Multimedia SoC (System-on-Chip)
256MB
512MB
1/2.7" Progressive CMOS
2880x1616 (5MP)
Fixed-focal
f = 2.8mm
f/1.6
Fixed iris
111 Degree (Horizontal)
59 Degree (Vertical)
133 Degree (Diagonal)
1/5 sec. to 1/32,000 sec.
WDR Pro
Yes
Yes
Built-in IR Illuminator up to 30 meters with Smart IR, 2x IR LED
0.055 lux @ F1.6 (Color)
0.005 lux @ F1.6 (B/W)
0 lux with IR illumination on
90 Degree
180 Degree
Seamless Recording to MicroSD/SDHC/SDXC card (1TB capacity supported) and recording to network-attached storage (NAS)
Pixel Calculator
H.265, H.264, MJPEG
30 fps @ 2880x1616
3 video streams (Up to 7 configurable profiles)
30fps @2880x1616, 2688x1512, 2560x1440, 1920x1080, 1600x904, 1360x768, 1280x720, 640x360 (16:9)
30fps @1920x1080, 1600x904, 1360x768, 1280x720, 640x360 (16:9)
30 fps @ 1280x720, 640x360, 480x272 (16:9)
58 dB
120 dB
Adjustable resolution, quality and constant bit rate control, Smart Stream III
General settings: Video title and time stamp overlay, video orientation (flip, mirror, rotation), day/night settings
Illuminators: Illuminators, anti-overexposure/smart IR
Image settings: White balance, image adjustment (brightness, contrast, saturation, sharpness, gamma curve), defog, 3DNR
Exposure: BLC, HLC, exposure control (exposure level, exposure time, gain control), AE speed adjustment, WDR
Privacy mask
Pixel calculator
Scheduled profile settings
Two-way Audio
MPEG-2 AAC-LC, G.711, G.726
Built-in microphone
External line Input
External line output
16.4' (5m)
Live viewing for up to 10 clients
Access list, CSRF protection, digest authentication, HTTPS , IEEE 802.1x, Password protection, signed firmware, Trend Micro IoT Security (brute force attack event, cyberattack event, quarantine event), user access log, user account management
802.1X, ARP, Bonjour, CIFS/SMB, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMPv3, IPv4, IPv6, NTCIP, NTP, PPPoE, QoS (CoS/DSCP), RTSP/RTP/RTCP, SMTP, SNMP, SSL, TCP/IP, TLS 1.2/1.3, UDP, UPnP
10 Base-T/100 Base-TX Ethernet (RJ-45)
Profile G, S, T supported, Onvif 21.06
SoC with built-in hardware deep learning accelerator
Object Detection: People, Vehicle (4-wheeled), Human / Vehicle Bestshot, Path Extraction
Deep Learning VCA (Smart Motion Detection, Smart VCA)
Smart VCA - Group 1: Smart Motion Detection (Five-window video motion detection, People detection, Vehicle detection, Time filter), Smart VCA (Intrusion detection, Loitering detection, Line crossing detection)
Trend Micro (Default, 1-year free trial)
Motion Detection (Five-window video motion detection)
Periodically trigger, system boot, manual trigger, digital input, motion detection, tampering detection, recording notification
Event notification via camera link, email, HTTP, FTP/SFTP, NAS server, SD card
File upload via email, HTTP, FTP, NAS server, SD card
Microsoft Windows 10/8/7
Mac 10.12 (Chrome only)
Chrome 58.0 or above
VLC: 1.1.11 or above
208.5' (63.6m)
83.4' (25.4m)
41.6' (12.7m)
20.7' (6.3m)
Black/White
RJ-45 cable connector for 10/100/100 Mbps Network/PoE connection
Audio line input
Audio line output
DC 12V power input
1x Digital input
1x Digital output
System power and status indicator
IEEE 802.3af PoE Class 3
DC 12V
DC12V: Max. 6.24W
PoE: Max. 6.38W, typical 3.5W
EMC: CE (EN 55032/EN 55035 Class A), UKCA (BS EN 55032/BS EN 55035 Class A), FCC (FCC Part 15 Subpart B Class A), RCM (AS/NZS CISPR 32 Class A), VCCI (VCCI-CISPR 32 Class A), IC (ICES-003 Issue 7, Class A)
Safety: UL (UL 62368-1), CB (IEC/EN 62368-1, IEC/EN 60950-22,IEC/EN 62471), LVD (IEC/EN 62368-1), UKCA (BS EN 62368-1)
Environment: IK10 (IEC 62262), IP66,IP67 (IEC 60529)
IA: BSMI (EMC: CNS 15936, Safety: CNS 15598-1)
Starting/Working: -22 Degree F - 140 Degree F (-30 Degree C - 60 Degree C)
90% RH (non-condensing)
Taiwan
3.58 x 6.6" (91 x 169mm)
23.4 oz (664g)
4710469356186
See More Details with Robust Design
Clear details in 5MP resolution
With 5MP resolution and 30 fps recording, capture sharp, detailed footage without frame loss. High-resolution video offers enhanced visibility and stronger evidence for investigations.
Clear vision in high-contrast conditions
Powered by WDR Pro, the camera delivers sharp, high-quality images, ensuring accurate detail capture in difficult high-contrast conditions for comprehensive surveillance.
Balanced IR in nighttime
VIVOTEK's Smart IR technology optimizes infrared intensity to ensure optimal exposure, capturing details in low-light conditions. With an effective IR range of up to 30M, it delivers reliable nighttime vision.
Metal housing with IK10 certification
IK10 metal housing safeguards the camera from vandal attacks and retains its color for a long-lasting, polished look.
Built for Everyone: Smart, Secure, and Everyday-Ready Solution
Focus on people and vehicle
Effortlessly detect and distinguish people, vehicles with Vision Object Analytics-designed to prioritize what truly matters.
Accurate alarm with Smart VCA
VIVOTEK Smart VCA offers precise object tracking, detects specified abnormal behavior, and provides detailed video analytics for targeted monitoring and real-time alarm.
Easy operation with cloud solution
VORTEX integration via the V-series embedded NVR offers plug-and-play convenience and cloud-based push notification, supporting fast response from any device. The xLite license plan provides free cloud access, scalable expansion, and unified remote management.
End-to-end security, secured operation
VIVOTEK safeguards your surveillance system with layered security. From device-level protection with Trend Micro, Secure Boot, and Signed Firmware, to cloud-level safeguards like AES-256 encryption, TLS 1.2, and MFA authentication-your data and access are fully secured across the entire ecosystem.
