Universal Audio Apollo Interface - SKU#1600825 Specifications

  • SHARC Processor

    2x SHARC DSP

  • Microphone Inputs

    4

  • High-Z Instrument Inputs

    2

  • Analog Line Inputs

    8

  • Analog Line Outputs

    8

  • Analog Monitor Outputs

    2 (stereo pair, independent L/R mix buses)

  • Headphone Outputs

    2x stereo (independent L/R mix buses)

  • ADAT

    Up to 8 channels via dual I/O ports with S/MUX

  • S/PDIF

    Stereo input, Stereo output

  • FireWire 800 ports (IEEE 1394b)

    2

  • Thunderbolt ports

    2 (via Thunderbolt Option Card) Thunderbolt 2 compatible

  • Word Clock

    Input, Output

  • Supported Sample Rates (kHz)

    44.1, 48, 88.2, 96, 176.4, 192

  • Bit Depth Per Sample

    24

  • Simultaneous A/D conversion

    8 Channels

  • Simultaneous D/A conversion

    14 Channels

  • Analog Round-Trip Latency

    1.1 milliseconds at 96 kHz sample rate
    1.1 milliseconds at 96 kHz sample rate (up to four serial UAD plug-ins via Console application)

  • Phantom Power

    +48V (switchable per mic input)

  • Equivalent Input Noise

    -128 dB

  • Default Input Impedance

    5.4 kOhms (variable via Unison preamp plug-ins)

  • Pad Attenuation

    20 dB (switchable per mic input)

  • Mic Input 1-4: Maximum Input Level

    -31.1dBV, 23.9 dBV (at Minimum Gain, with Pad)

  • Hi-Z Inputs: Maximum Input Level

    At Minimum Gain: 10 dBV
    At Maximum Gain: -45dBV

  • Common-Mode Rejection Ratio (CMRR)

    Line Inputs 1 - 4: Greater than 60 dB (10' cable)
    Microphone Inputs 1 - 4: Greater than 60 dB (10' cable)

  • Gain Range

    Microphone Inputs 1 - 4: +10 dB to +65 dB
    Hi-Z Inputs: +10 dB to +65 dB
    Line Inputs 1 - 4: +10 dB to +65 dB

  • Maximum Input Level (at Minimum Gain)

    18 dBV

  • Maximum Input Level (at Maximum Gain)

    -37 dBV

  • Common-Mode Rejection Ratio

    Greater than 60 dB (10' / 3.04m cable)

  • Input Impedance

    Hi-Z Inputs: 2.2M Ohms
    Line Inputs 1 - 4: 10 kOhms
    Line Inputs 5 - 8: 10 kOhms

  • Gain Settings

    +4 dBu / -10 dBV (selectable per input)

  • Line Inputs 5-8: Maximum Input Level

    +4 dBU: 18 dBV
    -10dBV: -6 dBV

  • Connector Type

    Line Outputs 1 - 8: 1/4" Female TRS Balanced
    Monitor Outputs 1 - 2: 1/4" Female TRS Balanced
    Stereo Headphone Outputs 1 & 2: 1/4" Female TRS Stereo (unbalanced)
    Line Inputs 5 - 8: 1/4" Female TRS Balanced
    Line Inputs 1 - 4: 1/4" Female TRS Balanced
    Hi-Z Inputs: 1/4" Female TS Unbalanced
    Microphone Inputs 1 - 4: Female XLR Balanced (pin 2 positive)

  • Dynamic Range

    Line Outputs 1 - 8: 118 dB (A-weighting)
    Monitor Outputs 1 - 2: 115 dB (A-weighting)
    Stereo Headphone Outputs 1 & 2: 113 dB (A-weighting)
    Line Inputs 5 - 8: 117 dB (A-weighting)
    Microphone Inputs 1 - 4: 118 dB (A-weighting)
    Hi-Z Inputs: 117 dB (A-weighting)
    Line Inputs 1 - 4: 117 dB (A-weighting)

