Approx. 18.1 million effective pixels (Total pixels: Approx. 19.3 million)
5208 x 3477 effective pixels
Full-Frame CMOS sensor
6.95 microns square
Same as indicated on lens (as indicated on lens)
4K: approx. 1.3x; Super 35mm Crop: approx. 1.6x
Canon EF Lenses (excluding EF-S, EF-M lenses)
Canon EF Cinema (CN-E) lenses
Since the image circle of EF Cinema zoom lenses only support the image sizes of Super 35mm Crop and APS-C, vignetting will occur if you shoot larger image sizes
61
1 to 5 cross-type AF points at f/2.8
- 10 to 20 cross-type AF points at f/4
- 15 to 21 cross-type AF points at f/5.6
1 cross-type AF point at f/8
(The number of cross-type AF points will differ depending on the lens.)
Single-point AF (Manual selection)
Auto selection 61-point AF
Single-point Spot AF (Manual selection)
AF point expansion (Manual selection, 4 points: up, down, left, and right)
AF point expansion (Manual selection, surrounding 8 points)
Zone AF (Manual zone selection)
Available
One-Shot AF
Predictive AI Servo AF
Manual focus
For automatic AF point selection, the AF point to start the AI Servo AF operation can be selected. For automatic AF point selection, the active AF point can be displayed.
Recording Format: MOV
4K: Motion JPEG
Super 35mm Crop, Full HD, HD
MPEG-4 AVC (H.264), variable bit rate
Audio: Linear PCM, Meta information is embedded in the MOV file (no separate THM file
NTSC and PAL
Coverage: Approx. 100% vertically and horizontally
Color space matches the TV monitor
YCbCr 4:2:2 (8bit): 4K
YCbCr 4:2:0 (8bit): Super 35mm Crop, Full HD, HD, SD
Rec. ITU-R BT.601: 4K, SD
Rec. ITU-R BT.709: Super 35mm Crop, Full HD, HD
Based on current Picture Style
Canon Log gamma * View Assist possible
Full range (0-255)
Count up: Rec run, Free run
Start time setting: Manual entry, Reset, Set to camera time
Count indicator: Rec/Play time (Recording and playback time), Timecode
Drop frame: Enable, Disable
4GB
12 hours
Possible - Output frame rate: Auto/24p/50i/60i
Adding time code is possible
Possible to synchronize an external recording device to start/stop recording
1080: 60i/50i/24p, 480/60p, 576/50p
Before movie shooting: 1080: 60i/50i/24p
During movie shooting: 1080: 60i/50i/24p
Linear PCM
Internal monaural microphone
External stereo microphone jack
Recording level automatically adjusted
Sampling frequency: 48 kHz, Bits: 16 bit x 2 ch
Compatible with a commercially-available external microphone with 3.5mm dia. stereo mini-jack.
Stereo mini-jack (3.5mm diameter) provided * Max. -9dBv (with 16 k ohm)
Stereo mini-jack (3.5mm diameter) provided * Max. -9dBv (with 16 k ohm)
Sound-recording level: Auto, Manual (64 levels), None
With the movie silent setting, recording level can be changed with touch pad
Sound-recording meter: Provided
- Wind filter: Disable/Enable
Not provided
Based on current Picture Style
Canon Log gamma (View Assist possible)
Same as focusing with Live View shooting
During movie shooting, the image cannot be magnified for manual focusing
Compatible with power focus mode in movie shooting
AF point-linked evaluative metering
When the AF mode is Live mode or Face Detection Live mode
Center-weighted average metering
For manual focusing or when the AF mode is set to Quick mode
Metering range: EV 0 to EV 20 (At 73°F / 23°C and ISO 100, with 50mm f/1.4 lens)
Program AE for movie shooting
For shooting modes other than manual exposure and bulb
Shutter speed (1/30-1/4000 sec., signal accumulation time), aperture, and ISO speed automatically set.
Manual exposure
For manual exposure
Shutter speed (signal accumulation time), aperture, and ISO speed (auto/manual) manually set. The shutter speed (signal accumulation time) is limited to 1/4000 sec. at the maximum and to 1/30 sec. at the minimum for 24/25/30 fps or 1/60 sec. or higher for 50/60 fps.
