver

    Rack-Mounted Modular UHF

  • Receiver: Oscillation Mode

    Quartz Controlled Fixed Frequency

  • Receiver: Stability

    10 PPM

  • Receiver: Sensitivity

    1.6uV at sinad =12dB

  • Receiver: Max. Deviation Range

    50Hz

  • Receiver: S/N Ratio

    >105dB

  • Receiver: T.H.D.

    <0.5% at 1kHz

  • Receiver: Image rejection

    85dB typical

  • Receiver: Spurious Rejection

    75dB typical

  • Receiver: Frequency Response

    40Hz-16kHz

  • Receiver: Squelch Control

    Dual-squelch circuit

  • Receiver: Max. Output Level

    Balance: 0-400mV, Unbalance: 0-200mV

  • Receiver: Power Supply

    External DC Power Supply, 0.7A, 12-15V DC

  • Receiver: Display

    LED

  • Receiver: Mounting Options

    Rack Mountable

  • Receiver: Antenna Type

    Dual BNC

  • Receiver: Type of Outputs

    3-pin XLR x4
    1/4" Phone (Mixed) x1

  • Type of Transmitter

    UHF Handheld x4

  • Transmitter: Type of Microphone

    Dynamic

  • Transmitter: Interchangeable Mic Heads

    No

  • Transmitter: Power

    30mV

  • Transmitter: Spurious Emission

    <40dB(with carrier)

  • Transmitter: Battery Voltage

    AA 1.5Vx2

  • Transmitter: Battery Life

    12 Hours

  • Transmitter: Mute Switch

    On/Off

  • Transmitter: Level Control

    No

  • Transmitter: Antenna Type

    Internal

  • Transmitter: Display

    LED

  • Dimensions (L x H x D)

    Receiver: 18.9 x 1.8 x 7.8"/ 48 x 4.57 x 19.81cm

  • UPC Code

    692868845802

About VocoPro UHF-5800-4

Experience ultimate freedom with the VocoPro UHF-5800 Professional 4-Channel UHF Wireless Microphone System (Channel 4: Q, R, S, T). With 4 handheld mics, each on their own independent UHF channel, the UHF-5800 gives you maximized vocal options without the fear of frequency interference.

Going wireless means that you are free from cables for more active performances that the crowd will never forget. Plus, a 12-hour Mic battery life means the party can go all night. KJs will love that each mic channel has its own field-replaceable module that easily slides out, without the need for tools and without affecting the functionality of the other channels. Vocalists, home entertainment enthusiasts and club-goers will all benefit from the reliability and versatility of the UHF-5800.

VocoPro UHF-5800-4 Features

  • Complies with New FCC Frequency Rules
  • 4 individual XLR Mic Outputs and one 1/4" Mixed Output
  • Individual Volume controls for precise vocal balancing
  • 4 independent Field-replaceable Modules
  • Interference-resistant UHF Band operation
  • Rugged 1RU metal receiver chassis
  • Low power consumption design for longer battery life

Join VIP PRO

2 Day Delivery on thousands of items!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Complies with New FCC Frequency Rules
  • 4 independent Field-replaceable Modules
  • Interference-resistant UHF Band operation
  • Rugged 1RU metal receiver chassis

What's in the box:

  • VocoPro UHF-5800 Receiver
  • 4 x Handheld Microphone Transmitters
  • 1/4 " Phone Male to Male Cable (3')
  • 8 x AA Alkaline Batteries
  • AC Power Supply
  • Aluminum Carrying Case
  • VocoPro 1 Year Warranty