  • Frequency Response

    Line Outputs 1 - 8: 20 Hz - 20 kHz, +/-0.1 dB
    Monitor Outputs 1 - 2: 20 Hz - 20 kHz, +/-0.1 dB
    Stereo Headphone Outputs 1 & 2: 20 Hz - 20 kHz, +/-0.1 dB
    ANALOG I/O: 20Hz-20kHz, +/-0.1 dB

  • Signal-to-Noise Ratio

    Line Outputs 1 - 8: 118 dB (A-weighting)
    Monitor Outputs 1 - 2: 114 dB (A-weighting)
    Stereo Headphone Outputs 1 & 2: 113 dB (A-weighting)
    Line Inputs 5 - 8: 117 dB (A-weighting)
    Microphone Inputs 1 - 4: 118 dB (A-weighting)
    Hi-Z Inputs: 117 dB (A-weighting)
    Line Inputs 1 - 4: 117 dB (A-weighting)

  • Total Harmonic Distortion + Noise

    Line Outputs 1 - 8: -106 dBFS
    Monitor Outputs 1 - 2: -103 dB
    Stereo Headphone Outputs 1 & 2: -102 dB
    Line Inputs 5 - 8: -107 dBFS
    Microphone Inputs 1 - 4: -110 dBFS
    Hi-Z Inputs: -103 dB
    Line Inputs 1 - 4: -107 dBFS

  • Stereo Level Balance

    Line Outputs 1 - 8: +/-0.05 dB
    Monitor Outputs 1 - 2: +/-0.05 dB

  • Channel Separation

    Line Outputs 1 - 8: Greater than 120 dB
    Monitor Outputs 1 - 2: Greater than 120 dB
    ANALOG I/O: Greater than 120 dB

  • Output Impedance

    Line Outputs 1 - 8: 600 Ohms
    Monitor Outputs 1 - 2: 600 Ohms

  • Maximum Output Level

    Line Outputs 1 - 8: 18 dBV
    Monitor Outputs 1 - 2: 18 dBV

  • Maximum Output Power

    80 milliwatts into 600 Ohms

  • S/PDIF Connector Type

    Male Phono (RCA)

  • S/PDIF Format

    IEC958

  • S/PDIF Supported Sample Rates (kHz)

    44.1, 48, 88.2, 96, 176.4, 192

  • ADAT Connector Type

    Optical TOSLINK JIS F05

  • ADAT Format

    ADAT Digital Lightpipe with S/MUX

  • ADAT Supported Sample Rates (kHz)

    44.1, 48, 88.2, 96, 176.4, 192

  • Channel Assignments at 44.1 kHz, 48 kHz

    Port 1 = Channels 1 - 8, Port 2 = 1 - 8 (mirrored)

  • Channel Assignments at 88.2 kHz, 96 kHz

    Port 1 = Channels 1 - 4, Port 2 = Channels 5 - 8

  • Channel Assignments at 176.4 kHz, 192kHz

    Port 1 = Channels 1 - 2, Port 2 = Channels 3 - 4

  • Word Clock Connector Type

    BNC

  • Lock Range

    +/-0.5% of any supported sample rate

  • Word Clock Input Termination

    75 Ohms , switchable

  • Power Supply

    External AC to DC Power Supply

  • AC Input Connector

    Type IEC Female

  • AC Requirements

    100V - 240V AC, 50 - 60 Hz

  • DC Connector Type

    XLR 4-Pin Locking Male (Neutrik P/N NC4MDM3-H)

  • DC Requirements

    12 VDC, +/-5%

  • Maximum Power Consumption

    50 Watts

  • Operating Temperature Range

    32 deg. to 104 deg. Fahrenheit (0 deg. to 40 deg. Celsius)

  • Storage Temperature Range

    -40 deg. to 176 deg. Fahrenheit (-40 deg. to 80 deg. Celsius)

  • Operating Humidity Range

    10% - 95% Non-Condensing

  • Dimensions (W x D x H)

    19 x 12.12/13.5 x 1.75" (48.26 x 30.78/34.29 x 4.44cm)

  • Weight

    9.1lbs (4.12kg)

About Universal Audio Apollo Interface - SKU#1600825

The Universal Audio Apollo Interface with Realtime UAD DUO Processing and Thunderbolt is a 18 x 24 interface allows you to record with near-zero latency through the full range of UAD Powered Plug-Ins ingeniously merging classic analog tones with cutting-edge features.