P, Av, Bulb: Automatically set within ISO 100-25600
Expandable to H (equivalent to ISO 51200), H1 (equivalent to ISO 102400) and H2 (equivalent to ISO 204800)
Tv: Automatically set within ISO 100-25600
M: With Auto ISO, automatically set within ISO 100-25600
With manual setting, ISO 100?25600 set manually (in 1/3- or wholestop increments). Expandable to H (equivalent to ISO 32000/40000/51200), H1 (equivalent to ISO 102400) and H2 (equivalent to ISO 204800).
If highlight tone priority is set, the ISO speed range will be ISO 200-25600
Up to +/-3 stops in 1/3-stop increments
Up to +/-3 stops in 1/3-stop increments
During movie shooting, press AE Lock button to set AE lock and the AF point selection button to cancel AE lock (no automatic cancellation)
AE lock (canceled automatically when metering turns off) possible before movie shooting. Movie shooting can start while AE lock is in effect.
Not Provided
Switchable with INFO button (5 settings)
With an IS lens and the Image Stabilizer switch turned on, image stabilization operates during metering and movie shooting
Exposure
Depth of field
White balance
White balance compensation
Picture Style
Auto Lighting Optimizer
Peripheral illumination correction
Chromatic aberration correction
Highlight tone priority
Still photos shooting possible during movie shooting by pressing the shutter button (Still image capture is not possible when Canon Log gamma is set, or when 4K, Super 35mm Crop, or Full HD recording at 60p/50p is set)
Still shooting will interrupt the movie shooting
The still photo is inserted in the movie for about 1 sec
Exposure control used for movie shooting is applied to the still shooting
Flash cannot be used
Super high-speed continuous shooting at 14 fps cannot be selected
Enabled with Wireless Controller LC-5. Possible only when the shutter button can start/stop the movie shooting
1. Playback on camera LCD monitor
2. Playback on TV connected with AV or HDMI cable
3. Playback with ImageBrowser EX
Recommended are (1) and (2), while (3) requires a high-performance personal computer
4K: 1 hr. 25 min. at 73°F / 23°C
1 hr. 15 min. at 32°F / 0°C
Full HD (30 fps, ALL-I): 2 hr. 10 min. at 73°F / 23°C
2 hr. at 32°F / 0°C
The following playback is possible:
Playback, Slow motion (variable speed possible), Jump to first frame, Previous frame, Next frame, Jump to last frame, Edit first or last frame, and Audio volume (11 levels, including mute)
The audio level when the camera is connected to a TV set is adjusted with the TV set
First/last scenes editable (deletion) in 1-sec. increments
Possible with updated version of ImageBrowser EX
JPEG, RAW (14-bit)
JPEG (compression adjustable) RAW (CR2)
M-RAW
S-RAW
RAW + JPEG
M-RAW + JPEG
S-RAW + JPEG
Large - 5184 x 3456 (Approx. 17.90 million pixels)
Medium 1 - 4608 x 3072 (Approx. 14.20 million pixels)
Medium 2 - 3456 x 2304 (Approx. 8.00 million pixels)
Small - 2592 x 1728 (Approx. 4.50 million pixels)
RAW - 5184 x 3456 (Approx. 17.90 million pixels)
M-RAW - 3888 x 2592 (Approx. 10.10 million pixels)
S-RAW - 2592 x 1728 (Approx. 4.50 million pixels)
Complies with Design rule for Camera File system 2.0 and Exif 2.3
Creating new folders and selecting folders in the card is possible
CF card (2 slots)
Type I/II drive (Incompatible with Microdrive)
High-speed writing possible with UDMA CF cards
Select one of the CF cards to record.
When the current card becomes full, the camera switches to the other card automatically
The same image is saved to both cards, but in a different size (L, M1, M2, S, RAW, M-RAW, or S-RAW) that was set for the respective card
The same image is saved to both cards in the same size (RAW+JPEG also possible)
Possible between the two CF cards (2 slots)
Long exposure noise reduction (set with a menu):
Functions with exposures 1 sec. or longer
[Auto] or [Disable](always applied) settable
High ISO speed noise reduction (set with a menu):
[Standard], [Low], [High], or [Disable] can be selected
Dual DIGIC 5+ Image Processor
12 fps High-speed continuous shooting
14 fps Super high-speed continuous shooting
Single Shooting
High-speed continuous shooting (12 fps)
Low-speed continuous shooting (3 fps)
Silent single shooting
Self-timer (10 sec. and 2 sec.)
