J52: 558-616MHz
4-Pin male mini connector (TA4M)
Unbalanced
1 M Ohm
8.2 dBV (2.57 Vrms, 7.27 Vpp)
-118 dBV (EIN)
1/4 Wave
<200 kHz
Shure Proprietary Digital
1 mW/10 mW
Rechargeable Li-Ion or 1.5 V AA batteries
PC/ABS
3.86 x 2.68 x 1" (98 x 68 x 25.5mm)
3.1 oz (89g)
>75 dB Typical
50 Ohm
Yes
1/4 Wave Whip
20 Hz - 20 kHz (+1, -3 dB)
1/8" (3.5 mm), x2
Balanced (Mono): Tip=audio +, Ring=audio -, Sleeve=ground
Dual Mono: Tip = left, Ring = Right, Sleeve = Ground
Balanced (Mono) Line: 450 Ohm
Balanced (Mono) Mic: 240 Ohm
Dual Mono Line: 400 Ohm
Dual Mono Mic: 200 Ohm
Camera (Balanced Line): 15 dBV
Headphone: 13 mW @ 64 Ohm Load
Battery: Rechargeable Li-Ion or 1.5 V AA batteries
Power Supply: SBC-DC-903 Battery Eliminator, or 5 VDC via USB-C
Aluminum
4.21 x 2.68 x 1" (107 x 68 x 25.3mm)
1.8 lbs (182g)
Lavalier
Mono
MEMS
Cardioid
40 Hz to 20 kHz
130 dB SPL (1 kHz, 1% THD)
-42.5 dBV/Pa
98 dB (Typical)
62 dB A-Weighted
1 xTA4F/Mini-XLR 4-Pin Female (Waterproof)
66" (1.7m)
Plug-In Power
3.5 to 5 V
530 microA
Black
0.2 x 0.7" (5 x 17mm)
0.4oz (12.5g)
Required, included
Alkaline
AA
6
192223243620, 042406789486, 042406764735, 042406051125
Whether you’re a professional videographer, a field production specialist or a location sound mixer, stress-free audio capture is your calling card. Wherever the work takes you, SLX-D Portable lets you bring the rock-solid RF performance and flawless digital audio of SLX-D Digital Wireless with you. Locations can be unpredictable. Wireless audio shouldn’t be.
Get the shot. Capture the sound. Every time.
From weddings to live streams, great video is nothing without great audio.
Bring the great audio experiences of the SLX-D Digital Wireless platform to your productions.
Outstanding spectral efficiency and rock-solid RF performance deliver flawless wireless audio, time after time. Locations are Unpredictable. Wireless Audio Shouldn’t Be.
SLX-D Portables have innovative set-up features that get you going at a moment’s notice. Flexible and user-friendly, SLX-D Portables capture the sound, every time.
It's time to elevate your audio experience with the SLXD15/UL4B Portable Digital Wireless Microphone System. This comprehensive package includes the SLXD1 Digital Wireless Bodypack Transmitter, the SLXD5 Single-Channel Portable Digital Wireless Receiver, and the UL4B UniPlex Cardioid Lavalier Microphone.
The SLXD1 Digital Wireless Bodypack Transmitter is a marvel of industry-leading digital wireless technology. It delivers transparent, 24-bit digital audio and robust RF performance, ensuring crystal-clear sound quality. With an extended frequency range of 20 Hz to 20 kHz, it captures every nuance of sound, making it an ideal choice for both day-long conferences and nighttime performances. The transmitter's TQG connectivity offers compatibility with a variety of microphone options, providing flexibility for a wide range of applications.
The SLXD5 Single-Channel Portable Digital Wireless Receiver is a compact powerhouse, designed for on-camera cold shoe mounting and audio bag use. It offers pristine 24-bit digital audio clarity and efficient long-range UHF transmission. The receiver's Multi-Mic Mode allows for the coordination and monitoring of large channel configurations with multiple sources. The bright OLED screen displays key system function readouts and remaining battery life, ensuring you're always in control of your audio setup.
Completing the package is the UL4B UniPlex Cardioid Lavalier Microphone. This lavalier microphone features a cardioid polar pattern, making it the perfect solution for speaking situations where sound rejection is required. Whether you're presenting at a conference, educating in a classroom, or broadcasting on air, the UniPlex ensures your voice is captured with superb directional accuracy.
In summary, the SLXD15/UL4B Portable Digital Wireless Microphone System is a versatile, high-performance solution for all your audio needs. Its combination of advanced technology, robust construction, and user-friendly features make it a standout choice for professionals seeking superior sound quality.
