SoundTube LA880I Specifications

  • Color

    White

  • Certifications

    CCC, CE, RoHS

  • Enclosure Properties

    MDF, Painted, Plywood, Ported

  • Source Inputs

    4 Pin 5.08mm Euroblock, SpeakON

  • Crossover Frequency

    1.1 kHz 2.5 kHz

  • Directivity Factor (Q)

    6.9 and 12.3 (Averaged 100Hz - 10kHz, @ 2kHz)

  • Directivity Index (DI) dB

    9.2dB and 10.9dB (Averaged 100Hz - 10kHz, @ 2kHz)

  • Frequency Response

    58 Hz - 22 kHz ( +/- 10 dB)
    71 Hz - 22 kHz ( +/- 3 dB)

  • Grille Properties

    Powder-Coated, Steel

  • Low Frequency Voice Coil

    1" (25.4mm)

  • Low Pass Crossover

    12 dB per octave

  • Magnetically Boosted

    No

  • Max. Continuous Power RMS

    300 W

  • Max. Program Power

    500 W

  • Impedance

    Minimum: 4.3 Ohm
    Nominal: 4 Ohm

  • Mounting Depth

    11.99" (304.5mm)

  • Network Type

    High Pass : 12 dB per octave

  • Driver

    Tweeter: 2.5" Planar Magnetic Ribbon Tweeter
    Midrange: (8) 2" Midrange Paper with Foam Surround
    Woofer: (8) 4.5" Woofers Paper with Rubber Surround

  • Sensitivity dB

    At 1W/1M: 88 dB
    At 2.83V/1M: 91 dB

  • Transformer Taps (25V/70.0V/100V)

    38W/300W/300W

  • Dimensions (H x W)

    40.87 x 7.91" (1038.1 x 200.9mm)

  • UPC Code

    644216199501

About SoundTube LA880I

The SoundTube LA880i is not a typical line array column loudspeaker. It is an advanced LAPS (Line Array-Point Source) 3-way design that provides a very short near-field extent and robust far-field performance. Frequency tapering of low and mid frequency pass bands allows the LA880i to maintain a more consistent ratio of array height to radiated wavelength, ensuring a stable vertical beamwidth that out-performs many other single box line arrays. Featuring eight 4.5-inch woofers, eight 2-inch midrange drivers and one 2.5-inch planar magnetics (ribbon) high frequency driver for extremely smooth high frequency response, the LA880i achieves superb coverage in an enclosure measuring only 7.91" x 40.87" x 11.99".

SoundTube LA880I Features

  • Passive, fixed length, low frequency directivity element for SoundTube Line Array
  • Designed for use only with LA880i Line Array
  • Eight 4.5" (115mm) woofers
  • Extends low frequency directivity of line array systems by up to an octave lower than with the LA880i alone
  • Paintable enclosure is constructed of MDF and plywood with metal threaded mounting points
  • Powder coated, paintable steel grille
  • Available in black or white paint finish
  • Custom woodgrain cabinets or paint finishes available
  • Flexible mounting options include surface-mount, pole-mount, ceiling-mount or suspended (flown)
  • Euroblock and SpeakOn connectors allow for fast connections and easy daisy chaining
  • UL 1480 UEAY planned

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Passive, fixed length, low frequency directivity element for SoundTube Line Array
  • Designed for use only with LA880i Line Array
  • Eight 4.5" (115mm) woofers
  • Paintable enclosure is constructed of MDF and plywood with metal threaded mounting points
  • Powder coated, paintable steel grille
  • Available in black or white paint finish

What's in the box:

  • LA880I 3-Way Line Array Speaker (White)
  • 10' Safety Cable
  • 3x Black Zip Ties
  • AC-LA8-BACK Back Plate
  • 7x Mounting Bolts (1/4-20 x 0.5 ")
  • Euroblock Connector
  • SoundTube 5 Year Limited Warranty