Class-Leading 24-bit/192 kHz Sound Quality
Designed to play a central role in a modern Mac- or Windows 7-based studio, Apollo incorporates an uncompromising approach to audio quality. Building upon decades of UA hardware heritage, it offers extremely high-resolution sound, with the lowest THD and highest dynamic range in its class. Apollo's four premium mic preamps, top-end converters and UA's meticulous attention to circuit design translate into greater accuracy in your recordings, from tracking and overdubbing, to mixing and mastering. In fact, its sound quality is on par with dedicated converters costing thousands more.

Realtime UAD Plug-In Processing for Tracking, Mixing and Mastering
While Apollo's "natural" sound is exceedingly open and transparent, it can quickly deliver a wide range of classic analog tones and color via its Realtime UAD Processing. Apollo's onboard DSP Acceleration allows for recording through UAD Powered Plug-Ins with as low as sub-2ms latency so that producers can quickly monitor, audition and "print" audio using classic analog emulations from Ampex, Lexicon, Manley, Neve, Roland, SSL, Studer and more. Better still, Apollo's Realtime UAD Processing is also available during mixing and mastering, so that music producers can use UAD plug-ins (VST, RTAS, AU, AAX 64) throughout the creative process.

Track Through Classic Mic Preamps Using Unison Technology
Unison technology allows Apollo's mic preamps to sound and behave like the world's most sought-after tube and solid state preamps including their all-important impedance, gain stage "sweet spots," and circuit behaviors. Based on breakthrough integration between Apollo's digitally controlled analog mic preamps and its onboard UAD processing, Unison lets you track through colorful preamp emulations like the bundled UA 610-B Tube Preamp plug-in.

High-speed Thunderbolt Connection toMac
Apollo offers compatibility with Thunderbolt technology on Macs via a user-installable dual-port Thunderbolt Option Card. Thunderbolt provides greater UAD plug-in instances, improved performance at high sample rates and reduced UAD plug-in latency. Because Thunderbolt offers many times the bandwidth of FireWire, it allows studios to connect numerous devices in series with the Apollo interface including hard drives, processors and additional computer monitors all with fast, flawless performance.

Hardware Design and Workflow
One key feature of Apollo isn't really a "feature" at all. It's the numerous design details that give you a fast, natural workflow and better results. There are physical front-panel controls for all the most commonly used features, including Preamp and Monitor level knobs, channel selection, mic pad and low cut, phantom power and dual headphone outs with independent level control. Smart Hi-Z inputs on the front panel detect when you've connected your guitar or bass and automatically enable hardware and software monitoring.

Console Application and Console Recall Plug-In
The Console application is Apollo's software control interface. Its intuitive, analog console-style design provides "realtime" tracking and monitoring with UAD Powered Plug-Ins a feature not found in any other interface. Complete Apollo Console setups can be saved as presets or even saved within your sessions using the Console Recall plug-in (VST, AU, RTAS, AAX 64). This enables hardware recall of all Apollo settings, even months and years after you last opened session.

Deeper Integration with Pro Tools, Logic, Cubase and More
Apollo's Core Audio and ASIO drivers ensure compatibility with all major DAWs, including Pro Tools, Logic Pro, Cubase and more. The included Console application and companion Console Recall plug-in (VST, AU, RTAS, AAX 64) provide control and recall of all interface and Realtime UAD plug-in settings within your DAW sessions, even months and years later. A new "PT Mode" allows easier insertion of external hardware in Pro Tools and a new Virtual I/O feature allows Realtime UAD Processing of DAW tracks and virtual instruments.

What's in the box:

  • Universal Audio Apollo Interface with Real-time UAD DUO Processing and Thunderbo- External Power Supply (SNAP-A087-3)
  • Power Cable
  • Item Note: Missing 6' Firewire 800 Cable; 4x Rack-Mount Screws