Super high-speed continuous shooting (14 fps)
JPEG Large: 180
JPEG Medium 1: 310
JPEG Medium 2: 1390
JPEG Small: 6430
RAW: 38
M-RAW: 28
S-RAW: 41
RAW + JPEG Large: 17
M-RAW + JPEG Large: 19
S-RAW + JPEG Large: 20
High-speed continuous shooting with 8GB UDMA-7 card based on Canon's testing standards and may vary depending on shooting conditions
Up to 1/250 sec
1. During SW-1 ON, time lag between SW-2 ON and start of exposure: Approx. 0.09 sec. *With flash, approx. 0.035 sec
2. Time lag between simultaneous SW-1/SW-2 ON and start of exposure: Approx. 0.55 sec
Approx. 0.1 sec (Based on CIPA testing standards)
High-speed writing possible with UDMA CF cards
3.2-inch (Screen aspect ratio of 3:2)
Approx. 1,040,000 dots
Approx. 100% coverage
Approx. 170° vertical and horizontal viewing angle
Manually adjustable to one of seven brightness levels
Single image display
Two types of single-image full display and two types of shooting information display
Index display
4-image index and 9-index image
Jump display, Jump 1 image, Jump 10 images, Jump 100 images, Date, Folder,Movies, Stills, or Rating
Carrier wave type, removes dust adhering to the infrared- and ultraviolet-blocking glass. Self-cleaning executed automatically (taking about 1.8 sec.) when power is turned on or off. Manual execution also possible (taking about 5.2 sec.). Low-pass filter has a fluorine coating
The coordinates of the dust adhering to the infrared- and ultraviolet-blocking glass are detected by a test shot and appended to subsequent images. The dust coordinate data appended to the image is used by the provided software to automatically erase the dust spots
Manual cleaning
100-51,200 in 1/3-stop or whole-stop increments
L: 50
H1: 102,400
H2: 204,800
Auto ISO: 100-51,200
1/8000 to 1/30 sec., bulb, X-sync at 1/250 sec.
Shutter speed's control range can be set with a Custom Function
Program AE (shiftable), Shutter-priority AE (Safety shift possible), Aperture-priority AE (Safety shift possible), Manual exposure, Bulb, E-TTL II autoflash program AE
252-zone metering with approx. 100,000-pixel RGB AE sensor and TTL maximum aperture metering employed
EOS iSA (Intelligent Subject Analysis) system employed
Evaluative metering (linked to all AF points)
Partial metering (center, approx. 6.5% of viewfinder)
Spot metering (center, approx. 2.5% of viewfinder)
Center spot metering
AF point-linked spot metering (Custom Function)
Multi-spot metering
Up to eight multi-spot meter
Center-weighted average metering
EV 0-20 (at 73°F / 23°C with 50mm f/1.4 lens at ISO 100)
Peripheral Illumination Correction
Chromatic Aberration Correction
Highlight Tone Priority
Auto Lighting Optimizer
Auto (AWB)
Preset (Daylight, Shade, Cloudy, Twilight, Sunset Tungsten, White fluorescent, Flash)
Custom (Custom WB)
Color Temperature (Approx. 2,500-10,000 Kelvin)
Personal WB settings PC-1 - PC-5 (up to five white balance data that you set yourself with the provided software.)
Alter white balance in amber-blue direction, and/or magenta-green direction +/-9 levels
Alter white balance in amber-blue direction or magenta-green direction, +/-3 levels in single-level increments
Auto, Standard, Portrait, Landscape, Neutral, Faithful, Monochrome, User Defined 1-3
Canon EX-Series Speedlites (Manual flash only with non EX-Speedlites)
Yes
Available
Available
+/-3 stops in 1/3-stop or 1/2-stop increments
Not Provided
AF Information:
AF Points
AF Confirmation
AF Status Indicator
Exposure information:
Metering mode
shooting mode
AE lock
Shutter speed
Aperture
Exposure compensation
ISO speed (always displayed)
Exposure level
Exposure warning
Flash information:
Flash ready
High-speed sync
FE lock
Flash exposure compensation
Image information
Battery check
Composition
Grid, electronic level
100%
Approx. 20mm
0.76x
Interchangeable
-3 ~ +1.0 (user-adjustable)
Electronic viewfinder with image sensor
Live mode (Contrast based)
Face Detection Live mode (Contrast based)
Quick mode (Phase based)
Magnified view, 3 Grid types, Correct Exposure/Exposure Simulation Display activated through Menu (Aspect Ratio indicator not provided.)
Exposures: 2 to 9
Type: Additive, Average, Bright, Dark
400,000 Cycles
HDMI mini OUT terminal (Type C), CEC compatible
Audio (stereo)/video (NTSC/PAL selectable) OUT terminal
3.5mm diameter stereo mini-jack
Not provided
For personal computer communications, direct printing (Hi-Speed USB)
Audio (stereo)/video (NTSC/PAL) output
Connects to GPS Receiver GP-E2 (Non-dedicated GPS)
N3-type terminal
Enabled with Wireless Controller LC-5
For Wireless Transmitter WFT-E6A and GPS Receiver GP-E1
RJ-45 jack (for gigabit Ethernet)
LP-E4 or LP-E4N Lithium-Ion battery pack
With the AC Adapter Kit ACK-E4, AC power is possible
With a fully charged LP-E4N Battery Pack:
Approx. 2 hr. 10 min. (at 73°F/23°C)
Approx. 2 hr. (at 32°F/0°C)
The power source type, remaining capacity (in 1% increments + 6-level battery check), shutter count, and recharge performance can be checked
The battery registration and operation history (serial number, remaining battery level when removed, and date) cannot be checked
Battery rechargeable regardless of remaining capacity
Exterior Material: Magnesium alloy
Weather Sealing: Dust and water resistant
6.2 x 6.4 x 3.3 in. (158 x 163.6 x 82.7mm)
3.4 lbs (1.5kg)
013803160130
Amazing
By STEPHEN R.
Great experience all around
Now under the umbrella of the Cinema EOS System, Canon is extending the flexibility of digital 4K origination with the EOS-1D C - the first Canon hybrid DSLR to offer onboard 4K motion imaging and Full HD motion imaging on CF cards, in a rugged, ultra-compact form factor. Coupled with Canon's compact EF-mount lenses, the EOS-1D C facilitates 4K image origination in the tightest and most challenging environments, opening up fresh cinematic opportunities along the way.
For anyone familiar with Canon's 5D Mark II or 1D product line, the size and weight of the EOS-1D C will be immediately familiar. The EOS-1D C features an 18.1-megapixel full frame CMOS image sensor that offers a wide range of image acquisition options, including 4K (4096 x 2160), HD (1920 x 1080); or 18-megapixel (5184 x 3456) still images. The 4K is recorded as Motion JPEG; the HD is recorded as H.264; and the still images are recorded as RAW or JPEG. All of the selected motion imaging formats can be recorded as normal gamma-corrected video or with Canon Log. In addition, like with other Cinema EOS products, the EOS-1D C exhibits incredible low-light performance, ensuring optimum image quality under conditions of extremely low scene illumination, essential for natural-looking image capture when shooting in challenging environments. For capturing stills, the EOS-1D C offers the same level of high performance as an EOS DSLR, with top-of-the-range focusing, exposure, and burst mode.
The EOS-1D C is designed to go where other 4K cameras cannot go - into hostile environments, into very cramped spaces, mounted on the end of extended jib arms, or embedded on-set. With onboard 4K recording at 24p or HD recording at a range of frame rates up to 60p; and Clean HD via HDMI, the EOS-1D C offers additional capabilities for film and TV production as well as specialty image acquisition applications. For added versatility, record start/stop can be remotely controlled by EOS Utility Software via a WFT unit.
Please Note:
This item is not Returnable
· 18.1 Megapixel Full-Frame CMOS Sensor
· Dual DIGIC 5+ Image Processors
· Compatibility with EF Cinema and EF Lens
· Full HD Recording Super 35mm Crop Mode
· Built-in-Headphone Terminal
· WFT-E6A Wi-Fi Unit with Remote Capabilities
